USER MANUAL
MOBILE VHF
RF POWER AMPLIFIER
RC3-1FE
3370 SAN FERNANDO RD., #206
LOS ANGELES, CA 90065
TEL: (323)256-3000
FAX: (323)254-3210
www.tplcom.com
L-RC3-1FE-U/K6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC3-1FE and is the answer not in the manual?

Questions and answers

Summary of Contents for TPL RC3-1FE

  • Page 1 USER MANUAL MOBILE VHF RF POWER AMPLIFIER RC3-1FE 3370 SAN FERNANDO RD., #206 LOS ANGELES, CA 90065 TEL: (323)256-3000 FAX: (323)254-3210 www.tplcom.com L-RC3-1FE-U/K6...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRODUCT DESCRIPTION ................. 2 GENERAL SPECIFICATIONS ..............2 OPERATING PRECAUTIONS ..............4 INSTALLATION ................... 5 WARRANTY ....................6 Page 1...
  • Page 3: Product Description

    PRODUCT DESCRIPTION The RC3-1FE model is a VHF broad band amplifier intended for use in mobile applications. This amplifier can deliver 100W when driven with 25W and it will cover the frequency range form 136-174 MHz. The amplifier’s dimensions are: 6.73"L x 1.94"H x 6.0" W, including tabs (see figure 1) and the weight is 2 lbs.
  • Page 4 CAUTION! nspect the amplifier thoroughly upon receipt for visible damage. If any is noticed, please call TPL Communications at 800 HI - POWER to request an RMA (Return Material Authorization) number. If purchased through a dealer or distributor, ask them to also follow this procedure for best results.
  • Page 5: Operating Precautions

    FCC CERTIFICATION TPL Communications commercial amplifiers are FCC certified for the use in Land mobile/fixed services. The technician installing this amplifier must hold a General Radio Telephone permit and be familiar with the pertinent FCC rules and regulations. Harmonics, and other spurious, signals from this amplifier are attenuated according to or beyond FCC requirements.
  • Page 6: Installation

    INSTALLATION The RC3-1FE amplifier installation is accomplished by the use of the flanges provided (see figure 1) to attach it to a radio transceiver. Keep coaxial cable runs short, avoiding sharp bends and pinching. Avoid loose connectors at the ends of the coaxial cables. The antenna should be matched to an SWR better than 1.5:1 for best results.
  • Page 7: Warranty

    TPL, nor does it extend to units which have been repaired or altered outside our service department, nor where the serial number has been removed, defaced or changed.
