Arrive EyePoint AEP-3030 User Manual

Usb 3.0 hd camera
Hide thumbs

Advertisement

Quick Links

Download this manual
Arrive EyePoint
AEP-3030
TM
USB 3.0 HD CAMERA
Please note the serial number of your purchased product for future reference:
AEP-3030-UPTZ
Model No.: _________________
Serial No.:___________________________________________
USER MANUAL
AEP-3030-804-001

Advertisement

loading
Need help?

Need help?

Do you have a question about the EyePoint AEP-3030 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arrive EyePoint AEP-3030

  • Page 1 Arrive EyePoint AEP-3030 USB 3.0 HD CAMERA Please note the serial number of your purchased product for future reference: AEP-3030-UPTZ Model No.: _________________ Serial No.:___________________________________________ USER MANUAL AEP-3030-804-001...
  • Page 2 We reserve the right to introduce changes after the printing of this document. Please refer to our website www.arrivesys.com for updated documentation and information. © 2014 Arrive Systems, Inc. All Rights Reserved.

  • Page 3: Table Of Contents

    CONTENTS 1. INTRODUCTION ..............................9 2. FEATURES AND SPECIFICATIONS ........................9 3. INSTALLING THE DEVICE ..........................12 4. USING THE DEVICE ............................15 5. CONNECTING THE CAMERA ..........................21 6. TROUBLESHOOTING ............................25 © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 4 © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 5 CE Declaration of Conformity (For EU Customers) We, Arrive Systems, Inc., declare under our sole responsibility that the Arrive component to which this declaration relates, is in conformity with General Emissions Standard EN50081-1 and with Generic Immunity Standard EN50082-1 1992.
  • Page 6 15. Do not attempt to modify or fix this unit. Contact qualified ARRIVE service personnel when any service is needed. 16. Condensation will form when any surrounding temperature changes suddenly. Disconnect the cables, then leave this unit alone.
  • Page 7 This product and related documentation are proprietary to ARRIVE. This document does not provide you with any legal rights to any intellectual property in any ARRIVE product. You may copy and use this document for your internal, reference purposes.
  • Page 8 Specifications of this unit and contents of this document are subject to change without notice. • ARRIVE does not accept any liability for any loss or damage resulting from any use of this unit. the warranty covers this unit only.

  • Page 9: Introduction

    INTRODUCTION ■ Document scope The document provides the usage guidelines for Arrive EyePoint™ 3030 UPTZ family of USB 3.0 HD cameras. It guides you through the features, technical specifications, and steps in deploying and configuring the camera. It also provides best practices information for unit installation and use.
  • Page 10 VISCA OUT//RS485 Control connect VISCA OUT of the first camera to VISCA IN of the second Interface camera. DC12V 1.2A Power supply socket ■ Physical specifications Figure 3: Arrive EyePoint front and side dimensions © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 11 F2.0 - 2.8 Horizontal View 50 degrees Video Output USB 3.0, UY2 Video format YUY4 | 1920x1080 30p Control Decoder EIA/RS-485 Communication EIA/RS-232(Bi-directional) PTZ Control Protocol VISCA,PELCO-P,PELCO-D Baud Rate 4800/9600 bps Patrol tours © 2014 Arrive Systems, Inc. All Rights Reserved.

  • Page 12: Installing The Device

    Weight 800g (Net) 1300g(Package) Mounting Desktop, Ceiling / Wall mount, Standard Tripod INSTALLING THE DEVICE ■ Package contents HD Color Video Camera 12V/2.0A DC Power adaptor Installation bracket Screws IR Remote Control © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 13 STEP 4 STEP 3 Figure 4: Bracket Installation After the bracket is fixed to the camera base, the camera can be installed on the ceiling, wall or any flat surface as per requirement. © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 14 ■ Tripod installation Fix the tripod accessory to the bottom of the Arrive EyePoint™ and mount the camera on the tripod. Figure 5: Tripod Installation © 2014 Arrive Systems, Inc. All Rights Reserved.

  • Page 15: Using The Device

    Camera baud rate 9600 Protocol PTZ Control Protocol VISCA Control Camera control type RS-232C Lens Type Camera module adopted Acute/Sony Dome Type Camera model No. Vendor Manufacturer name Version Initial Factory version 2.3.4.4 © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 16 Enable/disable speed match function, Proportion Possible values: ON/OFF Image auto flip Auto Rev Vlaues: P-positive / N- inverted /OFF 1080p@30, 1080p@25,1080p@24, Frame Format 1080I60 1080i@60 1080i@50,720p@60,720p@50 Output Type HDMI/DVI Data Sequence YCBCR/YCRCB YCBCR © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 17 ON / OFF White balance Auto/Custom/Manual/Daylight Auto /Cloudy/Shade/FLW/FLN/FLD/ Tungsten Digital effect Normal/Sepia/Monochrome/ Normal Posterize/Solarize/Nega Sharpness reduction High/Middle/Low Middle Noise reduction High/Middle/Low/Off Middle Chroma key CR High/Middle/Low Chroma key CB High/Middle/Low Auto slow shutter © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 18 Device Remote Control Figure 6: Remote control © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 19 Move camera upwards Move camera downwards Move camera left Pan/Tilt control Move camera right Enable Pan movement scanning Image Freeze Freeze Backlight compensation White Balance Auto Exposure Auxiliary Digital Zoom DZOOM HDMI Format © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 20 Set left limit points for boundary scanning L-Limit Enable scanning automatically Scan Pan & Tilt Set right limit point for boundary R-Limit scanning Function area Home position of camera Home Enable touring Tour Image up-side down option © 2014 Arrive Systems, Inc. All Rights Reserved.

  • Page 21: Connecting The Camera

    Figure 7: VISCA RS-232-C IN Pin S/N Function DTR IN DSR IN TXD IN RXD IN IR Commander Signal OUTPUT NO Connection VISCA RS-232C OUT VISCA Out Reference Figure 8: VISCA RS-232C OUT © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 22 2. DSR IN 2. TXD 3. TXD IN 3. RXD 4. GND 4. RTS 5. RXD IN 5. CTS 6. GND 6. DSR 7. IR OUT 7. GND 8. N.C 20. DTR © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 23 7. RS485- 7. IR OUT 8. RS485+ 20. N.C References Note: Switch -off the power supply prior to altering the DIP switch settings. DIP-switch settings 底部拨码开关视图 Figure 9: DIP - switch overview © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 24 SW 2 Baud rate Communication Protocol DIP-1 DIP-2 DIP-3 38400bps RS-485 PELCO-D 9600bps RS-232 VISCA IR Remote control Input settings SW 2 Dip-switch status (Pin 4, Pin 5) R/C Address DIP-4 DIP-5 default © 2014 Arrive Systems, Inc. All Rights Reserved.

  • Page 25: Troubleshooting

    “ Connecting the Camera”) The camera is not Power off the camera, and restart working properly. after a few seconds. ■ Warranty Information Please visit Arrive CarePoint for updated information on warranty for non-computing equipment © 2014 Arrive Systems, Inc. All Rights Reserved.
  • Page 26 © 2014 Arrive Systems, Inc. All Rights Reserved. Arrive Systems, Inc. 6737 Katella Ave. Cypress, CA 90630, USA Toll Free: +1-844-427-7483 (USA / Canada) Email: info@arrivesys.com www.arrivesys.com...
