Acnodes APW5170 User Manual

17 inch 1920 x 1200 widescreen lcd
Hide thumbs

Advertisement

Quick Links

Download this manual
APW5170
User Manual
All rights reserved. Product description and product specifications are subject to change without notice.
For lastest product information, please visit Acnodes' website at www.acnodes.com
17" 1920 x 1200 Widescreen LCD
A l u m i n u m F r o n t B e z e l
P a n e l / V E S A M o u n t R e a d y
14628 Central Ave. Chino, CA91710
© Copyright 2015 Acnodes Corp.
Tel: 909.597.7588
Fax: 909.597.1939

Advertisement

loading
Need help?

Need help?

Do you have a question about the APW5170 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acnodes APW5170

  • Page 1 P a n e l / V E S A M o u n t R e a d y User Manual All rights reserved. Product description and product specifications are subject to change without notice. For lastest product information, please visit Acnodes’ website at www.acnodes.com 14628 Central Ave. Chino, CA91710 Tel: 909.597.7588 Fax: 909.597.1939...
  • Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 3: Table Of Contents

    Contents < Part. 1 > APW 5170 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 < Part. 2 > Specifications I OSD I Remote Controller P.6 - 7 Product Specifications P.8 - 9 On-screen Display Operation ( OSD ) P.10 Remote Controller ( RC-2 )
  • Page 4 Before Installation ● It is very important to mount the equipment in a suitable cabinet or on a stable surface. ● Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
  • Page 5 < Part 1 > < 1.1 > Package Content – APW 5170 APW 5170 17” Widescreen LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Mounting hardware X 1 pack - Mounting bracket x 4 pcs - M4* 6mm screw x 8 pcs - M4* 50mm screw x 8 pcs Standard IIO...
  • Page 6 (W x D x H) Weight Weight 469 x 57 x 331 mm 615 x 113 x 523 mm 5.5 kg 8 kg APW5170 18.4 x 2.2 x 13 inch 24.2 x 4.4 x 20.6 inch 12.1 lbs 17.6 lbs...
  • Page 7 < 1.2 > Dimension - APW 5170 Front View Side View Rear View UNIT : mm 1mm = 0.03937 inch Bottom View...
  • Page 8 < 1.3 > Panel Mount Installation – APW 5170 M4*50mm screw M4*6mm screw Mounting bracket x 8 p x 8 pcs x 4 pcs Hardware set part no. UV-BK#2 Steps ● Install 4 mounting brackets with 8 x M4*6mm screws ●...
  • Page 9 APW 5170 17” Industrial Panel Mount Widescreen LCD < 1.3 > VESA mount Installation – APW 5170 M4 screw VESA mount ( 100*100mm ) ¦ Hardware and M4*4 pcs for VESA mount are not provided...

  • Page 10: Product Specifications

    < Part 2 > < 2.1 > Product Specifications Mechanical APW 5170 Design Front Panel Black, RAL 9005 Rear Casing Dark grey, RAL 7037 VESA Mounting 100 x 100mm Other Mounting Panel mount Protection 3mm protective glass Panel Size ( diagonal ) 17.1-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines )
  • Page 11 Regulatory Safety Approval FCC & CE Environmental Operating Temperature 0 to 50°C degree Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical Product ( W x D x H ) 469 x 57 x 331 mm Specification 18.4 x 2.2 x 13 inch...

  • Page 12: On-Screen Display Operation ( Osd )

    < 2.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &...
  • Page 13 < 2.2 > On-screen Display Operation ( OSD ) Audio Audio mode : Movie / Voice / Normal / Music mode to choose Volume : Adjust the volume of sound Bass : Set the value of bass sound Treble : Set the value of treble sound Balance : Set the balance value of treble and bass sound...

  • Page 14: Remote Controller ( Rc-2 )

    < 2.3 > Remote Controller ( RC-2 ) INP UT MUTE -/-- AUTO F REE ZE ME NU SE LECT AS P ECT SLEEP ENTE R BA CK EXIT SWAP S OURCE POS ITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode.

  • Page 15: Part 3 > Options

    < Part 3 > Options < 3.1 > Option Table Options SDI *** Touc hscreen MCS multi-display control *** DC Power MIL-type / lockable connector TV ( Analog ) The user can only select either SDI or MCS inputs.
  • Page 16 17” Industrial Panel Mount Widescreen LCD < 3.2 > Options : 3G I HD I SD-SDI input Acnodes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with Full HD 1080p and ultra high resolution...
  • Page 17 More control is always good. Especially when it is necessary and ( Multi-display Control ) easy. Acnodes provides MCS solution to control the OSD of various LCD display up to 64 units. The RS-232C is used for the communication between the PC and...
  • Page 18 < 3.4 > Options : Touchscreen & driver 17" USB Touchscreen Specification Model e-Resistive e-Capacitive 5-Wire Resistive Capacitive Technology Single Single Touch Point Stylus or Finger Finger Method Activation Force = 50g / Stylus=R0.8 = 50g Durability 10 million touches 300 million touches Response Time 15 ms...
  • Page 19 Please follow the below steps to setup the touch screen:- Step 1. Run the bundled CD disc Step 2. Double click the Setup.exe Step 3. Follow the installation instruction to finish the setup Step 4. After installation, run the TouchKit program & the “4 point calibration” Please do the initial calibration after the first setup...
  • Page 20 < 3.5 > Options : DC Power Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA...
  • Page 21 < 3.6 > Options : MIL-type or Lockable Connector Input Part no. MIL Standard MIL - type MIL - DTL - 26482 MS3470W8-33P DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design flexibility possible.

  • Page 22: Tv ( Analog )

    < 3.7 > Options : TV ( Analog ) Audio Power BNC S-Video DVI-D HDMI HDMI out - in - out - in - in Video Video PC ( 1 ) For TV option, casing dimensions will be changed. ( 2 ) For RC-2 remote controller specifications, please refer to P.14...
