- Page 1 HEAVY-DUTY STEEL WAGON Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 51205 SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a BANNON product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Assembly Instructions .......................... 7 Before Each Use ............................ 9 Operating Instructions ........................10 Maintenance ............................10 Parts Diagram ............................11 Parts List .............................. -
Page 4: Intended Use
Intended Use Perfect for hauling oversized loads such as firewood, rock, mulch and dirt. Technical Specifications Property Specification Capacity 1500 lbs. 15 inch Pneumatic Tires Tires Do not inflate the tires to more than 30 PSI. Construction Steel construction Dimensions (in.) 52 x 34 x 12 Important Safety Information ... - Page 5 WORK AREA SAFETY Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well lit. Cluttered, wet, or dark work areas can result in injury. Using the wagon in confined work areas may put you dangerously close to other cutting tools and rotating parts. ...
-
Page 6: Specific Operation Warnings
Specific Operation Warnings Do not exceed the overall maximum load capacity of 1500 lbs. The weight rating is based on an evenly distributed load. Do not load items on the top edges of the panels. Remove panels before loading oversized items. Use caution when removing sides as the load can fall out and cause injury. -
Page 7: Assembly Instructions
Assembly Instructions TOOLS REQUIRED STEP 1 Assemble the front and rear axle to the bed of the wagon. Tighten bolts securely. STEP 2 Assemble the yoke to the front axle. Tighten bolts securely. Page 7 of 13... - Page 8 STEP 3 Place the wheels onto each axle (valve stem facing out) and secure using washer and cotter pin. Bend back the ends of the cotter pin to keep them in place. STEP 4 Turn the wagon upright. Attach the handle to the yoke. Tighten securely. Page 8 of 13...
-
Page 9: Before Each Use
STEP 5 Attach the mesh panels to the side of the bed frame. STEP 6 Insert liner. Before Each Use Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Page 9 of 13... -
Page 10: Operating Instructions
Operating Instructions Distribute the load evenly over the surface of the bed. Do not load items on the top edges of the wagon. USING THE SWIVEL HANDLE 1. Remove clips and cotter pins. 2. Rotate the handle and insert cotter pin. Secure by attaching the clip. 3. -
Page 11: Parts Diagram
Parts Diagram Parts List REF. Description Qty. Front Axle Yoke Rear Axle Front/Rear Panels Side Panels Tires Handle Hardware Kit Liner Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the parts. -
Page 12: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Bannon product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of two year from date of purchase. - Page 13 Distributed by Northern Tool and Equipment Company, Inc. Burnsville, Minnesota 55306 NorthernTool.com Made in China Page 13 of 13...
