Wireless PIR Smoke Detector
IP Camera
Model: 2643-62/2650-62/2651-62
en Operation and Installation Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2643-62 and is the answer not in the manual?

Questions and answers

Related Manuals for Golbong 2643-62

Summary of Contents for Golbong 2643-62

  • Page 1 Wireless PIR Smoke Detector IP Camera Model: 2643-62/2650-62/2651-62 en Operation and Installation Manual...

  • Page 2: Table Of Contents

    WELCOME ................................4 PRODUCT OVERVIEW ............................. 5 HARDWARE INSTALLATION ..........................5 Attach the External Power Adapter........................5 Install the microSD card to the TF card slot...................... 6 SMARTPHONE OR TABLET APPS ......................... 6 ............................... 6 OWNLOAD APP ..................... 8 ONNECT THE CAMERA TO YOUR HOME NETWORK .............................
  • Page 3 Setting Camera Parameters ..........................61 Installing a new Firmware ..........................63 WEB BROWSER CONNECTION ........................... 64 ....................64 HECKING YOUR WEB BROWSER SECURITY LEVEL ........................66 CCESS THE CAMERA OVER INTERNET...

  • Page 4: Welcome

    Email GOLBONG Customer Support: support@golbong.com Important Security Warning In order to keep your GOLBONG camera secure and prevent unauthorized access, please make sure to follow the steps below: Never use the default password for your camera. Always ensure that your password is at least 8-10 characters long and contains a combination of lowercase characters, uppercase characters as well as numbers.

  • Page 5: Product Overview

    Product Overview Hardware Installation Attach the External Power Adapter Connect the power adapter to the power connector on your camera, then plug the power adapter into a wall outlet...

  • Page 6: Install The Microsd Card To The Tf Card Slot

    Install the microSD card to the TF card slot. open the cover with screw drive Insert the TF memory card Smartphone or Tablet Apps Download app Download: Search and install the app “XMEYE” in app store or Google play.
  • Page 7 Power up the camera and wait for 2 minutes Enter the WIFI setting of your smart phone. A new AP spot will appear. Connect the new AP, fill in the password “1234567890”...

  • Page 8: Connect The Camera To Your Home Network

    Login the XMEYE, press the “Direct Login” at the right down on screen. Click the camera list to watch the live. Connect the camera to your home network. Double press (twice) the inline reset button continuously...
  • Page 9 The new AP should disappear on your smart phone’s wifi setting. The camera was switch to “Network mode” NOTE: If you still see the AP spot, disable-enable the “WLAN” on your smart phone. NOTE: Press the reset button for 10 seconds can reboot the camera and return back to “AP”...
  • Page 10 NOTE: Click “Login Problem?” You can register a new account. On the Device List page, click the “+” right-top on screen. On the Add Device page, select the “Quick Configuration”...
  • Page 11 Fill in the password of your home router, and click both “Ensure the indicator” and “Device Operation” NOTE: you can ignore the remark message, click it anyway. Press “Deep Config”...
  • Page 12 NOTE: After pressing “Deep Config”, the screen will display a sentence and click “yes” Wait for 1 minute, a green cam icon pop up on the screen. Click the icon to add the camera...

  • Page 13: Live View Interface

    NOTE: if you fill in the wrong password of your home router, you need to press the reset button for 10 seconds. Then return to the step “a”. Click the camera list to watch the live. Live view interface Click the camera name in the device list, the live view will display.
  • Page 14 Press the square icon on the upper right corner to enlarge the video to full screen. NOTE: The users can zoom in/out on the screen with fingers. Click “SD/HD” to choose the video quality. NOTE: “SD”: standard definition; “HD”: high definition. 4 channels: In the live video page, choose the number “4”, click “+”...
  • Page 15 NOTE: User can select 1/4/9/16 channel Touch the tick icon on right to select the camera. NOTE: The tick will change to red once selected. Press the “Start preview” at the bottom to watch multi-channel video.

  • Page 16: Optional 1: How To Change The Video Quality To Adapt To Low Bandwidth Network

    Press speaker button to hear the voice from the camera NOTE: Your camera must support audio and connects to audio pick up. Optional1: How to change the video quality to adapt to low bandwidth network. In the Live Video page, click the Home icon Touch “Encode”...

  • Page 17: Set A Password For The Camera

    NOTE: higher frame rate and resolution require higher bandwidth Set a Password for the Camera. In the Live Video page, click the Home icon In the Menu page, press the “Change password ” Input old password and a new password. Click “Save”...
  • Page 18 NOTE: default password is blank.(No need) Click return icon to enter Device list click the edit icon , a new dialog pop up Select “Edit” Name the device, key in the new password. Click OK to save.

  • Page 19: Saving Live Stream To Your Smart Phone

    Saving live stream to your smart phone In Live Video page, press “camcorder” button to start recording NOTE: Camcorder button will change to Blue when recording is activated. Press camcorder button again to save the video Click return icon to enter Device list Press the list icon to enter the main menu...

  • Page 20: View Snapshot At Local Files

    Touch “local record” to locate the video on your smart phone. Press the snapshot will start play the video on your phone. Press the edit icon on top right corner, press snapshot to select the video. Press the save icon to save the video to your phone.

  • Page 21: Playback Footage On Tf Memory Card ( Cameras With Micro Sd Only )

    Touch “Local Album” to view the snapshot. Press the edit icon on top right corner, select the snapshot to view the picture. Press the save icon to save the snapshot to your phone. Playback footage on TF memory card (cameras with microSD only) Touch home icon in the live view page.

  • Page 22: Optional : How To Enable The Motion Recording From Your Smart Phone

    Press “Remote playback” from the menu The playback video will display. Press the button on right corner, you can select the time unit: h/m/s NOTE: the footage block in Yellow is the video with motion detection. You need to enable the motion recording function in the camera to see the yellow block.

  • Page 23: Download Footage From Tf Memory Card (Cameras With Micro Sd Only )

    2. Press the “Motion detection”, slide the icon to right for “alarm”, “alarm record”, press “OK” to save. Download footage from TF memory card (Cameras with microSD only) In the live, press Home to enter “Menu”, press “Download”...
  • Page 24 2. Choose either download by file or by time Click the “Download” icon, the app start downloading by file Click icon twice to return to device list Press the icon to enter the main menu...

  • Page 25: Enable Push Notification

    Touch “local record” to view the download video. Enable Push Notification In the live view page, Touch home icon. Press “Alarm Config” from the menu, a new dialog pop up. Press the “Motion detection”, enable “Send To Phone”, press “OK” to save.
  • Page 26 Click icon twice to return to device list Press the icon to enter the main menu Press Alarm Push, Slide the icon to right turn on alarm push notification.
  • Page 27 7. Click the camera name to see the motion detection detail of the camera. 8. In push setting, if the “open failed” pop up on screen, that mean we need to give this app authority to receive push message. It usually happens with iOS. Go to settings of your iphone.
  • Page 28 10. Touch “Notifications”, and find XMEYE 11. In the XMEYE page, slide the icon to right to enable the notification function from you smart phone.

  • Page 29: Optional Receive The Ip Setting From Your Local Network (Dhcp)

    Optional Receive the IP setting from your local network (DHCP) If the IP camera don’t have correct IP setting, especially DDNS, it will failed to receive the push message. 1. Touch home icon in the live view page. 2. Touch “set Network” from the menu, enter a new screen. 3.

  • Page 30: Using Cms5 For Pc Or Mac

    Using CMS5 for PC or Mac System Requirements Core 2 Duo 3.0GHz Windows™ 8/7/Vista Operating System Memory Video 512 MB of video memory and above Network (LAN) 10/100 Base-T Network Network (WAN) 1 Mbps upstream High-speed Internet service is required to remotely connect to your system.
  • Page 31 NOTE: The default username and password of the software is “admin” If you want to revise the login username and password of the software, go to the “Main” click "User Manager" , change the new password. , Click “Add Cameras” to enter a new screen. In the "Main"...

  • Page 32: Optional 1: What Should You Do When Ip Address Get Conflict

    under “operation”, a new dialog pop up, name the camera, Click “OK” Click the pen icon to save. NOTE: NO password required for camera/NVR in default. You can jump to page-11 to change camera’s password. NOTE: If you want to access the camera over internet, choose cloudID in “Login Type” Once the software has connected the camera successfully, the “Status”...

  • Page 33: Optional 2: How To Add The Cameras To Cms5 Outside Of Lan

    Return back to step 3. Click “IPV4 search” again. Following step 4 and step 5 until you add all the camera successfully. Optional 2: How to add the cameras to CMS5 outside of LAN Click “Manual Add” button at the lower right corner. A new dialog appear. Name the camera, Choose the login type.
  • Page 34 Click Network icon, a new screen will appear with “TCP/IP” setting. Modify the IP setting. Click ”OK” to save Important: The DNS should be configured correctly, otherwise the cloud connection and email notification may not be working. NOTE: If you don’t know you network setting, mark “enable DHCP” to receive the IP setting from your local network.

  • Page 35: Live Video

    Live Video Watch the live In the "Main" ,. Click "Live" icon to enter live view interface. Double click the camera in the devices list. CMS5 will start receiving the live. NOTE: Double click the name again can close the video. Digital ZOOM Right the video you want to operate digital zoom on the screen, select “Digital Zoom”...

  • Page 36: Activate The Audio ( Camera Supports Audio And Connect To The Audio Pick-Up Only)

    Hold the left-button on mouse to selected area in red square. As shown below: Release the mouse to zoom in. Right click mouse again, uncheck “digital zoom” to close the zoom operation. Activate the audio ( camera supports audio and connect to the audio pick-up only) In the live, Click headset icon“...

  • Page 37: Ptz Control (Camera With Motorized Zoom Lens Only)

    PTZ control (camera with motorized zoom lens only) In the live, click the joystick icon on the top right window, a joystick panel appear Click the panel button, you can pan/tilt/zoom with camera Change the Password of the Camera Set a new password for “admin” , click ”Device Config”.

  • Page 38: Optional1: How To Create An Account For Operator

    4. Click ”Modify Password”. A new screen pop up. Enter the old password and your new password. Click “OK” to save. Note: The default password is blank Optional1: How to create an account for operator? Click “Add User”, a new screen pop up. Key in the Username, Password.
  • Page 39 Mark the check box on the storage setting to select the storage disk from your PC computer. Mark the checkbox to select “Record Schedule” Mark the checkbox in front of “Enable Record”, Click “Apply” button to Save. NOTE: this is the switch button to turn on/off recording. Return to the live interface, double click camera on the list, CMS5 will start recording from the live.

  • Page 40: Playback The Video On Your Computer

    Playback the video on your computer , Click “Playback” icon In the "Main" , a new screen appear. Select the channel from the camera list in the upper right corner. Select the time period in the lower right corner.
  • Page 41 NOTE: It only can search footage within a single day. Click “Search”. The search result will display as below. Select the footage from the list, click play button , the software will start playing. NOTE: Click“ ” can locate the files in the PC computer. Choose the “Time”...

  • Page 42: Recording Live To Tf Memory Card (Cameras With Microsd Only)

    Recording live to TF memory card (cameras with microSD only) Format TF memory card , Enter “Device Config” and Click “Disk Manager” In the "Main" Select the memory disk from the list NOTE: Only the model with TF memory card slot, and the TF memory card is installed will display memory information.

  • Page 43: Turn On The Tf Memory Card Recording

    Important: All the data will be erased with format operation. NOTE: The TF memory card can not be viewed by windows PC directly. Turn on the TF memory card recording: , Click “Device Config” , Enter “Record Config” In the "Main" Choose “Auto”, Click “OK”...

  • Page 44: Enable Motion Recording

    Enable Motion recording , Click “Device Config” , enter “Video Detect”, a new screen appear. In the "Main" Click the enable to turn on the motion detection. Choose sensitivity level from “Sensitivity”. Important: Over sensitivity could cause much more false alarm. Click the “Region”, Mark the interested area with blue block.

  • Page 45: Enable Network Dis-Connection Recording

    Enable the checkbox next to “Record”, click OK to save. Enable network dis-connection recording. The IP camera can initial on-board recording when the network is dis-connected. , Enter “Device Config” , Click icon “Abnormality” In the "Main" Select “Network Abort” from event list, Mark both “Enable”, Click OK to save.

  • Page 46: Optional: Enable External Alarm Detection Recording

    Optional: Enable External Alarm Detection Recording , Enter “Device Config” , Click icon “Alarm input”, a new screen appear. In the "Main" Click the enable to turn on the external alarm detection. Select the alarm type. NOTE: Normal Open means the alarm device stays OPEN, it generates digital signal to the camera when the status change to closed.

  • Page 47: Playback The Video From Tf Memory Card ( Cameras With Micro Sd Only )

    Playback the video from TF memory card (cameras with microSD only) , Click “Playback” In the "Main" Click “Device” to playback the footage on TF memory card. NOTE: If choose “Local”, The CMS5 will try to search the footage on the PC computer. Check and select the camera you want to playback.
  • Page 48 NOTE: It only can search footage within a single day. Click “Search”. The search result will display as below. Select the footage from the list, click play button , the software will start play. Choose the “Time” over “File” at the left corner, the time frame will appear. Move the mouse to the time frame, time will display in white.

  • Page 49: Download The Video To Your Computer Hard Drive ( Cameras With Micro Sd Only )

    Download the video to your computer hard drive (cameras with microSD only) Click the download icon on the time frame, the software will start download the footage from the front device. NOTE: the icon will change to red flag when download is completed. Click the red flag to view the downloaded file in your PC computer.

  • Page 50: Setup The Ftp Server

    Setup the FTP server: , Enter the “Device Config” , Click icon “Network” In the "Main" Click the “FTP” Mark the check box “Enable”. Fill in the FTP information including server IP, Port, username, password. Click “OK” to save. Important: The FTP upload only will activate when the alarm event is detected, such as motion detection, external alarm detection.

  • Page 51: Enable The On-Board Storage Recording

    Enable the on-board storage recording , Enter “Device Config”, Click “Record Config” In the "Main" Select the auto, make sure the detect is checked. Click OK to save. Enable on Motion detection. , Enter the “Device Config”, Click icon “Video Detect”, enter a new interface. In the "Main"...

  • Page 52: Optional: Enable Ftp Upload With External Alarm Input Detection

    Choose “ON” for FTP, click OK to save. NOTE: The camera will upload the video or snapshot to the FTP server when it catch a motion detection. NOTE: Upload video to FTP requires TF memory card installed. Optional: Enable FTP upload with external alarm input detection. , Enter the “Device Config”, Click icon “alarm input”...

  • Page 53: Email Notification

    Enable the “Record” and “snapshot” Choose “ON” for FTP, click OK to save. NOTE: The alarm input FTP upload requires external alarm devices such as door contact is connected to the camera properly. Email notification Email Notification is popular function in IP camera and NVR. The user can set the email notification thru event such as motion detection, video masking, alarm input, video loss…...

  • Page 54: Enable Snapshot

    Mark checkbox in front of Test. fill in the SMTP server and Port NOTE: Use port 465 for “SSL” connection. Fill in UserName, Password, Sender, Recipient, email Subject: NOTE: The username and sender are full email account, such as abc@gmail.com Click the “Test”.

  • Page 55: Configure Alarm Event For Email Notification

    NOTE: Only IP cameras support email notification with snapshot. The NVR doesn’t support snapshot in the email notification. Configure alarm event for email notification. Motion detection Notification – The camera or NVR will send an email when it detects a alarm event such as motion, external alarm, video loss…...
  • Page 56 The camera or NVR will send an email when it detects camera masking front end. , Enter the “Device Config”, Click icon “Video Detect” In the "Main" Click “Camera Masking” Enable the “snapshot” Turn on “Send email”, Click OK to save. Alarm Input Event The camera or NVR will send an email when it detects digital input from external alarm device such as PIR sensor, door contact, Beam.
  • Page 57 Click the “enable” Enable the “snapshot” Turn on “Send email”, Click OK to save. Storage Device Not Existed Event The IP camera or NVR will send an email when it detects the TF memory card or hard drive accessing failed. , Enter the “Device Config”, Click icon “Abnormality”...

  • Page 58: Other Options

    Click “OK” to save. Other options Video View User can record the current video layout and recall it later. , click icon “Live” In the "Main" Click this icon in down corner to save currect video layout Name current layout, click Save. Click the “View”...

  • Page 59: Video Tour

    Video Tour User can pre-set the video layout and make it displays sequentially. , click icon “Video tour” In the "Main" Click + to program the new video layout. Name the layout, fill in the dwell time between two layout. Click a window to activate that channel.

  • Page 60: Local Alarm

    repeat step 3 until you finish all the binding. Click “Save and continue” to add a new layout. Repeat step 1 until you add all the layout. Return to “Live”, click the tour icon , the CMS5 will start display the layout in sequentially 10.

  • Page 61: Check The Log

    Check the log , click “Log” In the "Main" Click the “Device” to search log storage on the camera. Select the time frame, log type, Device name Click Search, the result will appear. NOTE: Some of the log may requires turn on the “write log” in the Main -> Device Config -> Alarm Config. Setting Camera Parameters , click “Device Config”...
  • Page 62 A new screen appear. Day/night Mode – Select “Color”, the camera will always stay on color. NOTE: If the environment has significant street light at night, the camera can generate nice color night vision with color mode Slow Shutter – Select “None” will erase motion blur, but low down the sensitivity. Wide Dynamic –...
  • Page 63 NOTE: If the camera keep switch around between color and black/white, DNC threshold can improve the performance. 9. Mirror & Flip – Turn the image upside down. It can help deploy the camera from wall mount to ceiling mount. Installing a new Firmware , click icon “Batch Upgrade”...
  • Page 64 Web Browser connection Checking your web browser security level When using the web browser interface, you can install ActiveX controls to connect and view video using Internet Explorer. However, if you cannot download data, such as video and images due to the increased security measure. you should check the security level of your PC so that you are able to interact with the cameras over the web and, if necessary, modify the Active X settings.
  • Page 65 4. Change the ActiveX controls and plug-ins options that are signed or marked as safe to Enable. Change the ActiveX controls and plug-ins options that are unsigned to Prompt or Disable. Click OK. 5. Click Apply in the Internet Options Security tab window. Windows 7 or above users Internet Explorer for Windows 7 or above operating systems have increased security measures to protect your PC from any malicious software being installed.
  • Page 66 5. Clear the “Require server verification (https:) for all sites in this zone box 6. Enter the IP address in the “Add this website to the zone” field. 7. Click Add, and then click Close 8. Click OK in the Internet Options dialog window. Access the camera over internet 1.
  • Page 67 NOTE: Ensure that the Active X controls are enabled. 2. Enter your user name and password. Username: admin Password: (no require) 3. Click Login. The web browser window appears in live view mode.
  • Page 68 All the designs and software here are subject to change without prior written notice.  All trademarks and registered trademarks mentioned are the properties of their respective owners. To contact GOLBONG support, please do one of the following: Visit http://www.golbong.com/contact-us.asp and use the email form or Email GOLBONG Customer Support: support@golbong.com...
  • Page 69 © Copyright GOLBONG 2017...
