3-17 HOW TO REMOVE AND REINSTALL THE PULLOUT DRAWER

3-17-1 Follow Steps to Remove

Step 1) Open the freezer door.
Step 3) Remove the two screws from the guide rails (one
from each side).
Step 5) Remove only 1 screw of gearice, and disassemble
the bar and gearice
Step 2) Remove the lower basket.
Step 4) Removal of the freezer door is done by l ifting clear
of the rail support.
Fully extend both rails.
Step 6) Remove 2 screws of both side of supporter covers
tv and disassemble the supporter cover tv.
