BY BULL MANUFACTURING
Ontario, California 91762
_____________________________________________________________________________________________________
____
ASSEMBLY & OPERATING INSTRUCTIONS
MODEL 0-4078
4 Burner Powder Coated, Built-In, L.P. (Propane)
MODEL 0-4079
4 Burner Powder Coated, Built-In, Natural Gas
MODEL 40628
4 Burner Stainless Steel, Rotisserie, Built-In, L.P. (Propane)
MODEL 40629
4 Burner Stainless Steel, Rotisserie, Built-In, Natural Gas
TABLE OF CONTENTS
PAGE
SAFETY INSTRUCTIONS .............................................................................................................. 2
INSTALLATION INSTRUCTIONS ..................................................................................................... 4
LIGHTING & OPERATING INSTRUCTIONS ........................................................................................ 9
CLEANING & MAINTENANCE .......................................................................................................... 12
TROUBLESHOOTING .................................................................................................................... 13
PARTS LIST ................................................................................................................................. 14
WARRANTY................................................................................................................................... 16
READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE SURE YOUR GRILL IS PROPERLY INSTALLED,
ASSEMBLED AND CARED FOR. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SERIOUS BODILY
INJURY AND/OR PROPERTY DAMAGE. IF YOU HAVE QUESTIONS CONCERNING ASSEMBLY OR OPERATION,
CONSULT YOUR DEALER, GAS APPLIANCE SERVICE REPRESENTATIVE OR YOUR GAS COMPANY
NOTE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH THE CONSUMER AFTER INSTALLATION.
NOTE TO THE CONSUMER
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Advertisement
Summary of Contents for Bullet Barbecue 0-4078
-
Page 1: Table Of Contents
BY BULL MANUFACTURING Ontario, California 91762 _____________________________________________________________________________________________________ ____ ASSEMBLY & OPERATING INSTRUCTIONS MODEL 0-4078 4 Burner Powder Coated, Built-In, L.P. (Propane) MODEL 0-4079 4 Burner Powder Coated, Built-In, Natural Gas MODEL 40628 4 Burner Stainless Steel, Rotisserie, Built-In, L.P. (Propane) -
Page 2: Safety Instructions
THIS OUTDOOR COOKING GAS APPLIANCE IS NOT INTENDED TO BE INSTALLED IN OR ON RECREATIONAL VEHICLES AND/OR BOATS. Revision 03/01 SAFETY INSTRUCTIONS Read carefully before assembling and operating your gas grill This gas grill must be installed in accordance with local codes or, if in an area without local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1. - Page 3 NEVER TEST FOR GAS LEAKS WITH A FLAME...prior to first use and at the beginning of each new season (or, if using LP, whenever gas cylinder is changed), it is a must that you check for gas leaks. Follow these steps: 1.
-
Page 4: Installation Instructions
WARNING: Gas valves are preset at the factory to operate on LP or natural gas. If you wish to convert, be sure to contact your grill dealer FIRST! SAFETY ! BEWARE OF SPIDERS CAUTION: BURNER TUBES MUST BE INSPECTED AND CLEANED BEFORE FIRST USE. Spiders and small insects occasionally spin webs or make nests in the burner tubes during warehousing and transit. - Page 5 action of natural gas must be used on all male pipe thread. Apply compound or tape to at least the first three threads when making the connection. Remove plastic cap from regulator installed on grill. Attach stainless steel flex line 3/8” flare-female end to the regulator. Attached the other end of flex line to shut-off valve thru a nipple.
- Page 6 MODEL 3 BURNER 23” 4 BURNER 30 ½” 5 BURNER 38 ” OUTDOORS PROPANE GAS BBQ INSTALLATION SPECIFICATIONS NOTE: Vents must be provided for combustion air on both sides of built-in cabinet. When choosing a location for your gas grill keep in mind that it should never be located under any overhead combustible construction.
- Page 7 MODEL 3 BURNER 23” 4 BURNER 30 ½” 5 BURNER 38” INSPECTING I CLEANING BURNERS AND GAS VALVE ORIFICES By following these cleaning procedures on a timely basis, your grill will be kept clean and working properly with minimum effort. BURNER CLEANING 1.
- Page 8 3. Wire brush entire outside surface of burner to remove loose corrosion. 4. Clean any clogged hole with a stiff wire (such as an open paper clip). 5. Inspect the burner assembly for any opening caused by correction. 6. Replace burner and put cotter pin back to hole of the cast peg beneath the burner.
- Page 9 IMPORTANT: Before first use wash flame tamers, cooking grids, and warming rack with warm, soapy water. Rinse and dry thoroughly. Season metal surfaces with cooking oil occasionally. (After cooking is completed, turn grill to high setting for NO MORE THAN five minutes to burn off excess grease or food residue) CAUTION: DO NOT LEAVE GRILL UNATTENDED.
-
Page 10: Lighting & Operating Instructions
LIGHTING & OPERATING INSTRUCTIONS LIGHTING PROCEDURES Lighting Main Burner(s): 1. Become familiar with safety guidelines at front of manual. DO NOT SMOKE WHILE LIGHTING GRILL OR CHECKING GAS SUPPLY CONNECTIONSI 2. If your grill fuel source is a LP gas cylinder, check to see that cylinder is filled. 3. - Page 11 Do not attempt to regulate the rotisserie burner by using the control knob. This control has a fixed setting and is not adjustable. NOTE: Initially, the Ceramic Panel will have a blue flame that, after some time, will change to an orange flame and the Ceramic Panel will glow an orange color.
- Page 12 Nevertheless, uncontrolled flaring can result in a ruined meal. To control excessive flare- ups caused by too high a heat setting, turn the heat control knob to a lower setting. CAUTION: If burners go out during operation, close gas supply at source, and turn all gas valves off. Open lid and wait five minutes before attempting to re-light (this allows accumulated gas fumes to clear).
-
Page 13: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING THE COOKING GRIDS After cooking, turn control knobs to “OFF” and let grill cool before attempting to clean your cooking grids. Before first use and periodically it is suggested that you wash the cooking grids in a mild soap and warm water solution. You can use a washcloth or a vegetable brush to clean your cooking grids. -
Page 14: Troubleshooting
1. Remove burners from grill by carefully lifting each burner up and away from gas valve orifice. 2. Wire brush entire outer surface of burner to remove food residue and dirt. Clean any clogged ports with a stiff wire such as an open paper clip. -
Page 15: Parts List
Wait until the grill has cooled, then clean the burner tubes and burner ports as described on page 7. PARTS LIST MODEL 0-4078 4 Burner Powder Coated, Built-In, L.P. (Propane) MODEL 0-4079 4 Burner Powder Coated, Built-In, Natural Gas MODEL 40628 4 Burner Stainless Steel, Rotisserie, Built-In, L.P. -
Page 16: Warranty
REF # DESCRIPTION Lid -Front Lid -Rear Bowl Assembly Control Panel Grease Tray Grease Tray Handle Heat Shield Burner Flame Tamer Cooking Grid Warming Rack Lid Handle Warming Rack Support Flame Tamer Support Bezel Control Knob Temperature Gauge Gas Valve With Ignition Regulator (Natural Gas Model Only) Regulator (LP Model Only) Manifold... - Page 17 ILLUSTRATED PARTS LIST...
- Page 18 BY BULL MANUFACTURING Ontario, California 91762 LIMITED WARRANTY Bull Outdoor Products, Inc. warrants to the original purchaser at the original site of delivery with proof of purchase of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below.
