Summary of Contents for Eneo TVD-1080V2812IR
- Page 1 User Manual 1/2.8” HD-TVI Dome, Fixed, Day&Night, 1920x1080, 2.8- 12mm, Infrared, 3D-DNR, 12V TVD-1080V2812IR...
-
Page 3: Safety Precaution
FULL-HD MEGA-PIXEL CAMERA Safety Precaution To prevent fire or shock hazard, do not expose the unit to rain or moisture. To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source. CAUTION: TO REDUCE THE RISK OF ELECTIC SHOCK, DO NOT REMOVE COVER (OR BACK). - Page 4 FULL-HD MEGA-PIXEL CAMERA Safety Precaution NOTICE The image used in this instruction manual are processed to help comprehension and may differ from actual video of the camera. Avoid installing areas where has shock or vibration which results in the problems. Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
-
Page 5: Table Of Contents
FULL-HD MEGA-PIXEL CAMERA Contents p.03~04 Safety Precaution p.05 Contents p.06~07 Features p.07 Composition p.08 Dimensions p.09 Part Names p.10~12 Installation Instructions p.13~27 Operating Instructions p.28 Specifications... -
Page 6: Features
FULL-HD MEGA-PIXEL CAMERA Features Key Features • Full HD, 2Mega Pixel HD-TVI CAMERA, 1920x1080(30p/25p) • TVI Video Transmission Distance over Coax.; 500M (RG59, 75Ω) • True WDR(Wide Dynamic Range) • Automatically removable IR Cut filter by Dual filter switcher • Built-in f=2.8~12mm F1.4 Mega pixel DC Auto Iris Vari-focal lens •... -
Page 7: Composition
FULL-HD MEGA-PIXEL CAMERA Composition Plastic Anchor: 6 x 30mm (3pcs) Easy Adaptor Mounting Screw: 3.5 x 25mm (3pcs) Open & Adjust Driver (1pc) Dome Camera Tilted Adaptor Operating Mounting Template Video Sub-out Cable Instruction... -
Page 8: Dimensions
FULL-HD MEGA-PIXEL CAMERA Dimensions (unit : mm) CAUTION • Extreme care should be taken NOT to scratch the bubble dome surface while the camera installing or adjusting. • Extreme care should be taken NOT to apply force to IR LEDs. •... -
Page 9: Part Names
FULL-HD MEGA-PIXEL CAMERA Part Names Option: Tilted Easy Adaptor Power Cable Easy Adaptor Flat type Dome Base Focus & Zoom adjustment Lens 3-Axis Gimbal Dome Cover Bubble Shield Bubble Light Sensor OSD Control Joystick SMD LEDs Video Sub-out Never apply force to connector IR LEDs... -
Page 10: Installation Instructions
FULL-HD MEGA-PIXEL CAMERA Installation Instructions 1. Drill three holes for mounting on the ceiling or wall. 2. Attach the Easy Adaptors at the pre-drilled installation position and fix it by using mounting screws. 3. Route the power/video cable to the connecting place. 4. - Page 11 FULL-HD MEGA-PIXEL CAMERA Installation Instructions Limit of pan & tilt 1) Pan limit: Pan is limited to +/- 175°. ■ EXTENDED VIEWING ANGLE Do NOT force to rotate the gimbal over the limit to prevent from the internal damage. 2) Tilt limit: Tilt is limited to 25°...
- Page 12 FULL-HD MEGA-PIXEL CAMERA Installation Instructions ■ Detach the dome camera from the easy adaptor Push the hook on the dome base and swing the dome base to counter- clock wise. Then detach the dome camera from the installed easy adaptor. ■...
-
Page 13: Operating Instructions
FULL-HD MEGA-PIXEL CAMERA Operating Instructions Using OSD controller Setup menu can be accessed and controlled by OSD control joy stick on gimbal of camera unit. Five commands are available with the joy stick. The design of OSD could be different according to the Model. OSD Control Joy Stick Description of the joystick operation 1) SET Key (●) : Access to the menu or enter the setting. - Page 14 FULL-HD MEGA-PIXEL CAMERA Operating Instructions OSD menu Startup Press ‘●’(OSD menu Joy stick key) down for about 2 seconds to access the setup menu mode. • RET : Returns to the previous menu. • EXIT : Exits the menu setting without save. •...
- Page 15 FULL-HD MEGA-PIXEL CAMERA Operating Instructions NORMAL SCENE D-WDR – Improves the visibility by compensating the video gain for ENHANCE the dark area. Noise can increase in the dark area accordingly. BLC – Improves the visibility for the dark object by the bright back light.
- Page 16 FULL-HD MEGA-PIXEL CAMERA Operating Instructions 1. EXPOSURE EXPOSURE SHUTTER AUTO |:::::::|::::::| 10 BRIGHTNESS SENS-UP |:::::::|::::::| 12 RETURN 1-1. SHUTTER (default: AUTO) : Can set SHUTTER MODE to AUTO, MANUAL and Flickerless. MANUAL and Flickerless modes disable SENS-UP functions. • AUTO: Optimizes the video level by controlling the iris and the shutter speed automatically.
- Page 17 FULL-HD MEGA-PIXEL CAMERA Operating Instructions 2. LENS Lens can be selected either DC or MANUAL lens. Lens MUST be set to DC for the best image when DC iris lens is installed MANUAL NORMAL MODE DEBLUR MODE RETURN RETURN 2-1. DC (default: DEBLUR for None LED type) : Selects lens mode according to installation place.
- Page 18 FULL-HD MEGA-PIXEL CAMERA Operating Instructions FOCUS Adj. menu is the unique and patented feature that prevents from the wrong focus and helps the EXACT NEEDLE focus by simulating DAY & NIGHT conditions. Set zoom first and adjust focus to get NEEDLE FOCUS while switching at DAY &...
- Page 19 FULL-HD MEGA-PIXEL CAMERA Operating Instructions Higher setting reduces noise much more but results in losing the sharpness and the tail effect or the motion blur for the fast moving target at low light. 6. DAY / NIGHT : Refer to ‘DIRECT CONTROL MENU’ table. Default setting are EXT for IR-LED types and AUTO for None IR LED types.
- Page 20 FULL-HD MEGA-PIXEL CAMERA Operating Instructions 7-2. SHARPNESS : Adjusts the sharpness of video(0~20). (default: 10) 7-3. COLOR GAIN : Adjusts the color level of video(0~20). (default: 10) 7-4. GAMMA : Adjusts the gamma of video. (default: 0.5) 7-5. SHADING (default: OFF) ON enables to compensate the shade caused by wide lens setting.
- Page 21 FULL-HD MEGA-PIXEL CAMERA Operating Instructions 7-3. MOTION (default: OFF) : MOTION can detect the changes in the motion window and displays the results in blocks and/or a text message. • SENSITIVITY : Adjusts the detection sensitivity for motion. High value increases the sensitivity to detect the small motion easily. Too low sensitivity will cause the erratic detection by the tree leaves or the light level changes.
- Page 22 FULL-HD MEGA-PIXEL CAMERA Operating Instructions • EXECUTE ‘ ’: Long pressing will execute the pixel calibration for the detected pixels. Menu will exit automatically after compensation. 8-5. TITLE SET : Camera title(name) can be set and edited up to 15 alpha numeric and symbolic characters from ASCII codes(ENGLISH only).
- Page 23 FULL-HD MEGA-PIXEL CAMERA Operating Instructions 9. SYSTEM SYSTEM TV SYSTEM EU(PAL) RESOLUTION 1080P COMM. SETUP LANGUAGE FACTORY DEFAULT RETUTN 9-1. TV SYSTEM (default: US or EU) : Selects HDTV standards for US(60HZ) or EU(50HZ). By this selection, 2nd analog video output switches to NTSC or PAL accordingly. 9-2.
- Page 24 FULL-HD MEGA-PIXEL CAMERA Operating Instructions A. EXIT A-1. SAVE&EXIT : Save all the setting and exit the main menu A-2. EXIT : Exit the main menu without save.
- Page 25 FULL-HD MEGA-PIXEL CAMERA Operating Instructions Detail Function Description ▐ SMART MOTION ZOOM SMART MOTION ZOOM enlarges the certain area defined by a yellow window to the full sized image when the motion is detected in the black window. SMART MOTION ZOOM window can be re-sized by adjusting D-ZOOM RATIO and moved by H-POINTER and V-POINTER.
- Page 26 FULL-HD MEGA-PIXEL CAMERA Operating Instructions ▐ POINTING ZOOM This camera has a very useful and powerful feature, POINTING ZOOM, which can zoom in/out any area. UNLIKE the conventional zoom which can zoom in/out the center area of image only, by the flexible zoom location and area, POINTING ZOOM differentiates its usefulness from others.
- Page 27 FULL-HD MEGA-PIXEL CAMERA Operating Instructions * EXAMPLE OF SMART MOTION & POINTING ZOOM [ At the ATM nearby ENTERANCE ] [ At the LOBBY ]...
-
Page 28: Specifications
FULL-HD MEGA-PIXEL CAMERA Specifications ITEM TVD-1080V2810IR Imaging Sensor 1/2.8” Sony Exmor progressive scan CMOS Sensor Effective Pixels 1920(H) x 1080(V) x 25p Scan Frequency 25Hz(V), 18.75Khz(H)/ Progressive Video Format 16:9, 1080p/25 Synchronization Internal Video Resolution 1920x1080 (30p/25p) Min.Illumination 0.0009 Lux @ (LED Off, AGC 12, DSS x2) S/N Ratio More than 50dB (AGC Off) Lens... - Page 32 Videor E. Hartig GmbH Exclusive distribution through special- ised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
