OUTDOOR FIRE PIT TABLE

ATTACH YOUR RECEIPT HERE

Serial Number ___________ Purchase Date _____________

Manufacturer: Changzhou Wellife Furnace Co., Ltd

Questions, problems, missing parts? Before returning to your retailer, call our customer

service hotline at 1-866-985-7877, 9 a.m. – 6 p.m., EST, Monday – Friday or email at

cservice@welltraveled.net.

Owner's Manual

ITEM # 61928

Table of Contents

Need help?

Do you have a question about the 61928 and is the answer not in the manual?

Questions and answers

Summary of Contents for Firesense 61928

Page 1 Owner's Manual OUTDOOR FIRE PIT TABLE ITEM # 61928 ATTACH YOUR RECEIPT HERE Serial Number ___________ Purchase Date _____________ Manufacturer: Changzhou Wellife Furnace Co., Ltd Questions, problems, missing parts? Before returning to your retailer, call our customer service hotline at 1-866-985-7877, 9 a.m. – 6 p.m., EST, Monday – Friday or email at...
Page 2: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Burner Cover Table Top Burner Burner Bracket Side Panel 1 Side Panel 2 Back Panel Door Frame Gas Tank Support Bolt(8*52mm)/Washer/Spring Washer/Nut(M8) Bolt(6*22mm)/Washer(M6) Screwdriver Wrench Allen Wrench Fire Glass 2 boxes/4 bags Protective Fire Pit Cover LPG Tank Cover Burner Cover Spring Button Bolt(4*10mm)
Page 3: Hardware Contents
HARDWARE CONTENTS SAFETY INFORMATION SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install this appliance. If you have any questions regarding the product, please call customer service 1-866-985-7877, 9 a.m. – 6 p.m., EST, Monday – Friday.
Page 4: Safety Information
SAFETY INFORMATION DANGER DANGER EXPLOSION - FIRE HAZARD CARBON MONOXIDE HAZARD Keep solid combustibles, such as building materials, This fire pit is a combustion appliance. All combustion paper or cardboard, a safe distance away from the appliances produce carbon monoxide (CO) during the fire pit as recommended by the instructions.
Page 5: Burn Hazard
SAFETY INFORMATION WARNING WARNING California Proposition 65 This product is fueled by propane gas. Propane gas Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a rotten egg”smell.
Page 6: Operation Checklist
OPERATION CHECKLIST Operation Checklist For a safe and pleasurable heating experience, perform this checklist before each use. Before Operating: 1. I am familiar with entire owner’s manual and understand all precautions noted. 2. All components are properly assembled, intact and operable. 3.
Page 7 ASSEMBLY NOTE: It is best to use TWO PEOPLE for assembly of this gas fire pit. 1. Connect Side Panels (E & F) to Back Panel (G) and Door Frame (H). Align holes in Side Panels/Back Panel/Door and insert Bolt(M6*22)(K) through Washer(M6)(K) and then insert Bolt/Washer through holes.
Page 8 ASSEMBLY 3. Place the Burner Bracket (D) onto the assembled panels. Place the Burner (C) onto the Burner Bracket (D) making sure the burner controls are facing forward toward the Door Frame (H). (No hardware is required) 4. Turn the Table Top (B) upside down and attach the Bolt(8*52mm)(J) to the underside of the Table Top using the Screwdriver (L).
Page 9 ASSEMBLY 5. Attach the Burner Cover Spring Button (R) to the underside of the Burner Cover (A) using the Bolt(4*10mm)(S) and the Phillips Screwdriver (T). Pour the Fire Glass (O) around the Burner (C). Do not obstruct pilot light housing. Put the Burner Cover (A) on the Burner when the fire pit is NOT in use and is completely cooled.
Page 10 ASSEMBLY A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a propane cylinder with a damaged valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. Department of Transportation(DOT) or the standard for cylinders, spheres and tubes for transportation of dangerous goods and commission, CAN/CSA-B339.
Page 11 OPERATION INSTRUCTIONS Leak Test WARNING Perform all leak tests outdoors. Extinguish all open flames. NEVER leak test when smoking. Do not use the fire pit until all connections have been leak tested and do not leak. Hose / Regulator Regulator / Cylinder connection connection Underside of burner...
Page 12 OPERATION INSTRUCTIONS DANGER WARNING • CARBON MONOXIDE HAZARD Very hot while in operation! • For outdoor use only. Never use inside house, or other Never lean over the fire pit while in use. unventilated or enclosed areas. This fire pit consumes air Failure to comply with these instructions may result in serious bodily injury.
Page 13: For Your Safety
OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this fire pit. Holding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When fire pit is ON: Burner will display tongues of blue and yellow flame.
Page 14: Care And Maintenance
CARE AND MAINTENANCE Gas odor with extreme yellow tipping of flame. Fire pit does NOT reach the desired temperature. Fire pit glow is excessively uneven. Fire pit makes popping noises. Spiders and insects can nest in burner or orifices. This dangerous condition can damage fire pit and render it unsafe for use.
Page 15: Troubleshooting
TROUBLESHOOTING Wait until the propane cylinder Propane cylinder is frosted over warms up and becomes unfrosted Burner won`t light Blockage in orifice Clear blockage Control knob is not in ON position Turn control knob to ON Turn cylinder valve OFF and fill the Gas pressure is low cylinder Outdoor temperature is less than 40ºF and...
Page 16 Distributed By: Well Traveled Living Web: www wtliving com 716 S 8 Street Email: cservice@welltraveled.net Amelia Island, FL 32034 Toll Free: 866-WTL-SUPP (866-985-7877) 5 YEAR LIMITED WARRANTY – Customers in the Continental US All components are warranted for a period of 5 years after date of purchase by the original owner against defects in materials and workmanship under normal use.
