Summary of Contents for Furious FPV KOMBINI DSHOT
- Page 1 KOMBINI DSHOT VERSION Flight Controller USER MANUAL VERSION 1.1 Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...
-
Page 2: Table Of Contents
Contents Change Log ......................2 Introduction ....................... 3 WHAT’S NEW KOMBINI DSHOT VERSION? ............3 Features ......................3 Connections ....................... 6 Connect with Receiver ..................6 Using SPD15 Receiver ................6 Using LR1000D Receiver ................ 7 Using XSR FrSky Receiver ............... 8 ... -
Page 3: Change Log
Change Log v1.1 Add guideline configuration OSD with TRUE VISION CONFIGURATOR V1.0 New OSD Menu Index... -
Page 4: Introduction
For the pinnacle in simplicity, performance and cutting edge capability, the Furious KOMBINI is the feature packed FC system that is ready and waiting to dominate. Get yours today, and change the way you FPV. WHAT’S NEW KOMBINI DSHOT VERSION? Remove PPM pin and add TX3 pin for the pinnacle in simplicity, performance ... - Page 5 5S 18.5V Ready Heavy Duty 1.5A BEC @ 5V and 0.8A BEC @12V Output Ultra Compact Design for Ease of Installation Gold Plated Pads for the Very Best Connectivity Firmware Perfection via BetaFlight BLHeli Pass Through Setup ...
- Page 6 Board Layout Dimensions...
-
Page 7: Connections
Connections *WARNING: Kombini DShot Version can support up to 5s Lipo battery but make sure other devices also support it. Connect with Receiver: Using SPD15 Receiver: You can buy SPD15 Receiver right here: https://goo.gl/FTnrpR... -
Page 8: Using Lr1000D Receiver
Using LR1000D Receiver: You can buy LR1000D Receiver right here: https://goo.gl/4Cr0Hl * NOTE: If you use LR1000D Receiver please go to CLI and type the following commands: set sbus_inversion = OFF save... -
Page 9: Using Xsr Frsky Receiver
Using XSR FrSky Receiver: Using Spektrum Satellite Receiver:... -
Page 10: Connect With Video Transmitter
Connect with Video Transmitter: Using Tramp HV: With Piggy V2 OSD... - Page 11 With Only Camera...
-
Page 12: Using Tbs Unify Pro
Using TBS Unify Pro: With Piggy V2 OSD... - Page 13 With Only Camera...
-
Page 14: Using Fx Fx799T
Using FX FX799T: With Piggy V2 OSD... - Page 15 With Only Camera...
-
Page 16: Connect With Stack Mnova And Runcam
Connect with stack Mnova and Runcam : * Mnova is only compatible with 5V input. Please only solder to 5V input You can buy Mnova right here: https://goo.gl/JyQnds... -
Page 17: Connect With Other Devices
Connect with other devices: You can buy LED STRIP right here: https://goo.gl/TXwSwI... -
Page 18: Connect With Esc 4 In 1
Connect with ESC 4 in 1: Using Aikon SEFM 30A: You can buy ESC Aikon SEFM 30 4 in 1 right here: https://goo.gl/IOYBEr... -
Page 19: Using Cicada 35X4 35A
Using Cicada 35x4 35A: You can buy ESC Sunrise Cicada 35x4 35A right here: https://goo.gl/s08OaI... -
Page 20: Using T-Motor F 35A 4In1-4S
Using T-Motor F 35A 4IN1-4S: You can buy ESC F 35A 4in1-4S right hexre: https://goo.gl/QyM3eh... -
Page 21: Basic Setup
Basic setup Please, follow carefully these next steps, and always remove your propellers when you’re configuring your quad STEP 1: Connect Kombini DS with the computer via USB cable and then open BetaFlight STEP 2: Configure Ports. (1) Turn on MSP of UART 1 to use OSD. (2) Turn on Serial Rx of UART 3 to use Receiver Mode (3) Select SmartPort of UART 2 to use S.Port of Receiver. -
Page 22: Tips
If you are using SBus, iBus or a Spektrum Satellite, you will need to pick your Serial Receiver Provider. Follow this table: RX Type Serial Receiver Provider DSM2 1024bit/22ms SPEKTRUM1024 DSM2 2048bit/11ms SPEKTRUM2048 DSMX 1024bit/22ms SPEKTRUM1024 DSMX 2048bit/11ms SPEKTRUM2048 FrSky RX SBUS Futaba RX SBUS... - Page 23 Then go to the Configuration tab. Under the section labeled “Receiver”, pick Serial Receiver Provider compare with your RX Type. RX Type Serial Receiver Provider DSM2 1024bit/22ms SPEKTRUM1024 DSM2 2048bit/11ms SPEKTRUM2048 DSMX 1024bit/22ms SPEKTRUM1024 DSMX 2048bit/11ms SPEKTRUM2048 Click “Save”. Finally, go to the Receiver tab. Pull down the drop down that says “Channel Map” and select the “JR / Spektrum / Graupner”...
-
Page 24: How To Turn On Bind Mode
How to turn on bind mode NOTE: Plug battery to the quad during setup. Connect quadcopter to the computer and go to Command-line interface (CLI) tab. Remember to type “save” and hit enter after these commands have been executed. Type in the commands as pictured above, or copy and paste them from below: set spektrum_sat_bind=9 set spektrum_sat_bind_autorst=0 save... -
Page 25: Guideline Configuration Osd With True Vision Configurator V1.0
Guideline configuration OSD with TRUE VISION CONFIGURATOR V1.0 Serial Pass Through don’t need CLI in Betaflight DOWNLOAD: Guideline install and configuration TRUE VISION CONFIGURATOR STEP 1: Connect Kombini DS (connected with VTX/OSD) with PC via USB cable. Then plug battery for FC. STEP 2: Open True Vision Configurator on google chrome. -
Page 26: How To Open Vtx/Osd Menu By Transmitter
How to open VTX/OSD menu by Transmitter To access the in-built OSD menu in MW-OSD, disarm your quadcopter first. THROTTLE MIDDLE YAW RIGHT PITCH FULL To navigate through menu in the OSD: PITCH/ROLL sticks are used to navigate ... - Page 27 Thanks for using our product...
