Summary of Contents for Mobility Works Buffalo
- Page 1 Mobility Works……. ® Buffalo OWNER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. PREFACE …………………………………………………………………………………………… 2 2. SAFETY NOTICE …………………………………………………………………………………… 4 2.1 Before Driving 2.2 Whilst Driving 2.3 Labelling 2.4 Electromagnetic Interference 3. PARTS INTRODUCTION ………………………………………………………………………… 10 4. OPERATION ……………………………………………………………………………………… 4.1 Control Panel 4.2 How to Operate Your Scooter 5. -
Page 3: Preface
We reserve the right to make design modifications. The Buffalo models is a large scooter designed and manufactured to provide a comfortable solution for some mobility requirements, they are easy to manoeuvre and are suitable for indoor and some outdoor applications. -
Page 4: Safety Notice
2. SAFETY NOTICE 2.1 BEFORE DRIVING The user needs to be familiar with the use and operation of this vehicle before driving. Therefore, please follow the recommendations in this safety notice. The same traffic rules apply to the user of this vehicle as apply to pedestrians. ... -
Page 5: Whilst Driving
2.2 WHILST DRIVING ■ Do not use your vehicle under the circumstances below. On surfaces that are muddy, gravelly, bumpy, narrow, snowed over, icy, or towpaths very near to canals which not guarded by any fence or hedge. Keep away from places where you might get the wheels stuck. ... -
Page 6: Labelling
WARNING： Do not set in freewheel mode when driving on a gradient. Always re-engage the freewheel device into drive mode before use. Failure to do so may result in injury. The Maximum User Weight Limit is 180kg. Overloading past the weight limit may lead to damage of your scooter or cause it to malfunction and will endanger your safety. - Page 7 2.4.1 ELECTROMAGNETIC INTERFERENCE (EMI) FROM RADIO WAVE SOURCES Powered scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and mobile phones. The interference (from radio wave sources) can cause the powered scooter to release its brakes, move by itself, or move in unintended directions.
- Page 8 2.4.2 POWERED SCOOTER ELECTROMAGNETIC INTERFERENCE (EMI) Because EM energy rapidly becomes more intense as one moves closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the control system of the scooter while using these devices.
-
Page 9: Parts Introduction
3. PARTS INTRODUCTION Parts Description : 1. Rearview mirror 8. Front basket 2. Control panel 9. Tiller adjustment knob 3. Freewheel lever 10. Seat post 4. Anti-tip wheel 11. Charger socket 5. Seat 12. Circuit breaker 6. Arm rest 13. Anti-tip wheel 7. -
Page 10: Operation
4.OPERATION 4.1 CONTROL PANEL Two control panels available: press-button panel and switching panel, see pictures below. 1. Rearview mirror 5. Freewheel button 9. Wigwag Paddle 2. Speed control 6. Hazard warning switch 10.Headlight 3. Key Ignition 11. LED indicator 7. Horn Button 4. - Page 11 Pull the left-hand side of the wigwag paddle towards you with your left hand and the scooter will move backward, emitting an audible reversing alarm. To brake, release the wigwag paddle which will return to neutral and activate the electromagnetic brake automatically.
- Page 12 Lift up the lever to adjust seat back angle 90degree 100degree Lever Lever Adjusting seat back angle Attention： Return the seat to the forward position before driving. Adjusting the Seat Height 1. Remove the seat from your scooter 2.
- Page 13 Suggestion： 1. You should recharge the batteries after each time the vehicle is used to ensure maximum range. The batteries should be charged up at least once a week even if the scooter is not used. 2. After charging or replacing a new battery, drive the vehicle for 2-3 minutes to make sure the battery capacity is sufficient.
- Page 14 Freewheel Mode: Pull the lever up and the scooter can be moved manually. Warning： Never operate the freewheel lever while seated on the scooter or on an incline. Tiller Adjustment The tiller can be adjusted in to many different positions to suit each driver. The tiller can be adjusted by following the steps below：...
- Page 15 Attention： 1. Do not push both RH & LH sides of the wigwag paddle simultaneously. This might leave you unable to control your scooter. 2. Do not turn the power switch to OFF whilst driving as this will lead to an emergency stop and possible risk of accident and injury.
-
Page 16: Battery Charging And Care
The circle above shows the location of the circuit breaker on the photograph (see above). Under normal operating conditions the circuit breaker button will be protruding 2mm – 3mm. If the circuit breaker has tripped, the button will be protruding by 7mm. To reset the circuit breaker,push the button in and the scooter should function as normal. -
Page 17: Charger
6. After charging, do not leave the charger socket plugged in to the scooter, as this will cause a power drain on the scooter and temporarily reduce its range. 7. The batteries carry a twelve-month manufacturer's warranty. This warranty only covers issues relating to manufacturing faults, and not faults relating to failure to recharge the batteries as instructed above. -
Page 18: Battery
6.3 BATTERY Do not expose the battery to temperatures below – 10°C or above 50°C when charging or storing the vehicle. Being out of the above temperature range can cause the battery either to freeze or over heat. This will damage the batteries and shorten their life. -
Page 19: Inspection And Maintenance
7.INSPECTION AND MAINTENANCE 7.1 DAILY CHECKING Check the following items before driving. If you find anything abnormal, contact your dealer for further inspection or advice before using the scooter. Item Inspection Tiller Is there any looseness? Can it turn left and right smoothly ? Speed Control Dial Can it be adjusted freely and does it function well? ... -
Page 20: Regular Checking Record
7.2 REGULAR CHECKING RECORD To make sure your scooter is correctly serviced, please regularly check it, if you detect any faulty, please contact your dealer timely. Below check record list (for reference). Suggestion： Even if you do not use the vehicle for a long time it should still be serviced regularly. 7.3 BATTERY, FUSE AND TYRE ... -
Page 21: Maintenance
Tyres The condition of the tyres depends on how you drive and use your scooter. Please check the tread depth and air pressure regularly. Replace the tyres when the tread depth is less than 0.5mm. Attention： 1. When tread depth is below 0.5mm it can easily lead to vehicle slippage, making braking distances longer. -
Page 22: Storage
7.5 STORAGE Ensure the scooter is stored under the following conditions: Ensure the seat is set in the ‘forward’ position; Ensure the scooter is switched off; Ensure the charger is disconnected when not in use. Suggestion： Please store the scooter in an environment where it is out of direct sunlight or damp. When storing for a long time, charge the battery to full power and then disconnect the battery terminal. -
Page 23: Specification
drops in to place and is secure The tiller appears loose Tiller adjustment knob loose Tighten the tiller adjustment knob Involuntary horn sounds There is a fault on the scooter Ensure the wigwag paddle is released and switch the scooter on and off Recharge batteries 9.SPECIFICATION... -
Page 24: Warranty
Third year: 35% replacement of parts cost One-Year Limited Warranty: For one year from the date of purchase, Mobility Works will repair or replace, at our option, to the original purchaser, free of charge, any part found upon examination by an authorized representative of Mobility Works to be defective in material and/or workmanship. - Page 25 PO Box 1208, Lalor, VIC 3075 Phone 1300 23 66 24 www.mobilityworks.net.au Scooter Manufactured By Ningbo Jiahe Special Vehicle Co. Ltd. Ningbo, Zhejang China Sold to Name ________________________________________ Address ________________________________________ ________________________________________ ________________________________________ Date ________________________________________ Model Buffalo ( JH05-228A-A ) 1200WPG140A24V55AH Serial No ________________________________________...
