1 / 2 I N . D R I L L / D R I V E R
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item# 46180

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 46180 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ironton 46180

  • Page 1 1 / 2 I N . D R I L L / D R I V E R OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 46180...

  • Page 2: Specifications

    Thank you very much for choosing an IRONTON product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Electrical Safety

    • Inspect work area for hazards before using tool. • Keep bystanders, children, and visitors away while operating a power tool. Distractions can cause you to lose control. ELECTRICAL SAFETY • Power tool plugs must match the outlet. Never modify the plug in any way. Double insulated tools are equipped with a polarized plug (one blade is wider than the other).
  • Page 4 • Remove any adjusting keys or wrenches before turning the power tool on. A wrench or key that is left attached to a rotating part of the tool may result in personal injury. • Do not overreach. Maintain proper footing and balance at all times. Loss of balance can cause an injury in an unexpected situation.

  • Page 5: Extension Cords

    • Feed the work piece in the correct direction and speed. Feed the work piece into a blade, cutter, or abrasive surface against the direction of the cutting tool’s direction of rotation only. Incorrectly feeding the work piece in the same direction may cause the work piece to be thrown out at high speed.
  • Page 6 Guidelines for Using Extension Cords • If you are using an extension cord outdoors, be sure it is marked with the suffix “W-A” (“W” in Canada) to indicate that it is acceptable for outdoor use. • Be sure your extension cord is properly wired and in good electrical condition. Always replace a damaged extension cord or have it repaired by a qualified person before using it.
  • Page 7 Always check that the material being drilled is secure and clamped in place if • necessary to prevent any movement. An unstable work piece can cause the drill bit to bind, causing of control and injury. Never hold the work piece in your hand, lap or against other parts of the body when •...

  • Page 8: Unpacking And Contents

    FIG 1 KNOWING YOUR DRILL (FIG 1) 1. Chuck 4. Lock-On Button 2. Trigger Switch 5. Auxiliary Handle 3. Reserving Switch 6. Power-On Indicator UNPACKING AND CONTENTS IMPORTANT: Due to modern mass production techniques, it is unlikely the tool is faulty or that a part is missing.
  • Page 9 ASSEMBLY WARNING: Always be sure that the tool is switched off and unplugged before adjusting, adding accessories, or checking a function on the tool. INSTALLING AUXILIARY HANDLE The auxiliary handle can be attached to the electric drill in two different positions: left and right.
  • Page 10 CHUCK WARNING: Always be sure that the tool is switched off and unplugged before adjusting, adding accessories, or checking a function on the tool. The drill is equipped with a 1/2" (13mm) metal Keyed Chuck (1-FIG 1). A chuck key is provided to tighten or loosen the chuck jaws.
  • Page 11 DRILLING IN WOOD, COMPOSITE MATERIALS AND PLASTICS Although most “twist” drill bits are designed for drilling into metal, they are the most common bit used for boring holes in wood, wood composites and plastics. There are many types of drill bits available that may be more appropriate or designed specifically for boring the type of hole you desire.
  • Page 12 bit. Too little pressure keeps the bit from cutting, dulling the bit edges due to excessive friction. • If drilling large holes, first drill a smaller hole, and then enlarge it to the desired size. • Using lubricants such as oil on the point will help cool the bit, increase drilling action and extend drill bit life.
  • Page 13 DIAGRAM AND PARTS LIST Page of 15...
  • Page 14 Part # Description Part # Description Screw M5*22 Screw st4.2*60 Chuck 13mm Stator (120V) Output spindle Aluminum sleeve Key 3*3.7*10 Name plate Circlip for flange 32 Housing Bearing 6002 Right name plate holder Screw st4.2*35 Screw st4.2*10 Screw st4.2*55 Rear Handle, Right half Head shell Screw st4.2*16 Circlip for shaft 15...

  • Page 15: Two Year Warranty

    TWO-YEAR WARRANTY This product is warranted free from defects in material and workmanship for 2 years after date of purchase. This limited warranty does not cover normal wear and tear or damage from neglect or accident. The original purchaser is covered by this warranty and it is not transferable. Prior to returning your tool to store location of purchase, please call our Toll-Free Help Line for possible solutions.
