Summary of Contents for Style selections 88300/26MM40013-Z335
- Page 1 Style Selections is a registered trademark ® of LF, LLC. All rights reserved. MODEL # 88300/26MM40013-Z335 Français p. 22 Español p. 43 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Specifications ......................... 2 Safety Information ..........................3 Package Contents ..........................6 Hardware Contents..........................7 Preparation ............................8 Assembly Instructions........................... 8 Operating Instructions ........................17 Care and Maintenance ........................18 Troubleshooting ..........................19 Warranty ............................. 20 Replacement Parts List ........................21 PRODUCT SPECIFICATIONS VOLTAGE 120VAC, 60 Hz... -
Page 3: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock and injury to persons, including the following: DANGER: •... - Page 4 4. The appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. SAFETY INFORMATION 5. Always unplug this appliance when not in use. 6.
- Page 5 SAFETY INFORMATION • Batteries are to be inserted with the correct polarity. • Exhausted batteries are to be removed from the product. • Non-rechargeable batteries are not to be recharged. SAVE THESE INSTRUCTIONS Cold-climate installation: It is mandatory the outer walls be insulated to conform to applicable insulation codes.
-
Page 6: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Base Center Left Side Panel Center Right Side Panel Center Front Panel Left Side Panel Right Side Panel Mantel Top Wood Shelf Center Left Front Panel Center Right Front Panel Center Shelf Center Back Panel Insert Door Insert Support Bar Rear Panel... -
Page 7: Hardware Contents
HARDWARE CONTENTS (shown actual size) Bolt Truss Head Qty: 56 Door Pull Wood Dowel Shelf Pin Screw (Not to scale) Qty: 6 Qty: 46 Qty: 8 Qty: 10 Screw Door Bumper Qty: 24 Qty: 7 Long Screw Qty: 2 Touch-up Pen (Not to scale) Qty: 1 Lowes.com... -
Page 8: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble, install or operate the product. To protect the product from possible scratches, assemble the parts on a scratch-free surface. - Page 9 4. Attach 1 plastic connector from connector block (T) where shown to center front panel (D). Secure with bolts (AA). Hardware Used Bolt 5. Insert 4 wood dowels (BB) into each pre-drilled hole on center front panel (D). Then, attach center front panel (D) between center left side panel (B) and center right side panel (C).
- Page 10 7. Use bolts (AA) through plastic connectors on center left side panel (B) and center right side panel (C) to attach assembly to center shelf (K). Hardware Used Bolt 8. Align 8 plastic connectors from connector pack (T) with correct holes on left side panel (E) and right side panel (F).
- Page 11 10. Align 1 plastic connector from connector pack (T) with correct holes on top middle support panel (Q). Secure plastic connectors with bolts (AA). Hardware Used Bolt 11. Insert one wood dowel (BB) into each of the pre-drilled holes in the top middle support panel (Q) and attach it to the top of center shelf (K);...
- Page 12 13. Set assembly upright, then use bolts (AA) through plastic connectors to attach mantel top (G). Hardware Used Bolt 14. Attach the center back panel (L) and rear panels (O) to the back of the assembly using truss head screws (CC) through the pre-drilled holes on the panels.
- Page 13 16. Remove the preassembled bolts from 6 door pulls (EE), then install door pulls (EE) to insert door (M) with the bolts. Hardware Used Door Pull Door Bumper 17. Align the hinges on doors (P) with the hinge brackets on the assembly, sliding the hinge until it is secure in the hinge bracket.
- Page 14 19 Choose desired height of wood shelf (H) and place the four shelf pins (DD) into the corresponding holes. Insert wood shelf (H) on top of the shelf pins (DD). Repeat as desired for the other wood shelf (H). Hardware Used Shelf Pin WARNING: Be sure to read all safety information prior to installing the insert (R).
- Page 15 21. Align insert support bar (N) with the holes on center right side panel (C) and center left side panel (B). Attach plastic blocks from 2-block connector pack (T) where shown to secure insert support bar (N). Secure with bolts (AA). Hardware Used Bolt 22.
- Page 16 23. WARNING: Installing the tipping restraint hardware will help prevent accidents and/or damage to the unit. It is highly recommended you complete this step. Unit Anchor To secure the item to the wall, find and mark a stud wall closest to the edge of the left side of the mantel. Attach the wall anchor from the tipping restraint hardware pack (W) at the marked locations using 2 of the screws from the pack.
-
Page 17: Operating Instructions
OPERATING INSTRUCTIONS The heater can be operated by either the remote control or the control panel. Control Panel Display Front View of Insert (R) Remote (S) FUNCTION ICON DESCRIPTION POWER Use the POWER button to turn on or off the fireplace from the remote or control panel. -
Page 18: Care And Maintenance
CARE AND MAINTENANCE • Dust the fireplace regularly with a soft, non-lint producing cloth or household dusting product. • Clean the fireplace with a gentle non-abrasive household cleaner. Make sure to dry the fireplace immediately with a soft cloth or towel. •... -
Page 19: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and The thermostat sensor is check that the thermostat is plugged into the main circuit board. If Display shows “ ”. broken or disconnected. this does not solve the problem, contact customer service for a replacement thermostat sensor. -
Page 20: Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants this product to be free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. 1. Install and operate this item in accordance with the installation and operating instructions furnished with the product at all times. -
Page 21: Replacement Parts List
Y15-C70-P85 Emberbed with Log Y15-S148-P02 Emberbed Circuit Board Y15-C75-P44E Blue Flame Circuit Board Y15-C70-P40BL Flame Circuit Board Y15-C76-P40 Spinner Y15-S148-P11 Remote Control P115 Printed in China Style Selections is a registered trademark ® of LF, LLC. All rights reserved. Lowes.com...
