Pidion HM45 User Manual

Hide thumbs Also See for HM45:
Table of Contents

Advertisement

Quick Links

Download this manual
www.bluebirdsoft.com
HM45
HM45
USER MANUAL
USER MANUAL
- Before using, please read and follow the user warnings.
- Before using, please read and follow the user warnings.
- In the manual the component's shape and color
- In the manual the component's shape and color
can be different from the actual model.
can be different from the actual model.
-The information in the manual can vary depending
-The information in the manual can vary depending
on the software version and your mobile carrier.
on the software version and your mobile carrier.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HM45 and is the answer not in the manual?

Questions and answers

Related Manuals for Pidion HM45

Summary of Contents for Pidion HM45

  • Page 1 HM45 HM45 USER MANUAL USER MANUAL - Before using, please read and follow the user warnings. - Before using, please read and follow the user warnings. - In the manual the component’s shape and color - In the manual the component’s shape and color can be different from the actual model.
  • Page 2 HM45 FCC Compliance Information This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 HM45 FCC Compliance Information This device complies with Part 15 of FCC Rules. Operation is subject to the following twoconditions: (1) the device may not cause interference, and (2) the device must accept any interference, including interference that may cause undesired operation of this device.
  • Page 4 ∙ T his wireless equipment cannot service related to safety of human lives due to possible signal interference. REGISTERED PIDION as the future mobile’s leading global brand, expresses with reliability, representativeness, and image of advanced technology. It is a registered trademark from the global brand of Bluebird Soft.

  • Page 5: Table Of Contents

    Contents HM45 - - - - - - - - - - 2 - - - - - - - - - - - 19 Notice Befor e Using the Device Connecting ActiveSync - - - - - - - - - - - - - - 19...

  • Page 6: Notice Befor E Using The Device

    (Ring tones, text/voice ∙ Please follow instructions when using the batter. message, characters will be reset.) ∙ D o not use your device at an explosive danger zone. HM45 Manual...
  • Page 7 HM45 ∙ ∙ Please refrain from using your device while driving. If Do not place your device at a dusty place. Keep your you are in an unavoidable situation, stop your vehicle or power cord away from any heating devices. Unplug use your hand free kit.

  • Page 8: Pr Ecautions Befor E Using The Battery

    P lease take precaution in not letting necklaces, coins and etc touch the battery’s terminal (metal part). Do not give an impact on the battery by a sharp object or an animal. There is a risk of explosion. HM45 Manual...

  • Page 9: About The Product

    About the Product HM45 1. Checking components The images in this User’s Manual may not reflect the color and shape of the actual product. (Please contact the Customer Care Center if you wish to purchase any additional or optional products.)

  • Page 10: Getting To Know Your Device's Each Part

    Getting to know your Device 2. Getting to know y our de vice's each part Power/Programmable Phone Speaker Power Button Screen Barcode Scan Button Microphone MicroUSB Port Cradle I/O Connector HM45 Manual...
  • Page 11 HM45 Battery Cover Battery Cover On/Off Flash Speaker Camera FN/PTT Button Volume Down Barcode Scan Window Volume Up Stylus pen...

  • Page 12: Learning Basics

    1. Insert/Remo v e the battery 1-1. Insert the battery 1 Push the battery to the direction of the arrow. 2 Push down the battery protect cover to the direction of arrow. Only use the supplied adapter to charge your battery. HM45 Manual...
  • Page 13 Learning Basics HM45 3 Push the battery cover to the direction of the arrow. 4 Lock the battery cover sliding the ‘LOCK’ to the right.
  • Page 14 1-2. Removing the battery 1 Unlock the battery cover sliding the ‘LCOK’ to the left. 2 Slide down the battery cover to remove. HM45 Manual...
  • Page 15 Learning Basics HM45 3 Lift up the battery protect cover . 4 Lift up the battery from the top of the battery.

  • Page 16: I Nsert/Remove The Usim Card

    2. Insert/Remo v e the USIM car d 2-1. Insert the USIM card 1 Push the USIM card holder to (◀ OPEN), direction then lift 2 Place the USIM card on the holder then push down the holder. HM45 Manual...

  • Page 17: Insert/Remove The Microsd Card

    Learning Basics HM45 3. Insert/Remo v e the Micr oSD Car d 2-3. Removing the USIM card 3-1. Insert the MicroSD Card Push the top of the USIM card and slide it out from the holder. 1 Open the storage card holder by lifting up the flap.
  • Page 18 2 Insert the microSD card into the storage card holder with its 3 Lock the storage card holder by pushing it down into place. gold contacts facing out. HM45 Manual...
  • Page 19 Learning Basics HM45 3-2. Remove the MicroSD card 3-3. Precautions using the MicroSD Card ∙ The SD card can break if you frequently slide in/out or put or excessively put too much force. ∙ If the card is removed while being used or being turned off, the data can be lost or malfunction.

  • Page 20: Charging With Cradle

    ∙ When the device’s battery is low, it may warn you with a ring and a message. ∙ The charging time can vary depending on the environment. A new battery is only partially charged. Please charge fully before using. HM45 Manual...

  • Page 21: Turning On

    Learning Basics HM45 5. T urning On 6. Soft Reset ∙ T he [Power] button in on the side. ∙ Please soft reset if your device freezes or has an unexpected error. ∙ T o turn your device on you must press the shortly.

  • Page 22: Hard Reset

    ∙ We are not responsible for any information selected item, hold down on the item and being erased. Before you hard reset, please a popup will appear. ( it is similar to the back up your data. mouse right click on the PC) HM45 Manual...

  • Page 23: Connecting Activesync

    Connecting ActiveSync HM45 1. Installing on PC ∙ [Microsoft ActiveSync 4.5] version. 1 After connecting to the Microsoft homepage, download and install [Microsoft ActiveSync]. ∙ The functions and the layout can be different if you use different version. ∙ [Microsoft ActiveSync] can be updated through the Microsoft Homepage.
  • Page 24 2 On the window about the license terms, press <I accept 3 [Microsoft Active Sync] can be installed when it is ready to the license terms> ->On the [Client information] window, install. input <User name> ->Specify where you want to install. 4 [Microsoft ActiveSync] is installed. HM45 Manual...

  • Page 25: Using Activesync

    HM45 2. Using A ctiv eSync ∙ You can see a Windows Mobile version on the 1 You can connect with the Cradle. display and it can be different according to the version. ∙ [Microsoft ActiveSync] can be used when the device is plugged into a notebook or pc.
  • Page 26 2 If the device and computer are successfully 3 In the <Mobile device> folder, you can check the connected, Microsoft Activesync] will automatically photos, music, and documents stored in the device start. Please select the <Search> button. and move it to the computer. HM45 Manual...
  • Page 27 HM45 [Precautions using ActiveSync] ∙ T he device not running after removing the battery ∙ W hen "unknown USB device" can pop up, when while device on. the device is turning on while connected to the For this to be avoided, do not remove the battery <Micro USB Cable>.

  • Page 28: Connecting Activesync

    Your device and the surrounding devices can you used when connected with the <USB Cable>. If you use the function [USB-PC Connect] your device’s battery consumption will be high. If you are not using the function [USB-PC Connect] disconnect to save your battery consumption. HM45 Manual...

  • Page 29: Using The Barcode Reader

    Using The Barcode Reader HM45 1. Using the Bar codes 2. Scanning Bar codes Press the [Barcode Scan] button on the side or front of In order to scan accurately, you must scan with the the device to start scanning barcodes.

  • Page 30: Checking Barcodes

    <Memo> is open, the barcode will be automatically saved in <Memo>. If you scan when <Memo> is not opened, it will not be saved. To do this, press the [Menu] button in [Create New] and [Paste] to save. HM45 Manual...

  • Page 31: Device Specifications

    Device Specifications HM45 Physical Characteristics Performance Characteristics Dimensions 1GHz 64.8 x 134.5 x 18.9 mm / 2.5 x 5.3 x 0.7 inch (W x H x D) Android Weight Including standard battery : 195g Memory 1GB RAM / 16GB ROM 3.5-inch widescreen capacitive Touch Display, 800x480...

  • Page 32: Q & A

    ※ If you have done the above and the device still battery. (The battery warranty is 6 menthes) does not work, please refer to the service center. ※ After the 1 year warranty the repair service will be charged. HM45 Manual...

  • Page 33: Service Center

    Service Center HM45 Before Requesting After-Sales Service Registering for After-Sales Service Before asking for after-sales service, please back up We receive the products for after-sales service through the data from the terminal. mail, delivery service and hand carry only in principle.
  • Page 34 - Default due to nature (fire, damage due to sea wind, after-sales service (note, returning of goods or flood damage, etc.). repayment is not allowed). - Expendable parts have exhausted there life (batteries, antenna, or other component parts). HM45 Manual...

  • Page 35: Warranty Certificate

    Warranty Certificate HM45 Thank you for purchasing a product from Bluebird Soft Inc. If a circumstance arises where you lose a receipt or the Name of Product Handheld Mobile Computer certificate of guarantee, then the term of guarantee will be calculated 3 months (certified by the number of the...
  • Page 36 4. Bluebird assumes no responsibility for repairing, replacement or refund until it receives the defective product from the customer. The replacement shall be equivalent to a new product in the aspect of performance. HM45 Manual...
  • Page 37 Customer Service Center Working hours Weekdays (9:30am ~ 6:30pm) Saturdays and Sundays Closed Phone Number: 1588-1380 Address: Customers service center, SSang- young IT twintower B 703, Sangdaewon-dong 442-5, Joongwon-gu, Sungnam-si, Keonggi-do, Customer Service Center 1588-1380 we will do our best to satisfy your needs.
