Propane Stoves

Instructions for use

9966 Series

Read these instructions for use carefully. Familiarise yourself with the

appliance before connecting it to its gas container. Keep these instructions

for future reference.

This instruction manual contains important information necessary for

the proper assembly and safe use of the appliance. Follow all warnings

and instructions when using the appliance. If you have questions about

assembly, operation, servicing or repair of this product, please call Coleman

on 1800 224 350 or + 61 2 8762 5000. Coleman Brands Pty Ltd. ABN 74

091 681 195, Suite W2C1, 75-85 O'Riordan Street, Sydney Corporate Park,

Alexandria, NSW 2015, Australia.

Gas cylinders shall be changed in a well-ventilated location, preferably

outside away from people and any sources of ignition, such as naked

flames, pilot flames, electric heaters / equipment. If there is a leak on your

appliance (smell of gas) and you cannot stop the gas flow, remove the

appliance to a well-ventilated location away from any ignition source.

Check for leaks using soapy water. Do not try to detect leaks using a

flame. This appliance must only be serviced by an authorised person. Gas

cylinders must be stored outdoors in a well ventilated area out of the reach

of children, any indoor storage shall comply with AS/NZS 1596.

This appliance shall only be used with Propane LPG Coleman disposable

gas cylinders certified to DOT-39 NRC 232/290 M1110. OR refillable Propane

LPG cylinder certified to AS2030 & Coleman hose assembly. IT MAY BE

HAZARDOUS TO ATTEMPT TO FIT OTHER TYPES OF GAS CONTAINERS. DO

NOT USE ADAPTORS.

CAUTION: Accessible parts may be very hot. Keep young children away,

USE OUTDOORS ONLY. Must only be operated on a horizontal surface. Not

suitable for marine environments. Do not modify this appliance.

* The griddles are only included for certain models.

IMPORTANT

INSTASTART™ Electronic Ignition

Standard Ignition

Camp Stove

www.coleman.com

Table of Contents

Need help?

Do you have a question about the 9966 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Coleman 9966 Series

Page 1 If you have questions about assembly, operation, servicing or repair of this product, please call Coleman on 1800 224 350 or + 61 2 8762 5000. Coleman Brands Pty Ltd. ABN 74 091 681 195, Suite W2C1, 75-85 O’Riordan Street, Sydney Corporate Park, Alexandria, NSW 2015, Australia.
Page 2: For Your Safety
FOR YOUR FOR YOUR SAFETY SAFETY If you smell gas: Do not store or 1. Do not attempt to use gasoline or light appliance. other liquids with 2. Extinguish any flammable vapors in open flame. the vicinity of this or 3.
Page 3 Do not chemicals known to the state of attempt to adjust. California to cause cancer, birth ● Use only Coleman® accessories defects, or other reproductive harm. or parts. During stove set-up, check all fittings for leaks using...
Page 4: Carbon Monoxide Hazard
Perform another leak check. If there is still a leak, remove the cylinder and contact Coleman for service or repairs. ● Use as a cooking appliance only. Never alter in any way or use with any device or part not expressly approved by Coleman.
Page 5: Technical Characteristics
This stove consumes air (oxygen). Do not use in unventilated or enclosed areas to avoid endangering your life. NOTE: Use Coleman® 16.4 oz. Fig. 2 disposable propane cylinders. The 3. Assemble Lid Stopper to stove. LP-gas cylinder(s) used with stoves (Fig.
Page 6: Service Safety
● Do not use this griddle on a campfire or other open fire. ● Use this griddle only on the Coleman® stove for which it was Fig. 8 Fig. 9 designed. 10. Propane cylinder correctly 6.
Page 7: Leak Check
INSTASTART™ Leak Check Electronic Ignition Stoves WARNING 1. Set stove on sturdy, flat surface. For outdoor use only. ● Perform leak test outdoors. Open burner valve and repeatedly ● Extinguish all open flames. push igniter button until burner ● NEVER leak test when smoking. ignites.
Page 8: To Turn Off
To Turn Off 1. Close the burner valves firmly. (Fig. 15) Fig. 18 To check if the gas cylinder is empty, disconnect the cylinder from the appliance and shake from side to side. Fig. 15 If there is no sound or movement of liquid, the cylinder is empty.
Page 9: Explosion - Fire Hazard
Wind Shield Pan Support. Coleman Service Center. (Fig. 19) ● If not completely satisfied with the 2. Place the griddle (if included) on performance of this product, please the Wind Shield Pan Support.
Page 10: Replacement Parts List
Replacement Parts List Item Part No. Description 5010002508 Windshield Pan Support - Hyperflame R430B565T Regulator Assembly 5010002509 Handle Assy - 9966 Models 5010002507 Knob - 9966 Models Accessories: 2000017528 Griddle...
Page 11: Warranty
Coleman or Coleman service centre, the use of a part other than a genuine Coleman® part; or (d) acts of God, such as re, ood, hurricanes and tornadoes.
Page 12 NSW 2015, Australia Telephne: 1800 224 350 or + 61 2 8762 5000 www.coleman.com © 2014 The Coleman Company, Inc. All rights reserved. Coleman®, registered trademarks of The Coleman Company, Inc. The Coleman Company, Inc., a Jarden Corporation company (NYSE:JAH)
