3-2 DOOR
Mullion Removal
●
1. Remove 2 screws.
2. Lift mullion up carefully.
3. Disconnect wire harness.
Door Gasket Removal
●
1. Remove gasket
Remove the gasket from gasket channel at doorliner as
shown in the illustration below.
Door Gasket Replacement
●
1. Insert gasket into channel
Insert and press gasket into channels at doorliner.
Mullion Replacement
●
1. Connect wire harness.
2. Insert mullion into channel.
Insert the mullion into channel at door as shown below.
3. Assemble 2 screws.
Gasket
Channel
Gasket
- 6 -
