Summary of Contents for Breville VIN143

  • Page 2: Product Safety

    product safety Please read these instructions before operating the appliance and retain them for future use. This product is not suitable for use by children, and may not be suitable for persons requiring supervision unless they receive instruction by a competent person on how to safely use the product.
  • Page 3 features q we r Water tank inlet cover Heel rest Steam control Cord wrap Shot of steam button Stainless steel soleplate Spray button Pointer Temperature selector Water level maximum indicator Indicator light Water tank Flexible cord protector Spray nozzle Due to our policy of continuous improvement, the actual product may differ slightly from the one illustrated in these instructions.

  • Page 4: Before First Use

    before first use Remove all packaging including any soleplate protection before using your iron. Wipe over the soleplate with a cloth moistened with methylated spirit. Wipe off the methylated spirit with a damp cloth then dry the soleplate thoroughly. Fill the water tank and then empty it. This will rinse out any foreign particles remaining in the water tank from the manufacturing process.
  • Page 5 filling your iron Never add fabric conditioner, starches or any other chemicals to the water in your iron. Ensure your iron is switched off and unplugged from the mains supply socket. Set the steam control to the no steam position (0). Open the water tank inlet cover.
  • Page 6 using your iron We recommend that you: • Start by ironing those items of laundry that require the lowest temperature (e.g. synthetics). Finish by ironing fabrics which respond best to higher temperatures and steam—such as cotton and linen. • If you iron a fabric made of a blend of fibres set the temperature of your iron to the most delicate fibre.

  • Page 7: Ironing Without Steam

    using your iron Ironing without steam If you intend to dry-iron fabrics there is no need to fill the water tank. However, if water is already in the water tank, you don’t need to empty it. Set the steam control to the no steam position (0). Plug your iron into the mains supply and switch on.
  • Page 8 using your iron Vertical steam ironing Never iron garments when they are being worn. Your iron can be used for vertical steam ironing curtains, dresses on hangers etc. Fill your iron with water. Plug your iron into the mains supply and switch on. Set the temperature control dial to the setting.

  • Page 9: Care And Cleaning

    care and cleaning Do not use harsh abrasives, chemical cleaners or solvents to clean the exterior of your iron because they will damage the surface. Cleaning the soleplate of your Iron After each use, allow your iron to completely cool down before wiping the soleplate with a soft damp cloth.
  • Page 10 storing Storing your iron • Set the steam control to the no steam position (0). • Switch the mains supply socket off and remove the plug. • When the soleplate has cooled, empty the remaining water from the tank. • Always store your iron on its heel rest.

  • Page 11: Connection To The Mains Supply

    connection to the mains supply This appliance must be earthed. This appliance is fitted with either a moulded or rewirable BS1363, 13 amp plug. The fuse should be rated at 13 amps and be ASTA approved to BS1362. If the fuse in a moulded plug needs to be changed, the fuse cover must be refitted. The appliance must not be used without the fuse cover fitted.

  • Page 12: After Sales Service

    after sales service These appliances are built to the very highest of standards. There are no user serviceable parts. Follow these steps if the unit fails to operate: Check the instructions have been followed correctly. Check that the fuse has not blown. Check that the mains supply is functional.
  • Page 13 guarantee This product is guaranteed for a period of 1 year from the date of purchase against mechanical and electrical defects. This guarantee is only valid if the appliance is used solely for domestic purposes in accordance with the instructions provided, that it is not connected to an unsuitable electricity supply, dismantled or interfered with in any way or damaged through misuse.
  • Page 16 VIN143_Iss_2 12/09 92977-1...
