Summary of Contents for Techni-Lux DL-QUADBOX1630TC
- Page 1 Information specifically for: DL-QUADBOX1630TC v1.0 This manual contains important information. Please read before operating fixture.
- Page 2 If purchase date can not be provided, warranty period will start at manufacture date. It is the sole discretion of Techni-Lux to repair or replace parts or equipment. All shipping will be paid by purchaser. This warranty does not cover lamps, fuses,...
-
Page 3: Table Of Contents
Table of Contents Specifications ..........................4 Unpacking ...........................5 Power............................5 Mounting .............................6 Basic Reference..........................6 Setup and Operation Modes (LCD Display)................7 Control Panel Menu & Operation Settings ................7 Built-in Program Chase Operation (P01-P15) ................7 Auto Run Operation ........................8 Slave Operation ........................8 Sound Active Operation ......................8 DMX Operation .........................8 DMX-512 Control.........................9 DMX Data Connection ......................9... -
Page 4: Specifications
Specifications Fixture Overview • Compact 4 x 4 design • Powerful 16 x 30w RGB COB LEDs • Individual control of 16 LEDS • Beam Angle – 60° • Rugged Housing • Operating modes: DMX, Auto Run, Chases, Sound Active, Master/Slave •... -
Page 5: Unpacking
Unpacking Immediately upon receipt, carefully unpack and inspect the fixture to verify that all parts are present and have been received in good condition. If any parts appear damaged from shipping or the shipping carton shows signs of mishandling, notify the shipper immediately. Retain carton and all packing material for inspection. -
Page 6: Mounting
Mounting Always consult a qualified professional when rigging. Consider access for routine maintenance when selecting a mounting position. This fixture may be mounted in any position provided there is adequate room for movement and ventilation. Mount the fixture securely using proper hardware, clamps and a safety cables. -
Page 7: Setup And Operation Modes (Lcd Display)
Setup and Operation Modes (LCD Display) The following refers to the different modes that are available on this fixture via the LCD Control Panel display. All functions are selectable from the display menu located at the back of the fixture. Note: The actual fixture may vary from the illustrations shown in this manual. -
Page 8: Auto Run Operation
P9 FLOW 4 Seven color chase 4 Speed 00-99 Flash 00-99 Speed & Flash strobe adjustable P10 FLOW 5 Seven color chase 5 Speed 00-99 Flash 00-99 Speed & Flash strobe adjustable P11 FLOW 6 Seven color chase 6 Speed 00-99 Flash 00-99 Speed &... -
Page 9: Dmx-512 Control
Note: The following DMX-512 Control section explains how to select a DMX start address for your fixture. It also covers connecting data cables, proper termination, specific channel assignments and channel value tables. DMX-512 Control Fixtures require a "Start Address" from 1 to 512, setting the first DMX channel containing data for the fixture (see DMX Background). -
Page 10: Adapter 5-To-3 Pin
Adapter 5-to-3 pin Systems using 5 pin DMX interfaces can be accommodated by purchasing 3-to-5 pin adapters or building adapter cables. Numbers designating each pin can be found on connectors. Converting between the two XLR types is done in a pin-to-pin fashion. Connect the shields to pin 1, then connect pin 2 to pin 2 and pin 3 to pin 3, regardless of either connector’s gender or pin count. -
Page 11: Channel Mode
DMX Channel Mode Descriptions In the 3 and 5 channel modes, the first 3 channels (1, 2, 3) function the same. 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 1,2,3 3 Channel Mode Channel Function Fixture completely operates as 1... -
Page 12: Channel Mode
48 Channel Mode Fixture is divided into 16 individual sections of RGB, without any macro, master dimmer or strobe function channels. R,G,B R,G,B R,G,B R,G,B 1,2,3 4,5,6 7,8,9 10,11,12 R,G,B R,G,B R,G,B R,G,B 13,14,15 16,17,18 19,20,21 22,23,24 R,G,B R,G,B R,G,B R,G,B 25,26,27 28,29,30... -
Page 13: Channel Mode
51 Channel Mode Fixture is divided into 16 individual sections of RGB with macro, master dimmer and strobe functions. Channels 1,2,3 are used to set what the other channels will R,G,B R,G,B R,G,B R,G,B 4,5,6 7,8,9 10,11,12 13,14,15 R,G,B R,G,B R,G,B R,G,B 16,17,18... - Page 14 Note: The first two channels in the 51 channel mode determine what the other channels will do. The table below shows what the channels affect. ….CH51 0-15 Master dimmer …. (0-255） ） ） ） (0-255） ） ） ） (0-255） ） ） ） 16-23 R Master dimmer 24-31 G...
-
Page 15: Maintenance
Maintenance Make sure fixture is cool and disconnected from power mains before any service. Weekly operating hours and environmental conditions will establish how often the fixtures need cleaning. Fixtures should be cleaned and inspected at least once a month to maintain optimum performance. -
Page 16: Troubleshooting
3 pin XLR connectors as these types of balanced or “Lo-Z” cables Data Negative (S- or Cold) are common in the audio industry. In either case, pin numbers are the same and Data Positive (S+ or Hot) carry the same signals. n/c (not used) n/c (not used) www.techni-lux.com...
