Summary of Contents for Kodak i5000 Series

  • Page 2: Table Of Contents

    Using the ISIS Driver Contents Starting the SVT Diagnostics/Scan Validation Tool ......2 The Scan Validation Tool dialog box ..........4 Configuring Image settings ..............6 Main tab..................8 Layout tab..................11 Scan Area dialog box ..............12 Image Processing tab..............14 Auto Color Detect tab ..............

  • Page 3: Starting The Svt Diagnostics/Scan Validation Tool

    Diagnostics. Diagnostics/Scan Validation Tool 2. Select ISIS for the Driver Type and the KODAK i5200 (i5600, i5800, i5850) as the driver and click OK. 3. Click the one of the Image Display mode buttons to enable the image preview panels.
  • Page 4 5. Click ISIS. The Preset Configurations dialog box will be displayed. This dialog box maintains a list of saved driver settings. You can save, delete or import a preset; or select a preset that is already set up or one you want to modify. 6.

  • Page 5: The Scan Validation Tool Dialog Box

    The Scan Validation The Scan Validation Tool (SVT) is a diagnostic application provided by Kodak. The SVT user interface allows access to all the features of the Tool dialog box scanner and is a good way to verify that the scanner is working properly.
  • Page 6 Save Images to Files — when selected, will save the images to the specified directory. Display Every ⎯ enter the sampling rate of the images you want to display while scanning. For example, to see every image, enter a value of 1.

  • Page 7: Configuring Image Settings

    Options include: Front Image #1, Front Image #2, Back Image #1 and Back Image #2. The Kodak Scanner drivers allow you to control the camera settings independently. Some settings apply only to black and white images, others apply to color/grayscale images.
  • Page 8 • Mode — select one of the following modes: - Black and White: if you want your electronic image to represent all elements of your document in black and white. - Grayscale: if you want your electronic image to have a range of varying shades of gray from black to white.

  • Page 9: Main Tab

    Main tab The Main tab provides the following options: Dots per inch (dpi) or resolution ⎯ indicates the scanning resolution, which largely determines the quality of the scanned image. The greater the resolution, the better the reproduction. However, scanning at a higher resolution also increases scanning time and file size.
  • Page 10 Control). For challenging documents the grayscale version of the document is produced, allowing you final control over image quality within your application software. NOTE: This option is only available with Kodak Capture Pro Software. Refer to the software’s documentation for more information.
  • Page 11 Threshold (Brightness) — this option is available when you select Fixed Processing or Adaptive Thresholding (ATP). This option allows you to change the black and white image to be darker or lighter. The higher the threshold value, the darker the image. Use the slider to select a value from 0 to 255.

  • Page 12: Layout Tab

    Layout tab The Layout tab provides the following options: Page Size ⎯ the default page size is set when a scanner is first selected. You can choose a different page size using the drop-down list. Page size should be set to the Scanner’s maximum when using the Automatic, Aggressive or Photo cropping option.

  • Page 13: Scan Area Dialog Box

    Page Orientation — allows you to select the way you place your documents in the scanner, Top edge first, Bottom edge first, Left edge first or Right edge first. Scan Area — displays the Scan Area dialog box. The Scan Area options are only available for images when the cropping option is Fixed to Transport or Relative to Document.
  • Page 14 NOTE: The Scan Area dialog box is only available when Fixed to Transport or Relative to Document is selected on the Main tab. Page Size ⎯ the default paper size is set when a scanner is first selected. You can choose a different paper size using the drop-down list.

  • Page 15: Image Processing Tab

    Image Processing tab The Image Processing tab provides the following options: General Options • Deskew ⎯ automatically straightens a document within ±0.3 degrees of the leading edge of the document. Deskew can detect up to a 45-degree skew and correct up to a 24-degree angle at 200 dpi or a 10-degree skew angle at 300 dpi.
  • Page 16 Hole Fill — allows you to fill in the holes that are around the edges of your document. The types of holes that are filled include: round, rectangular, and irregularly shaped (e.g., double-punched or those having a slight tear that could have occurred when the document was removed from a binder).

  • Page 17: Auto Color Detect Tab

    Auto Color Detect tab The Auto Color Detect tab provides the following options: Color Content • Off: this is the default. No color content will be detected. • Low: documents requiring only a small amount of color to be saved as color or grayscale images.
  • Page 18 • Custom: allows you to manually adjust the Color Amount and/or Color Threshold. NOTE: When setting Auto Color Detect values, it is suggested that you start with the Medium option and scan a typical job set. If too many documents were returned as color/grayscale vs. black and white, then change to the High option and re-run the job.

  • Page 19: Dropout Tab

    Dropout tab The Dropout tab provides the following options: Color Dropout — used to eliminate a form's background so that only the entered data is included in the electronic image (i.e., remove the form’s lines and boxes). For black and white images, these settings effect the grayscale version of the document which the scanner analyzes to produce that electronic image.
  • Page 20 The following is a list of colors which may be used with the red, green and blue dropout options. RGB Electronic Color Dropout for i5000 Series Scanners, Firmware V3.09.01 Red Dropout 144U...
  • Page 21 Green Dropout 106U 107U 108U 109U 113U 114U 115U 120U 121U 122U 1205U 1215U 127U 134U 135U 1345U 148U 317U 3245U 331U 332U 333U 337U 3375U 3385U 3395U 344U 345U 351U 352U 353U 358U 359U 360U 365U 366U 367U 368U 372U 373U 374U...

  • Page 22: Adjustments Tab

    Adjustments tab The Adjustments tab provides the following options: Brightness and Contrast • None • Automatic: automatically adjusts each image. • Manual: allows you to set specific values that will be used for all images. - Brightness — changes the amount of white in the color or grayscale image.

  • Page 23: Background Tab

    Background tab The Background tab provide the following options: Background Smoothing — using this option for documents or forms with a background color will help produce images with a more uniform background color. • None: no background smoothing will be performed. •...

  • Page 24: Image Edge Fill Tab

    Image Edge Fill tab The Image Edge Fill tab provides the following options: Image Edge Fill — fills the edges of the final electronic image by covering the area with the specified color. • Fill Color: - None - Automatic: the scanner will automatically fill the edges of the image using the surrounding color.

  • Page 25: Blank Image Detection Tab

    Blank Image Detection tab The Blank Image Detection tab provides the following options:. Blank Image Detection — allows you to configure the scanner to not give blank images to the scanning application. Select the image size (KB), below which an image is determined to be blank. Images with sizes less than the number you select will not be created.

  • Page 26: About Tab

    Learn Content — allows the scanner to determine the content amount based on the documents to be scanned. Click Learn to use this function. NOTE: Learn mode cannot be applied to both the front and back sides simultaneously. You must select the side you want to configure. About tab The About tab displays information about your scanner and driver.

  • Page 27: Configuring Scanner Settings

    Configuring Scanner To access scanner settings from the ISIS Driver, go into the Scan Validation tool as described earlier in this guide and access the ISIS settings driver. • Click Scanner to configure settings associated with the scanner. The following sections provide descriptions and procedures for configuring Scanner settings.

  • Page 28: Scanner Tab

    Scanner tab The Scanner tab provides the following options: Document Feeder Paper Source — ADF (automatic document feeder). All documents will be scanned from the input elevator. Feeder Position — select one of the following input elevator positions: • Normal: the input elevator is the highest position. This position is recommended when you are scanning 25 sheets or less from the input elevator.
  • Page 29 Sheet Counter — enter the number to be assigned to the next physical sheet of paper entering the scanner. This is incremented sequentially by the scanner and is returned in the image header. Timeout — allows you to set the amount of time the scanner will wait after the last document enters the transport before the transport timeout action is taken.
  • Page 30 • Improved Stacking: aids in controlling how the documents are stacked/ordered in the output tray for mixed document sets. This should work for the majority of mixed sets. Possible slight reduction in throughput Controlled stacking On Minimum gap between documents •...
  • Page 31 • The Maximum Length will always range from 2.5 to 180 inches but the true maximum length of the scan will depend on the bit depth (color/grayscale/black and white and the resolution used for the scan). Black and white 200 dpi will be 180 inches, but color 600 dpi will be much less.

  • Page 32: Multifeed Detection Tab

    Multifeed Detection tab Multifeed detection aids in document processing by detecting documents that may go through the feeder overlapped. Multifeed can happen due to stapled documents, adhesives on documents or electrostatically charged documents. The Multifeed Detection tab provides the following options: Ultrasonic Detection —...
  • Page 33 Sensors — five sensors cover the width of the paper path. In order for multifed documents to be detected correctly, they must pass under one of these sensors. • Left through Right: these controls allow you to select which of the five sensor(s) you want to have turned on.
  • Page 34 • Pause Scanning: scanning will stop but the scanning application will be waiting for additional images (i.e., stops the feeder). Scanning may be resumed by pressing the Start/Resume button on the scanner. Scanning may be stopped by pressing the Stop/Pause. This option allows you to inspect a preview image of the scanned page and choose to Accept the scanned image or Rescan the page and discard the image from the scan that triggered a multifeed alarm.
  • Page 35 Accepting the images: if you want to accept the image, touch Accept on the Operator Control Panel or press the Start/Resume button on the scanner. When Accept is selected, the images shown in the scanner’s preview will immediately be sent to the scanning application and scanning will continue.

  • Page 36: Imprinter Tab

    Imprinter tab The Enhanced Printer operates at full scanner speed. The printer can add a date, time, document sequential counter, and custom messages. This tab will only be present if the optional Enhanced Printer Accessory has been purchased and installed in the scanner. The print string can be configured to include both literal (static) information (e.g., information that stays the same for each document, such as batch name or operator) and dynamic information (i.e.,...
  • Page 37 Format Template — the format template is used to build the print string. The print string is what is printed on documents as they pass through the transport. If using the front printer, the print string is printed before the document is scanned, therefore, it is part of the image. If using the rear printer (i5850 Scanner), the documents are printed after scanning, therefore, the printing will not be on the image.
  • Page 38 Units — select Inches, Centimeters or Pixels. • Font — you can select what orientation you want your information to be printed: Normal, Large and Bold. Normal: 90° rotation Large: 90° rotation Bold: 90° rotation - Rotation — while the characters are printed vertically (starting at the lead edge of the document) this allows you to select the orientation of the print string.

  • Page 39: Image Address Tab (I5850 Scanner Only)

    The scanner will increment the indexes based on how you set up the selections on this tab. The Kodak i5850 Scanner has an option that was previously not available with scanners having image address capability. The i5850 Scanner allows the scanner driver to control whether the scanner has Indexing enabled or not.
  • Page 40 Format String — this text field allows you to structure your image address. The format string in the sample screen above represents a fixed field value of address and a 3 level image address. Image Address — displays the starting image address. The values in this field reflect information from the Format String area and the Start Value field in the Counters area.

  • Page 41: Patch/Batch Tab

    Patch/Batch tab The Batch/Patch tab provides batch and patch functionality. Batching is the operation of counting pages or documents. The Patch tab provides choices of what patch type to recognize. One or more patches can be selected at a time Batch Control On —...
  • Page 42 Patch Detection On — turns patch detection on and makes the rest of the options for Patch Detection available. Image Address Patch Codes — these patch types are used for image addressing. When the Patch Reader detects a patch, it automatically assigns a new image address to the new document.
  • Page 43 Feature Patch Codes — these patch types can be used by the host for post-scan image control (they are not used for image addressing). For example, use these patch types for changing between black and white and color/grayscale imaging or workflow control. Feature Patch Type 1 (Do not use these patches for production - they are not to spec)

  • Page 44: Stacking Tab

    Stacking tab The Stacking tab allows you to set options for separating documents into the two stacks of the Kodak Controlled Stacking Accessory output tray. NOTE: The Stacking tab is only available when the Kodak Controlled Dual Stacking Accessory has been enabled for your scanner.
  • Page 45 Detect Based On • Patch Type — allows you to select which patch sheets, if any, to separate from the document set and place in the selected stack. Options are any combination of: T, 1, 2, 3, 4 and Toggle and 6. It is recommended that the patch sheets go into Stack #2.

  • Page 46: Recommended Configurations For Using The Stacking Option

    Recommended Following are some examples of how to use the Stacking option. configurations for using Short document out-sorting the Stacking option Short document Long documents If your goal is to sort checks or short documents from your other documents, configure the Stacking settings as follows: Stack to put detected documents in: 1 (Stack #1)
  • Page 47 Patch code document separator out-sorting Non-patch documents Patch documents If your goal is to sort document separator sheets with patch codes (or color toggle patch sheets) from your other documents, configure the Stacking settings as follows: Stack to put detected documents in: 2 (Stack #2) and set the Detect Based On: Patch Type option to one or more patch...
  • Page 48 Selected document out-sorting Non-patch documents Patch documents If your goal is to out-sort a selected document(s) from the stack (e.g., invoices that are over a $10,000), configure the Stacking settings as follows: Stack to put detected documents in: 2 (Stack #2) and set the Detect Based On: Patch Type option to one or more patch types.
  • Page 49 Multifeed alarm document out-sorting If your goal is to sort documents that have triggered a multifeed alarm, configure the Stacking settings as follows: Stack to put detected documents in: 2 (Stack #2) and set the Detect Based On: Multifeed option. Triggering exception stacking by multifeed can provide additional functionality.

  • Page 50: Logs Tab

    Logs tab The Logs tab provides a listing of any errors that have been encountered. You can view the Operator and Meter logs and save this information to a file by clicking the Save icon, or copy the information to the clipboard which can then be pasted into a document.
