LG LC7F-P User Manual

LG LC7F-P User Manual

Faceplate radio asm-receiver


Quick Links

Car AV
User Manual
Model Name : LC7F-P



Summary of Contents for LG LC7F-P

  • Page 1 Car AV User Manual Model Name : LC7F-P...
  • Page 2 5) Connect a portable music player to the auxiliary sound input to enjoy the rich sound of the Infotainment system. (2) Specifications *Product Item Categories Specifications Product Name Faceplate RADIO ASM-RECEIVER Model LC7F-P Dimensions Refer to image Weight 1.48kg(Base) / 1.52kg(XM, DAB) Specification Power source DC 12V Operational -30 ℃ ~ 80 ℃...
  • Page 3 *RF specifications [ BT ] Item Specifications Unit Frequency 2400 ~2483.5 Modulation Type GFSK, Π/4-DQPSK, 8-DPSK BT Power Power class 2 Datarate 1 ~ 3 Mbps channel spacing BT version BT 3.0...
  • Page 4 2. Component...
  • Page 5 3. Operation Item (#No.) Description (1) Display Display for Play/Reception/Menu state and information. (2) HOME button Press this button to enter the home menu. (3)/(6) Seek button Press this button to seek the station or media contents. Press and hold this button to turn the power on/off. (4) POWER button Press this button to turn the mute function on/off.
  • Page 6 (8) Interactions | Rotary Knob *Rotate *Push Users can rotate the Volume Users can press on the center of knob on the faceplate. the rotary-push knob to mute volume. (9) Touch Gestures *Tap *Press & Hold *Fling/Swipe *Pinch & Spread...
  • Page 7 4. Precautions 1) Always operate the vehicle in a safe manner. Do not become distracted by the vehicle while driving and always be fully aware of all driving conditions. Do not change settings or any functions. Pull over in a safe and legal manner before attempting such operations.
  • Page 8 Declaration of Conformity Hereby, LG Electronics European Shared Service Center B.V., declares that this device is compliant with the essential requirements and other relevant provisions of Directive 1999/5/EC. This device should be installed and operated with minimum distance 20 cm between the device...
