SUMMARY Introduction Safety instructions Conditions of use Presentation and features Dimensions Description Installation instructions DMX512 connection Control Panel VersaPix-RS control panel menu - Option details Master/Slave Mode settings DMX Chart Error Messages Care and maintenance Technical Specifications Warranty USER MANUAL...
Please take the time to read this manual carefully and thoroughly before At first use, your VERSAPIX-RS may give off an odor. This is a normal installing and operating the luminaire. You should have a good knowledge occurrence that should dissipate after a few minutes of operation.
Do not shake the VERSAPIX-RS while installing or handling. If your VERSAPIX-RS is not being used for a long period, you should Do not pull the VERSAPIX-RS by one of its cables to move it. Lift the disconnect the luminaire from the power source.
INSTALLATION INSTRUCTIONS The VERSAPIX-RS consists of a metal frame and plastic covers. The power connectors and DMX512 signal connectors are on the back of the fixture’s base. During installation please observe the instructions according to GB7000.15 / EN60598-2-17 standards and other national standards applicable.
DMX address 30 (29 + 1), the third with DMX address 59 connectors. (29 + 30), etc . Refer to the following diagram when connecting the VERSAPIX-RS luminaires in a daisy chain: CONTROL PANEL (MENU OPTIONS) A large number of settings are accessible from the fixture’s control panel.
Access the menu by pressing the “Mode Esc” key. w Go to the “ADDRESS” menu and press “Enter”, then find “Set DMX TABLE 1: VERSAPIX-RS MENU FUNCTIONS AND OPTIONS Address.” w Use the up/down arrows to scroll through until you locate the desired address and press “Enter”...
Page 9
Finally, use the left/right arrow keys to select “RDM PID.” w Use the left/right arrow keys to select the unit of measurement. Press w Use the up/down arrow keys to change the value and left/right to move “Enter” to confirm. from one number to the next.
DMX controller. Set the desired number of scenes from the control panel. Then run the scenes from your controller. They will CLR LAST RUN be automatically transmitted to the VERSAPIX-RS. After entering the “Timer PIN”, you can reset the value for “Last Run Hrs” through this menu.
Part 2: Use the buttons to select “Slave 1”, “Slave 2” or “Slave 3.” Press ENTER to confirm. Press MODE/ESC to return to the main menu. Scene 8 cene 9 cene 10 Scene 8 Automatic Program Run Part 3: Use the buttons to select “Function Mode.” Press ENTER to confirm.
Cyan ERROR MESSAGES 50-54 Salmon 55-59 Turquoise When you turn on the VERSAPIX-RS, it will first perform an automatic reset. 60-64 Light Green The display may show “Err channel is XX” indicating there is a problem 65-69 Steel Blue with one or more of the channels. “XX” represents channel 1, 2, 3, 4, 5...
CARE AND MAINTENANCE TECHNICAL SPECIFICATIONS OPTICAL The care and maintenance of your VERSAPIX-RS should be ensured • Optical efficiency: 85% maximum by a qualified technician. Your VERSAPIX-RS requires regular servicing. • Opening angle of the beam: 4.5° The frequency depends essentially on its operating conditions and environment.
• Product: 676 mm x 300 mm x 341 mm (L x H x D) Any modification to the fixture will void the warranty. AYRTON cannot under • Protective foam: 750 mm x 325 mm x 220 mm (L x H x D) any circumstances be held liable for quality and conformity regarding the installation of this product, which is the responsibility of the installer.
