Cover Front; How To Remove And Reinstall The Homebar Door - LG LSFXC2476 Series Service Manual

3-23-4 COVER FRONT

The Cover Front is removable for easy cleaning and adjustment.
1. To remove the Cover Front, simply lifts the basket doorr up and pulls slopingly out.
2. Remove two screws of The Cover Front and pull slopingly straight out.
NOTE : To replace the Cover Front and basket door, Slide them in above desired support and push down until them
snaps into place.

3-24 HOW TO REMOVE AND REINSTALL THE HOMEBAR DOOR

1. Remove three Screws on the Top
of Frame Door.
2. Pull Frame Door. up and
out.
- 20 - - 20 -
