11. ICEMAKER OPERATING METHOD AND TROUBLE SHOOTING
11-1 Icemaker's Basic Operating Method
Power On Power On
Start Position
Icemaking
Mode
Full Ice
Check
Full Ice?
Harvest
Mode
Fill
Test Mode
※ While ICE OFF indicator is on, icemaker stops making ice. But you can disense the ices until the ices run out
from the ice stoare.
Test
Button
- 106 -
• Adjusts EJECTOR to Start Position with power on.
• Walls until water becomes cold after starting the
icemaking operation.
• Check if the ice bin is full.
• Runs MOTOR to drop ice from the tray into the ICE
BIN.
• Performs Ice Making Mode afer supplying water by
operating the SOLENOID in ICE VALVE.
• With the detect lever, checks if the ICE BIN is full.
• To operate LINE and SERVICE, press and hold the
Test Button for 3 seconds. The icemaker will run
throught 3 stages:
Harvest, Fill, Ice making
