Summary of Contents for Intel NUC Kit D54250WYKH
- Page 1 Intel NUC Kit D54250WYKH & D34010WYKH User Guide Intel® NUC Kit D54250WYKH Intel® NUC Kit D34010WYKH User Guide...
-
Page 2: Before You Begin
If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis. Installation Precautions When you install and test the Intel NUC, observe all warnings and cautions in the installation instructions. To avoid injury, be careful of: ... - Page 3 Intel NUC Kit D54250WYKH & D34010WYKH User Guide This guide tells you how to: Install and remove memory • Install a wireless card • Install an mSATA SSD • Install a 2.5” drive • Install a VESA mount bracket •...
-
Page 4: Installing And Removing Memory
Intel NUC Kit D54250WYKH & D34010WYKH User Guide 2. Lift up the hard drive bracket and set it over the edge of the chassis to expose the motherboard. Installing and Removing Memory Intel NUC Kits D54250WYKH and D34010WYKH have two 204-pin DDR3L SO-DIMM sockets. Memory requirements: ... - Page 5 For more information on wireless adapters, go to: http://www.intel.com/support/wireless/wlan. CAUTION When installing a Mini-PCIe wireless adapter on the Intel NUC, ensure that the adapter is fully seated in the connector before you power on the system. If the adapter is not fully seated in the connector, an electrical short may result across the connector pins.
- Page 6 Intel NUC Kit D54250WYKH & D34010WYKH User Guide Install a Mini-PCIe Wireless Adapter Follow these instructions to install a Mini-PCIe wireless adapter: 1. Observe the precautions in "Before You Begin" on page 2. 2. Remove the small silver screw from the metal standoff on the motherboard (A).
- Page 7 Intel NUC Kit D54250WYKH & D34010WYKH User Guide 6. Remove the black tape holding the two wireless antennas. 7. Slide the clear plastic protective sleeve down onto the antenna wires, away from the connectors at the ends of the antennas (D).
- Page 8 Intel NUC Kit D54250WYKH & D34010WYKH User Guide 2. Remove the small silver screw from the metal standoff on the motherboard (A). 3. Align the small notch at the bottom edge of the mSATA card with the key in the connector.
- Page 9 Intel NUC Kit D54250WYKH & D34010WYKH User Guide 2. Slide the 2.5” drive into the drive bay, ensuring the SATA connectors are fully seated into the connectors of the SATA daughter card (A). 3. Secure the drive into the drive bay with the two small silver screws that were included in the box (B).
-
Page 10: Close The Chassis
Intel NUC Kit D54250WYKH & D34010WYKH User Guide Close the Chassis After all components have been installed, close the Intel NUC chassis. Intel recommends this be done by hand with a screwdriver to avoid over-tightening and possibly damaging the screws. -
Page 11: Install An Operating System
Intel NUC Kit D54250WYKH & D34010WYKH User Guide 2. Attach the two slightly larger black screws to the bottom chassis cover of the Intel NUC. 3. Slide the Intel NUC onto the VESA mount bracket. Install an Operating System Refer to... - Page 12 Intel NUC Kit D54250WYKH & D34010WYKH User Guide Install Intel NUC Drivers To download the latest Microsoft* Windows* drivers and BIOS updates, go to Download Center: Links: Intel® NUC Kit D54250WYKH Intel® NUC Kit D34010WYKH Drivers are available for the following features: ...
