LG LSFXC2476 Series Service Manual page 57

Hide thumbs Also See for LSFXC2476 Series:
Table of Contents

Advertisement

LEVER S/W
Pushing
CON2
4
th
pin ~
Not
B(NEUTRAL)
Pushing
Pushing
CON1
12
th
pin ~
Not
13
th
pin
Pushing
Voltage [V]
112~115V
0~2V
9~12V
0~2V
- 57 -
Resistance [Ω]
Geared Motor
Dispenser Motor
31.1 ~ 42.1
9.9 ~ 12.1
