- Page 1 KD319RI ADSL Router User Manual FOUR-PORT ADSL ROUTER KASDA Digital Technology Co. Ltd www.kasda.cn...
- Page 2 ADSL ROUTER USER MANUAL NOTICE This document contains proprietary information protected by copyright, and this Manual and all the accompanying hardware, software, and documentation are copyrighted. All rights are reserved. No part of this document may be photocopied or reproduced by mechanical, electronic, or other means in any form.
-
Page 3: Table Of Contents
Content OVERVIEW ..........................1 ..........................1 EATURES ........................3 ACKET ONTENTS ......................3 YSTEM EQUIREMENTS ........................3 ACTORY EFAULTS ......................4 ARNINGS AND AUTIONS 2 HARDWARE DESCRIPTION ....................... 5 Front Panel ............................5 Rear Panel ............................6 3 HARDWARE INSTALLATION ..................... 7 4 PC CONFIGURATION GUIDE ..................... -
Page 4: Overview
ADSL ROUTER USER MANUAL 1 Overview Thank you for using this Asymmetric Digital Subscriber Line (ADSL) router. With the asymmetric technology, this device runs over standard copper phone lines. In addition, ADSL allows you to have both voice and data services in use simultaneously all over one phone line. - Page 5 ADSL ROUTER USER MANUAL 1.1.3 Operating System Support WINDOWS 98 WINDOWS 98 SE WINDOWS ME WINDOWS 2000 WINDOWS XP WINDOWS VISTA WINDOWS 7 Macintosh LINUX 1.1.4 ATM Capabilities ATM Connection ...
-
Page 6: Packet Contents
ADSL ROUTER USER MANUAL Packet Contents The packet contents are as the following: ADSL Router External Splitter Power Adapter Telephone Line Ethernet Cable System Requirements Before using this ADSL router, verify that you meet the following requirements: ... -
Page 7: Warnings And Cautions
ADSL ROUTER USER MANUAL Warnings and Cautions Never install telephone wiring during storm. Avoid using a telephone during an electrical storm. There might be a risk of electric shock from lightening. Do not install telephone jacks in wet locations and never use the product near water. -
Page 8: Hardware Description
ADSL ROUTER USER MANUAL 2 Hardware Description Front Panel Color Function ON:Power is on Green OFF:Power is off On: LAN link established and active Green Blinking: Data activity occurs Off: No LAN link On: DSL link established and active Green Quick Blinking: DSL is trying to establish a connection Slow Blinking: No DSL link On: IP connected... -
Page 9: Rear Panel
ADSL ROUTER USER MANUAL Rear Panel Port Function Connects the device to an ADSL telephone jack or splitter using a RJ-11 telephone cable Reset System reset or reset to factory defaults. Connects the device to your PC's Ethernet port, or to the uplink port on your hub/switch, using a RJ-45 cable Switches the unit on and off POWER... -
Page 10: Hardware Installation
ADSL ROUTER USER MANUAL 3 Hardware Installation This Hardware Installation describes how to connect ADSL router to your computer, LAN and the Internet. This Installation assumes you have subscribed to an ISP for ADSL service and only covers the basic configurations to be applied to residential or corporate networks. -
Page 11: Pc Configuration Guide
ADSL ROUTER USER MANUAL 4 PC Configuration Guide Local PC Configuration 4.1.1 Windows 95, 98, ME, XP In the Windows task bar, click the “Start” button, point to “Settings”, and then click “Control Panel”. Double-click the “Network” icon. On the “Configuration” tab, select the TCP/IP network associated with your network card and then click “Properties”. - Page 12 ADSL ROUTER USER MANUAL 4.1.3 Windows Vista 1. Go to Start. Click on Network. 2. Then click on Network and Sharing Center at the top bar. 3. When the Network and Sharing Center window pops up, select and click on Manage network connections on the left window column.
-
Page 13: Access The Program
ADSL ROUTER USER MANUAL Access the program After configuring the IP Address of you computer, powering on the ADSL Router, and launching a web browser, such as Internet Explorer, use http://192.168.1.1/ to log on to the setting pages. Enter username ‘admin’ and password ‘admin’... -
Page 14: Pppoe(Ppp Over Ethernet)
ADSL ROUTER USER MANUAL 4.3.1 PPPoE(PPP over Ethernet) PPPoE (Point to Point Protocol over Ethernet) provides access control and billing functionality in a manner similar to dial-up services using PPP. The router bridges a PPP session over Ethernet (PPP over Ethernet, RFC2516) from your computer to an ATM PVC (Permanent Virtual Circuit) which connects to ADSL Access Concentrator where the PPP session terminates. - Page 15 ADSL ROUTER USER MANUAL Item Description VPI/VCI Enter the PVC that your ISP gives you. NAPT extends the notion of NAT one step further by also translating the transport identifier (eg TCP and UDP port numbers, Enable NAPT ICMP query identifiers). This allows the transport identifiers of a number of private hosts to be multiplexed into the transport identifiers of a single public IP address.
-
Page 16: Pppoa(Ppp Over Atm)
ADSL ROUTER USER MANUAL 4.3.2 PPPoA(PPP over ATM) PPPoA stands for Point to Point Protocol over ATM Adaptation Layer 5 (AAL5). A PPPoA connection functions like a dial-up Internet connection. The router encapsulates the PPP session based on RFC1483 and sends it through an ATM PVC (Permanent Virtual Circuit) to the Internet Service Provider’s (ISP) DSLAM (digital access multiplexer). - Page 17 ADSL ROUTER USER MANUAL Item Description VPI/VCI Enter the PVC that your ISP gives you. NAPT extends the notion of NAT one step further by also translating the transport identifier (eg TCP and UDP port numbers, Enable NAPT ICMP query identifiers). This allows the transport identifiers of a number of private hosts to be multiplexed into the transport identifiers of a single public IP address.
-
Page 18: Bridged
ADSL ROUTER USER MANUAL 4.3.3 Bridged With bridging the router has a static IP address for connection. The router passes traffic through to another device (a computer or router for example) that handles authenticating with the ISP. Enter VPI and VCI according to your local region and select the appropriate Encapsulation mode. -
Page 19: Lan Interface
ADSL ROUTER USER MANUAL 4.3.4 LAN Interface From LAN, Configure the DSL Router’s IP Address and Subnet Mask for LAN interface. Item Description This is the IP address that other devices on your local network will IP address use to connect to the modem. The default is 192.168.1.1. Subnet mask This defines the size of your network. - Page 20 ADSL ROUTER USER MANUAL address of your device in dotted decimal notation, for example, 10.0.0.1. Type the subnet mask. IGMP Snooping is a method that actually “snoops” or inspects IGMP traffic on a switch. When enabled, the switch will watch for IGMP snooping IGMP messages passed between a host and a router, and will add the necessary ports to its multicast table, ensuring that only the...
-
Page 21: Tr069
ADSL ROUTER USER MANUAL 4.3.5 TR069 WAN Management Protocol (TR-069) allows a Auto-Configuration Server (ACS) to perform auto-configuration, provision, collection, and diagnostics to this device. Select Configure TR-069 from AdvancedCWMP. URL: URL for the CPE to connect to the ACS using the CPE WAN Management Protocol. -
Page 22: Reset Router
ADSL ROUTER USER MANUAL Reset Router On the Rear Panel of the ADSL router you will find a small hole with the word "reset" written below it. It's just big enough for a ball-point tip. Insert a ball-point tip into this little hole (actually it's a reset switch) and keep the ball-point tip in there. You can release the ball-point after about 5 seconds. -
Page 23: Appendix Frequent Asked Questions
ADSL ROUTER USER MANUAL Appendix Frequent Asked Questions Q: None of the LEDs are on when you power on the ADSL router? A: Please make sure what you use is the power adaptor attached with the ADSL router package，and check the connection between the AC power and ADSL router. Q: DSL LED does not turn on after connect telephone line? A: Please make sure what you use is the standard telephone line (as attached with the package), make sure the line is connected correctly and check whether there is... - Page 24 ADSL ROUTER USER MANUAL Q: Initialization of the PVC connection failed? A: Be sure that cable is connected properly from the DSL port to the wall jack. The DSL LED on the front panel of the ADSL router should be on. Check that your VPI, VCI, type of encapsulation and type of multiplexing setting are the same as what you collected from your service provider, Re-configure ADSL router and reboot it.
