Summary of Contents for Vulcan-Hart 839-8224
- Page 1 Instruction Manual Manual de instrucciones 28 & 30 degree Framing Strip Nailer ITEM NO. 839-8224 ARTICULO No. OFN2890 000-0000 v070823...
- Page 2 THANK YOU for your purchase of this Vulcan Air Tool. With proper care and use you can expect your purchase to provide years of trouble free service! SHOULD YOU HAVE A QUESTION OR A PROBLEM WITH YOUR VULCAN TOOL, PLEASE CALL OUR CUSTOMER SERVICE DEPARTMENT TOLL FREE AT: 1-800-482-0131 Please have the tool, model number and instruction manual at hand before calling.
-
Page 3: Safety Rules For All Tools
SAFETY RULES FOR ALL TOOLS Read and understand all instructions. Failure to follow all instructions listed WARNING below may result in serious personal injury. SAVE THESE INSTRUCTIONS Work Area Employers must enforce compliance with the safety warnings and all other instructions Keep work area clean and well lit. - Page 4 switch does not turn it on and off properly. return springs may be improperly mounted. User service. Some user-serviceable components When servicing tool, use only identical are described in the Troubleshooting section. We replacement parts. Follow instructions in cannot guarantee repairs made or attempted by the Maintenance section of this manual.
- Page 5 Do not drive fasteners on top of other Fire fasteners into work surface only and never fasteners, or with the tool at too steep an angle: into materials too hard to penetrate the fasteners can ricochet causing personal injury. Grip tool firmly to maintain control while Do not drive fasteners too close to the edge allowing the tool to recoil away from the work of the workpiece.
-
Page 6: Specifications
Nomenclature for No. 839-8224 & 30 Framing Nailer A) 30 degree re-directable exhaust port B) Depth adjustment screw C) Removeable contact tip D) Feeder shoe E) Feeder shoe lock F) Magazine G) Trigger H) Mode Selector Switch SPECIFICATIONS = Shoots standard 11-1/2ga. to 10-1/4ga. 28 degree framing strip nails up to 3-9/1” in... -
Page 7: Power Source
MANUAL. THIS WILL ALLOW FOR BEST USE AND MAXIMUM USER SATISFACTION. The Vulcan Model 839-8224 is a heavy duty pneumatic framing nailer with a lightweight magnesium housing. This tool is designed to install framing nails of various lengths (2-3/16” to 3-9/16” long.) with a fastener collation angle of 28 to 30 degrees including clip head nails like 28 degree Bostitch, Hitachi, &... -
Page 8: Loading Fasteners
LOADING FASTENERS After reading and understanding this entire manual, CAUTION = Disconnect tool from the air supply. = Keep tool pointed away from yourself and others at all times. = Be sure the tool has an empty magazine when connecting to the air supply = Do not load fasteners with trigger or safety pressed. -
Page 9: Using The Tool
Re-connect the tool to the air supply, being careful to aim the nosepiece in a safe direction, and careful to avoid touching the trigger or the safety mechanism. This is to prevent harm from fasteners accidentally discharging should the fastener driving mechanism cycle when the tool is connected to the air supply. - Page 10 CAUTION = Keep tool pointed away from yourself and others at all times. = Be sure the tool has an empty magazine when connecting to the air supply = Do not load fasteners with trigger or safety pressed. = Always wear approved safety glasses, and hearing protection when preparing or operating the tool.
-
Page 11: Maintenance
CLEARING A JAMMED FASTENER CAUTION Disconnect the tool from the air supply. Remove any remaining fasteners from the nailer. Pull feeder all the way to the rear until it latches Slide the fasteners to the rear, and remove fasteners from the magazine Use a pair of needle nose pliers and/or a flat screwdriver to remove bent fasteners from the back of the nosepiece. - Page 12 PROBLEM PROBLEM CAUSE CORRECTION Tool does nothing Inadequate air supply. Make sure air supply is Inadequate lubrication. adequate. operates sluggishly. O-rings or seal is worn Place two or three drops or damaged. of oil to the air inlet of the tool Air is leaking near Loose screws.
-
Page 13: Parts List
PARTS LIST Please refer to the schematic drawing on page 15 DESCRIPTION DESCRIPTION Screw M5 x 20 Bumper B Spring washer M5 Body Bushing O-Ring 62.3 x 1.8 Exhaust cover Nose Seal Spring washer M8 Screw M6 x 30 Screw M8 x 25 Spring washer M6 Spring Cylinder cap... - Page 14 PARTS LIST Please refer to the schematic drawing on page 15 DESCRIPTION DESCRIPTION O-Ring 24.8 x 2 Spring washer M4 Trigger valve guide Screw M4 X 12 Spring Feeder shoe Trigger assembly Screw M5 x 16 Rotating shaft pin Magazine Locking Washer Screw M4 x 16 Rotating shaft bushing...
-
Page 15: Schematic Drawing
SCHEMATIC DRAWING...
