  • Page 1 User manual Domestic hot water tank 220 SHL...
  • Page 2 Dear Customer, Thank you very much for buying this appliance. Please read through the manual carefully before using the product, and keep it in a safe place for later reference. In order to ensure continued safe and efficient operation we recommend that the product is serviced regularly. Our service and customer service organisation can assist with this.
  • Page 3: Table Of Contents

    Product fiche - Solar devices ............. 25 300028214 - v06 - 02022017 220 SHL...
  • Page 4: Safety

    Important The user and installation manuals are also availa­ ble on our website. Warning A disconnection device must be fitted to perma­ nent pipes in accordance with installation rules. 220 SHL 300028214 - v06 - 02022017...
  • Page 5: Recommendations

    Never drain the system. Never replace or add wa­ ter or solar fluid to the installation. These actions must be carried out by a qualified technician. Warning Do not modify the control system parameters un­ less fully conversant with them. 300028214 - v06 - 02022017 220 SHL...
  • Page 6: About This Manual

    Our liability as manufacturer may not be invoked in the following cases: Failure to abide by the instructions on installing the appliance. Failure to abide by the instructions on using the appliance. Faulty or insufficient maintenance of the appliance. 220 SHL 300028214 - v06 - 02022017...
  • Page 7: Installer's Liability

    Get your installer to explain your installation to you. Have the required inspections and maintenance carried out by a quali­ fied installer. Keep the instruction manuals in good condition close to the appliance. 300028214 - v06 - 02022017 220 SHL...
  • Page 8: Technical Specifications

    This product conforms to the requirements of European Directive 97/23/EC, article 3, paragraph 3, on pressure equipment. Technical data 3.2.1 Specifications of the DHW tank Tab.1 Unit DHW tank 220 SHL Primary circuit (heating water) Maximum operating °C temperature Maximum operating bar (MPa) 3 (0.3)
  • Page 9 3 Technical specifications Unit DHW tank 220 SHL Back-up volume Solar volume Weight Shipping weight (foam coated tank) Tab.2 Performance linked to gas-fired floor-standing condensing boilers Unit 10/15 kW 15 kW 25 kW 35 kW Power exchanged Hourly flow rate (∆T = 35°C)
  • Page 10: Description Of The Product

    The outside casing is made of painted steel sheeting. The solar control system The thermostatic mixing valve Le préparateur d’eau chaude sanitaire 220 SHL est exclusivement pro­ posé en association avec les chaudières listées ci-dessous, il ne peut pas être utilisé en tant que préparateur indépendant :...
  • Page 11 Heat pump + do­ Package / Refer­ Package / Reference ence mestic hot water ence tank assembly DIETRISOL Modu­ On roof ER430-100019693 220 SHL AGC 15 ER220-100016425 ER316 100017611 lens 220D-2 (1 ER431-100019694 VH / V220SHL 100018125 sensor) AGC 15 VH / 100018127 Roof-integral In­...
  • Page 12 Package / Refer­ Package / Reference ence mestic hot water ence tank assembly DIETRISOL Modu­ On roof ER240-100016502 220 SHL AGC 15 ER220-100016425 ER316 100017611 lens 220-3 (1 sen­ ER245-100016506 VH / V220SHL 100018125 sor — Vertical as­ ER247-100016508 AGC 15 VH /...
  • Page 13 Heat pump + do­ Package / Refer­ Package / Reference ence mestic hot water ence tank assembly DIETRISOL Modu­ On roof ER432-100019695 220 SHL AGC 15 ER220-100016425 ER316 100017611 lens 220D-4 (2 ER433-100019696 VH / V220SHL 100018125 sensors) ER434-100019697 AGC 15 VH /...
  • Page 14 Package / Refer­ Package / Reference ence mestic hot water ence tank assembly DIETRISOL Modu­ On roof ER240-100016502 220 SHL AGC 15 ER220-100016425 ER316 100017611 lens 220-5 (2 sen­ ER245-100016506 VH / V220SHL 100018125 sors - Vertical as­ ER247-100016508 AGC 15 VH /...
  • Page 15 Heat pump + do­ Package / Refer­ Package / Reference ence mestic hot water ence tank assembly PERFECTSUN On roof ER430-100019693 V 220 SHL GVCR ER220-100016425 ER316 100017611 Oenovia 220D-2 (1 ER431-100019694 15 HOR/220SHL 100018232 sensor) GCCR 15 HOR/ 100018234 Roof-integral In­...
  • Page 16 Heat pump + do­ Package / Refer­ Package / Reference ence mestic hot water ence tank assembly PERFECTSUN On roof ER240-100016502 V 220 SHL GVCR ER220-100016425 ER316 100017611 Oenovia 220-3 (1 ER245-100016506 15 HOR/220SHL 100018232 sensor - Horizontal ER247-100016508 GCCR 15 HOR/...
  • Page 17 Heat pump + do­ Package / Refer­ Package / Reference ence mestic hot water ence tank assembly PERFECTSUN On roof ER432-100019695 V 220 SHL GVCR ER220-100016425 ER316 100017611 Oenovia 220D-4 (2 ER433-100019696 15 HOR/220SHL 100018232 sensors) ER434-100019697 GCCR 15 HOR/...
  • Page 18 Heat pump + do­ Package / Refer­ Package / Reference ence mestic hot water ence tank assembly PERFECTSUN On roof ER240-100016502 V 220 SHL GVCR ER220-100016425 ER316 100017611 Oenovia 220-5 (2 ER245-100016506 15 HOR/220SHL 100018232 sensors - Horizon­ ER247-100016508 GCCR 15 HOR/...
  • Page 19: Main Components

    10 Primary solar circuit filling and draining device 11 Primary solar coil sensor 12 Manual venting degasser 13 Primary solar coil 14 Plate exchanger on the primary boiler circuit 15 Domestic hot water circulating pump 16 Drain valve L000225-B 300028214 - v06 - 02022017 220 SHL...
  • Page 20: Operation

    The system is designed in such a way that no special precautions are nec­ essary during long periods of absence in summer. The solar control system protects the installation from overheating. 220 SHL 300028214 - v06 - 02022017...
  • Page 21: Maintenance

    Solar control system The solar control system is governed by the boiler control system. All parameters and settings on the solar control system are managed from the boiler control panel. 300028214 - v06 - 02022017 220 SHL...
  • Page 22: Maintenance Of The Thermostatic Mixer Valve

    6 Maintenance Refer to the boiler's installation and service manual. Maintenance of the thermostatic mixer valve The thermostatic mixer valve does not require any particular maintenance. 220 SHL 300028214 - v06 - 02022017...
  • Page 23: Warranty

    The warranty is only valid for sub-sets such as motors, pumps, electrical valves, etc. if these parts have never been dismantled. 300028214 - v06 - 02022017 220 SHL...
  • Page 24 7 Warranty The rights established in European Directive 99/44/EEC, implemented by legal decree No. 24 of 2 February 2002 and published in Official Journal No. 57 of 8 March 2002, remain in force. 220 SHL 300028214 - v06 - 02022017...
  • Page 25: Appendix

    8.1.4 Product fiche - Solar devices Tab.4 Product fiche for solar devices 220 SHL Solar hot water storage tank - Energy efficiency class Solar hot water storage tank - Standing loss Solar hot water storage tank - Storage volume 0.220...
  • Page 26 8 Appendix 220 SHL 300028214 - v06 - 02022017...
  • Page 27 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical de­ scriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations.
  • Page 28 300028214 - v06 - 02022017 300028214-001-06...
