Master MH-40-GFA User's Manual And Operating Instructions
Hide thumbs
Also See for MH-40-GFA:
- User's manual & operating instructions (48 pages) ,
- User's manual and operating instructions (28 pages) ,
- User's manual & operating instructions (36 pages)
Table of Contents
Advertisement
Quick Links
User's Manual & Operating Instructions
MH-40-GFA / MH-60V-GFA-A / MH-125V-GFA-A / MH-150V-GFA-A
CONSUMER: READ AND SAVE THESE INSTRUCTIONS
GENERAL HAZARD WARNING:
DANGER
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH
THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS
OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN. ASPHYXIATION, CARBON
MONOXIDE POISONING AND / OR ELECTRIC SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE
OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS
MANUAL, LABEL, ETC. CONTACT THE MANUFACTURER.
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID
WARNING
COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR
CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY
THESE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY
CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNERS, DUST PARTICLES OR UNKNOWN CHEMICALS.
668 Stony Hill Road #302 Yardley, PA 19067 USA
Fax: (215)-891-8461
Model Numbers
© 2014 Pinnacle Products International, Inc.
• Web: www.masterindustrialproducts.com • Email: info@pinnacleint.com
Toll Free (800)-641-6996
•
221000152-14
Advertisement
Table of Contents
Related Manuals for Master MH-40-GFA
Summary of Contents for Master MH-40-GFA
- Page 1 User’s Manual & Operating Instructions Model Numbers MH-40-GFA / MH-60V-GFA-A / MH-125V-GFA-A / MH-150V-GFA-A CONSUMER: READ AND SAVE THESE INSTRUCTIONS GENERAL HAZARD WARNING: DANGER FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN.
-
Page 2: Table Of Contents
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Table Of Contents Safety Information..........1-3 Wiring Diagrams...........9 Specifications and Features........4 Troubleshooting Guide........10 Operation............5-7 Exploded View...........11 Ventilation............8 Parts List............12 Maintenance............8 Warranty.............13 Safety Information NOT FOR HOME OR RECREATIONAL VEHICLE USE. -
Page 3: Safety Information
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Safety Information RISK OF INDOOR AIR PROPANE IS AN WARNING DANGER POLLUTION! EXPLOSIVE GAS. The products described in this manual are propane direct-fired, forced air heaters. Propane WHAT TO DO IF THE SMELL OF GAS IS PRESENT: forced air heaters are primarily intended for –... - Page 4 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Safety Information The hose assembly shall be WARNING RISK OF ELECTRIC SHOCK! WARNING pro tected from traffic, building material and contact with hot surfaces both Electrical Grounding WARNING during use and while in storage.
-
Page 5: Specifications And Features
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Specifications Model # MH-40-GFA MH-60V-GFA-A MH-125V-GFA-A MH-150V-GFA-A 40,000 40/50/60,000 95/110/125,000 120/135/150,000 Fuel Consumption (Lbs./hr) 1.9 / 2.3 / 2.8 4.4 / 5.1 / 5.8 5.5 / 6.2 / 6.9... -
Page 6: Operation
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Operation Propane Supply / Information: The amount of Propane (LP) used with this heater varies. Both factors are – The amount of gas in the cylinder of LP. Propane (LP) –... - Page 7 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Operation Pre-Lighting Instructions: – With heater gas valve knob still in OFF Connecting the LP Cylinder position turn ON the LP cylinder valve and check for leaks with soap solution.
- Page 8 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Operation Lighting Instructions: Shutdown Instructions Starting the Heater (Ignition) To Shut Off the Heater: 1. Connect the heater to a three prong (grounded) power source.
-
Page 9: Ventilation
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Ventilation CARBON MONOXIDE POISONING MAY LEAD TO DEATH! DANGER – Risk of indoor air pollution and Carbon Monoxide Poisoning. Use heater only in Minimum Ventilation Opening Needed well ventilated areas. -
Page 10: Wiring Diagrams
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Wiring Diagrams 40-GFA Figure 6 60V-GFA-A / 125V-GFA-A / 150V-GFA-A Figure 7 © 2014, Pinnacle Products International, Inc. Propane Forced Air Heater User’s Manual... -
Page 11: Troubleshooting Guide
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Troubleshooting Guide Locating Your Serial Number: Your serial number can be found on a white label on the right side cover of your heater. It will begin with the letters “HGF”... -
Page 12: Exploded View
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Exploded View Figure 8 © 2014, Pinnacle Products International, Inc. Propane Forced Air Heater User’s Manual... -
Page 13: Parts List
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Parts List Item # Description MH-40-GFA MH-60V-GFA-A MH-125V-GFA-A MH-150V-GFA-A Outer Shell 22-524-0075 22-524-0076 22-524-0077 22-524-0077 Inner Shell Assembly 22-524-0004 22-524-0004 22-524-0005 22-524-0005... -
Page 14: Warranty
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE LIMITED WARRANTY Pinnacle Products International, Inc. warrants this heater If Pinnacle Products International, Inc. finds the item to to the original retail purchaser only, to be free from defects be in normal operating condition, or not defective the item in material and workmanship for a period of one (1) year will be returned freight collect. - Page 15 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________...
- Page 16 © 2014 Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19067 USA • Toll Free (800)-641-6996 Fax: (215)-891-8461 • Web: www.pinnacleint.com • Email: info@pinnacleint.com...
