ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
show the degree of effort needed in assem-
bling a specific product (with 1 being easy and
5 being difficult). For most products, two per-
sons are recommended.
EASY
YNJ-1416-1 & 1416-5 & 1416-6
DIFFICULT
Page 1 of 13
TOOLS REQUIRED FOR ASSEMBLY
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
(Included)
(Not Included)
14-10-10
Advertisement
Summary of Contents for Furniture of America YNJ-1416-1
- Page 1 ASSEMBLY INSTRUCTIONS YNJ-1416-1 & 1416-5 & 1416-6 ASSEMBLY RATING TOOLS REQUIRED FOR ASSEMBLY The Assembly Rating is a 5-point system that Allen Wrench show the degree of effort needed in assem- (Included) Phillips Screwdriver bling a specific product (with 1 being easy and 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 13...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5 of 13...
- Page 6 MILTI-FUNCTION CABINET ASSEMBLY INSTRUCTIONS MODEL # YNJ-1416-1,1416-5,1416-6 Please keep for future reference PARTS LIST Before you begin, please read “Assembly and Care Advice”, “Pre- Assembly Introduction” and “Cam Lock Fastener Assembly Instructions”. DIMENSIONS 70.08”(W) X 15.75”(D) X 20.47”(H) PARTS LIST...
- Page 7 ASSEMBLY INSTRUCTIONS Assembling Drawer’s Runners (a.k.a. Rails, Glides, Slides or Guides) An assembly of ONE drawer requires two sets of runners. The runner is composed of an inner rail and outer slide. Please read completely first before assembling. Mounting the Inner Rail (Fixed) of the Runner: Before mounting, please determine which side of the panel is the front and rear.
- Page 8 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1 = 24pcs Hardware #2 = 14pcs Page 8 of 13...
- Page 9 ASSEMBLY INSTRUCTIONS STEP3 Hardware #2 = 2pcs Hardware #8 = 2 runners + 4 screws Screw Hole 2nd hole Flip Over Screw Hole 3rd hole STEP4 Hardware #4 = 8pcs Page 9 of 13...
- Page 10 ASSEMBLY INSTRUCTIONS STEP5 Hardware #2 = 8pcs Hardware #4 = 6pcs Hardware #12 = 8pcs STEP6 Hardware #12 = 16pcs Page 10 of 13...
- Page 11 ASSEMBLY INSTRUCTIONS STEP7 Hardware #1 = 4pcs Hardware #2 = 4pcs Hardware #3 = 4pcs Hardware #5 = 8pcs Hardware #6 = 4pcs Hardware #12 = 4pcs STEP8 Hardware #7 = 4 hinges + 16 screws Hardware #9 = 2 sets Hardware #13 = 4pcs hole usage Fasten screw from the inside of the drawer...
- Page 12 ASSEMBLY INSTRUCTIONS STEP9 Hardware #10 = 8 sets Make sure the product is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened. ASSEMBLY IS COMPLETED Page 12 of 13...
-
Page 13: Hinge Adjustment
HINGE ADJUSTMENT Height Adjustment Two screws, located at the top and bottom of the hinge, mount the hinge to the cabinet. Turn these first to make sure the door is secure. If the door is still too high or low, loosen these screws slightly and then lift or lower the door until it is in the position you want.
