QUICK START GUIDE
WK-1-C Access Point
802.11ac Dual Band Access Point
Version 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WK-1-C and is the answer not in the manual?

Questions and answers

Related Manuals for Pakedge WK-1-C

Summary of Contents for Pakedge WK-1-C

  • Page 1 QUICK START GUIDE WK-1-C Access Point 802.11ac Dual Band Access Point Version 1.2...

  • Page 2: Table Of Contents

    Contents Package contents WK-1-C mounting Powering up the access point Configuring the hardware Step 1: Logging in Step 2: Radio Step 3: Creating security profiles Step 4: Configuration Technical Support...

  • Page 3: Package Contents

    • 2 LAN ports for network extensions System requirements • Windows or Mac PC with an Ethernet interface WK-1-C default settings • Operation Mode: Access Point • IP Address: IP will be automatically assigned by router if a DHCP server is detected or, if no DHCP server is detected, the default IP address will be automatically set to 192.168.1.250.

  • Page 4: Wk-1-C Mounting

    WK-1-C mounting 1 Open the release latch and push on the back of WK-1-C to swing the WAP out from the ceiling or wall bracket.
  • Page 5 2 Swing the WAP down.
  • Page 6 3 Using the supplied template, cut a 9.125” diameter circle at the desired mounting location for your WK-1-C. Route an in-wall Ethernet cable through the opening on the back of WK-1-C housing, then insert the WK-1-C into the ceiling or wall.
  • Page 7 4 Use a Phillips screwdriver to tighten the mounting ears. Use a clockwise rotation. NOTE: Do not use excessive force when tightening the mounting-ears. This can strip the mounting ears and render them non-functional.
  • Page 8 5 Plug the Ethernet cable into WK-1-C. Route the Ethernet cable as shown. Use the optional cable clip, if necessary.
  • Page 9 6 Swing the WAP back into the WK-1-C housing.
  • Page 10 WK-1-C installation with optional pre-construction bracket Pre-construction bracket sold separately. 1 Place the pre-construction bracket against the bottom of the ceiling studs at the desired mounting location. 2 Mark locations for mounting screws. Drill 1/16” pilot holes at marked locations. Secure the pre-construction bracket to ceiling studs using the provided hardware.

  • Page 11: Powering Up The Access Point

    Powering up the access point The access point can be powered by PoE+. See below for examples: Power using a PoE+ injector Laptop Laptop WK-1 Ethernet Cable Tablet Panel PoE+ Injector Ethernet Cable Switch Smartphone...
  • Page 12 The Wireless Access Point should now be up and running with its default settings. It does not need to be configured to be functional. To make changes to the SSID and security settings, you need to access the WK-1-C using a web browser.

  • Page 13: Configuring The Hardware

    In the password box, type pakedgea and click Login. NOTE: If your computer is not set to the default IP scheme of the WK-1-C (192.168.1.X), you must first configure the TCP/IP settings on your computer to log in to the WK-1-C through a web...
  • Page 14 Using Windows 10 1 Under Control Panel, Network and Internet, click View Network Status and Tasks. 2 On the left panel, click Change Adapter Settings, right-click Local Area Connection, then click Properties. 3 Select Internet Protocol Version 4 (TCP/IPv4), then click Properties. 4 Select Use the Following IP Address and enter the following information: IP address: 192.168.1.10...
  • Page 15 Using OS X 1 Under System Preference, click Network. 2 On the left panel, click Ethernet (or Thunderbolt Ethernet on newer Macs), then select Manually from the drop-down menu. 3 Enter the following information: IP Address: 192.168.1.10 Subnet Mask: 255.255.255.0 Additional settings can be left blank.
  • Page 16 The following page will display when logged in:...
  • Page 17 You can use the Where’s My WAP (WMW) software, which is free to download from the Dealer Portal section of the Pakedge website. This application will automatically scan the network for any Pakedge access point. Once the application finds the access points, you will have the option to change their IP addresses by clicking on the pencil icon.
  • Page 18 After you are logged in to the AP, hover over Network and click LAN. NOTE: The default IP Setting on the WK-1-C is DHCP. If you want to assign a static IP to the WK-1-C, select Static IP from drop-down menu and fill in the IP address, subnet mask, and...

  • Page 19: Step 2: Radio

    The first tab under Wireless is Radio. By default, the WK-1-C operates in Access Point Mode. The mode can be set for either the 2.4 or the 5 GHz band. The available modes for the WK-1-C are: Access Point, WDS Root Access Point, WDS Repeater and WDS Bridge.
  • Page 20 Access Point Mode In Access Point Mode, the WK-1-C broadcasts both 2.4 GHz and 5 GHz signals to stations that support 802.11 ac. Laptop Laptop WK-1 Tablet Panel Smartphone Ethernet Cable...
  • Page 21 In WDS Bridge Mode, you can connect the WK-1-C to a client by its Ethernet port. The WK-1-C will receive the wireless signal from an access point and send the signal out through its Ethernet port to the client. A separate WK-1-C must be in WDS Root Access Point mode for this setting to operate.
  • Page 22 WDS Repeater Mode WDS Repeater Mode can be used to connect two WK-1-C access points wirelessly and extend your wireless network coverage. A separate WK-1-C must be in WDS Root Access Point mode for this setting to operate. WK-1 Laptop...

  • Page 23: Step 3: Creating Security Profiles

    Step 3: Creating security profiles The next tab over is Security Profiles. You can change the Profile Name and security settings for 2.4 GHz and 5 GHz, then click Apply to finalize these changes. This security is known to be the most secure and is compatible with all the latest devices. Note: The device/client you are working with factors into its security types.
  • Page 24 The most secure and common mode is WPA2-PSK. This setting is known to be the most secure and is compatible with all the latest devices. NOTE: When choosing the security settings, consider your client devices. Older laptops or phones do not support WPA2 security. Also, some devices are only compatible with certain security types. You may want to reference your device specifications.

  • Page 25: Step 4: Configuration

    Step 4: Configuration In this section, you can change the SSID name by applying the security profile that was set up in Step 3, “Creating Security Profiles.” By default, the SSID is Pakedge2.4-1 and Pakedge5-1. You will have the option to change the Wireless Name (SSID) and add security profiles by selecting the options from the drop-down menu.
  • Page 27 Guest network This will allow you to set up a guest network. Please see manual for further details.

  • Page 28: Technical Support

    (650) 385-8703 For non-technical inquires: customerservice@pakedge.com (650) 385-8701 For regulatory information: www.pakedge.com/regulatory pakedgedevice&software inc 3847 Breakwater Avenue, Hayward, CA 94545-3606 Main: (650) 385-8700 Fax: (650) 685-5520 www.pakedge.com sales@pakedge.com ©2016 Pakedge Device & Software Inc. All rights reserved. DOC-00234-C 2016-07-21 MS...
