Summary of Contents for SWIT S-1093H
- Page 1 SWIT Electronics Co., Ltd. Model: S-1093H 9” Full HD Broadcast LCD Monitor User Manual Ver：A.2 Please read this User Manual throughout before using.
-
Page 2: Preface
2. All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks in this user manual are the property of their respective owners. 3. Due to constant effort of product development, SWIT reserves the right to make changes and improvements to the product described in this manual without prior notice. -
Page 3: Maintenance
Maintenance Warning 1. In order to reduce the risk of fire and electrical shock, do not lay this product in rain or damp places. 2. Please keep away from the strong magnetic field; it may cause the noise of the video and audio signals. -
Page 4: Table Of Contents
( V-mount, Gold mount or DV battery plate) Introduction S-1093H adopts IPS LCD panel, with resolution 1920×1200 and wide viewing angle H170°⁄ V170°. It supports 2 x 3GSDI（Level A/B）, 1 x HDMI, 1 x CVBS and 1 x analog audio input. It also supports 2 x 3GSDI, 1 x HDMI, 1 x CVBS and 1 x analog audio loop through output. -
Page 5: Installation Dimension
Installation Dimension The main body (in mm) -
Page 6: Operation Instructions
Operation Instructions ·Front Panel ⑴Speaker: For SDI/HDMI embedded audio and analog audio monitoring. (Will not work if earphone is plugged in) ⑵ Button SOURCE: Press “SOURCE” to select SDI1, SDI2, HDMI, and CVBS signal input. F1～F5: User definable function keys. Please see details in “4. Function key” under “Main Menu”. AUDIOBAR: Press “AUDIOBAR”... -
Page 7: Osd
·OSD ⑴ Time code（SDI） Under SDI input, it can display Time code. If no Time code information is detected, it will be displayed as “TC: UNLOCKED”. User can set function keys F1～F5 or GPI pins as “Time code” to turn on or off this function. ⑵... - Page 8 Introduction of audio and video functions 2-ch embedded audio meters Under 3G/HD/SD SDI, HDMI and CVBS, it displays 2 channels embedded audio meters. The audio meter is green, and will turn yellow when audio exceeds -20dB, and turn red when audio exceeds -9dB.
-
Page 9: Back Panel
⑵ DC 12V IN: Connect with DC12V 4-pin XLR power adapter, support 6.5V-24V voltage input (Pin 1: Negative, Pin 4: Positive) ⑶ Battery mount connector Connect with SWIT S-7004 series quick release battery plate, and then mount corresponding V-mount or DV batteries. See details in “Optional Battery Plate”. ⑷ Audio Socket AUDIO IN: 3.5mm analog audio input (CVBS) -
Page 10: Main Menu
Main Menu S-1093H has OSD to adjust the parameters and settings, for example: Picture, color temp., function keys, etc. Press “MENU/ENTER” button, the main menu will popup from the left top of the screen. The selected main menu highlights in yellow. - Page 11 Submenu introduction（the default values are marked with underline ） 1. Exit & Status Displays the current status, the details are as down below: *1 Display the current video signal and format *2 Display the current function keys setup 2. Picture To adjust picture parameters.
- Page 12 4. Function key To define the F1～F5 function keys. *1 Function keys F1-F5 can be setted as the down below functions: Time code, Zebra, Audio Bar, false Color, AFD, H/V Delay, R/G/B/Mono, Marker , Color Bar, UMD, Audio Alarm, Focus Assist , Aspect Ratio, Scan Mode, Zoom Mode, Mute, Freeze Frame, Image Flip, CVBS,HDMI, SDI1,SDI2, color temp.
- Page 13 ID will be displayed on top or bottom of the screen. UMD setup: ⑴ Connect the external control equipment with S-1093H; ⑵ Set “Display Type” to “UMD” under UMD submenu; ⑶Make sure the “address”, “Baud Rate”, “Parity” the same;...
- Page 14 Aspect ratio: 4:3 Aspect ratio: 4:3 Safety Area: 85% Safety Area: 85% Center Marker: On Center Marker: Off Fit Marker: Off Fit Marker: On 8. Audio *1 When “Bar Frame” is set to “Off”, only the audio meter will be displayed. When “Bar Frame”...
- Page 15 When set to “Off”, source scan will not be supported. *2 Logo When powered on, the screen will display SWIT logo. *3、*4 Update Driver/ Kernel ⑴ Power the monitor, insert the USB equipment with update software into the USB socket.
-
Page 16: Optional Battery Plate
User can set “Key Inhibit” under “key Inhibit” submenu to “Off” to recover the functions of all buttons. Optional Battery Plate 1. Battery Mount choice S-1093H monitor can use V-mount, Gold mount and various DV batteries by connecting with SWIT S-7004 series battery plates. There’re following types of S-7004 for choice: Model Compatible battery type... - Page 17 2. Installation of S-7004F/D/J/C/U/E/B/V/I snap-on type DV battery plate: S-7004F/D/J/C/U/E/B/V/I DV plate is snap-on type, quick release and interchangeable. Please follow the instructions to install: (1) Please make sure the power terminals are clean and in well condition before use. (2) Align the S-7004 DV plates slots to the bolts of the monitor rear panel, and press tightly in.
-
Page 18: Specification
Specification LCD Performance Size 9inch Display area 191.5×119.7 mm Resolution 1920×RGB×1200 Color 8 bit Aspect ratio 16:9∕4:3 Brightness 450 cd∕㎡ Contrast 1000:1 Viewing Angle Horizontal: 170°Vertical: 170° Input/output BNC×2 3G/HD/SD-SDI ×2 BNC×1 CVBS input HDMI×1 HDMI input Inpu GPI×1 UMD, GPI×1 USB×1 3.5mm×1 analog audio input... -
Page 19: Trouble-Shooting
Trouble-shooting Symptom Possible Causes Solution Please check if the power is connected, and then The power is not turned on press ”POWER” button to turn on the monitor Unstable power voltage Reconnect to power supply BNC or HDMI cable loose No display Check and correctly connect the contact or not correctly...
