Summary of Contents for XNET NGE2055F
- Page 1 XNET Network Box Camera Installation Manual Ver. 1.2 XNET Network Box Camera (NGE2055F) Installation Manual...
- Page 2 About this Manual A compatibility and durability test ensured this product’s high performance. This installation guide is for XNET Network Box Camera users only, and it describes operations related to XNET Network Box Camera. Please read this manual thoroughly paying attention to cautions and warnings before using the product even if you have used similar products before.
-
Page 3: Table Of Contents
2.3.2. Front / Rear View ........................7 2.3.3 Connecting to Alarm devices ......................9 3 . Software Installation ..................... 10 3.1. Connecting XNET to network ..................... 10 3.2. Installing IP-Installer Software and Configuring IP address ..........11 3.2.1. About IP-Installer ........................11 3.2.2. -
Page 4: About Xnet
Codec such as MJPEG and H.264. XNET provides stable real-time surveillance by real time video/ audio at 1080P level, local storage for any network problems, and hybrid IP technology that can be used with existing analog CCTV devices. -
Page 5: About The Product
XNET Network Box Camera Installation Manual 2. About the Product Please make sure the following contents are included when you open the package Contents Description Additional info. XNET product Network Box Camera (Lens not included) Auto Iris Lens Plug Connection plug for Auto-Iris control signal... -
Page 6: Functions And Designations
XNET Network Box Camera Installation Manual Auto Iris control plug Mounting Screw Hole 1/4”. 20 UNC(20 THREAD) L : 4.5mm +-0.2mm (ISO standard) or 0.197” (ASA standard) CS Ring Fix Screw 백 포커스 길이 조정 C Ring Attach both C Ring and CS... -
Page 7: Front / Rear View
XNET Network Box Camera Installation Manual STATUS LED Factory Reset Figure 2-2 Network Camera Front / Rear view Power LED STATUS LED : Indicate the status of the product EVENT LED : If the alarm out is operating, the green LED blinks. - Page 8 XNET Network Box Camera Installation Manual LINK : Yellow light indicates that he network is properly connected. ACT : Green light indicates that the XNET system connected to 100Mbps LAN. This green lamp will blink if the system receives data.
-
Page 9: Connecting To Alarm Devices
XNET Network Box Camera Installation Manual Alarm Input Wires from various sensor type (IR, heat, and magnetic) can be connected to Alarm in(+)/(-) terminal as shown in figure 2.5. (NC or NO of sensor input can be selected at Menu screen.) Alarm Sensor device requires a separate power source. -
Page 10: Software Installation
3. Software Installation This section provides brief guidelines to install the XNET software quickly and to monitor XNET’s Video and Audio signals easily. If you have questions about details not explained in this section or if the product is not functioning as described, please refer to FAQ before contacting the store. -
Page 11: Installing Ip-Installer Software And Configuring Ip Address
XNET Network Box Camera Installation Manual A unique IP address has to be configured in order to connect network camera and monitoring PC to a network. IP-Installer software provided in the Installation CD (included in the package and also available to download from our website http://www.cnbtec.com) will configure IP address easily. - Page 12 XNET Network Box Camera Installation Manual 2. Select the camera of which you wish to change the IP address and click Installler Menu (Set IP Address) button to bring up the following box in Figure 3-2. Figure 3-2. IP Address box 3.
-
Page 13: Using Web Viewer
XNET Network Box Camera Installation Manual 4. Using Web Viewer Connecting to network devices can be done using internet web browser or “CNB-CMS” software. This guide explains about using internet web browser only. For instructions on how to configure network connection using CNB-CMS software, please refer to CNB-CMS Manual, which can be found in the installation CD. -
Page 14: Web Viewer Page
XNET Network Box Camera Installation Manual Web viewer page consists of Video monitor screen and menu option buttons. Figure 4-2 Web Viewer Page 14 / 17... - Page 15 Capture The image is saved as jpeg file in the following folder: C:\xNetCapture Brings up Menu screen. Setup page for each XNET feature can be opened from this Menu screen. Setting Please refer to [XNET Owner’s Manual] for detail. Opens up PTZ page.
-
Page 16: Specifications
XNET Network Box Camera Installation Manual 5. Specifications NGE2055F Specifications Signal System Progressive Image processing C a m e r a Scanning System 16:9 Progressive Image Sensor Progressive CMOS Sensor Sync. System Internal Effective Pixel Number 1920(H)x1080(V) Horizontal Resolution 1100 TV Lines Video Output Level Select NTSC/PAL 1.0Vp.p (BNC 75, composite) - Page 17 XNET Network Box Camera Installation Manual 17 / 17...
