9-9 Lamp Socket

Function
The lamp socket connect cover lamp assembly to lamp.
The lamp socket fix lamp and unite lamp and cover lamp assembly.
The lamp socket supply electric source to lamp also.
How to
Measure
Check the resistance between connector of housing and connector of lamp socket. It means
check whether or not applying an electric current.
If there is resistance it means the lamp socket is good.
Standard
(1) to (2) and (3) to (4)
(1)
Test Points
- 89 -
(3)
Result
0Ω
(2)
(4)
