German Engineered for Excellence
PLEASE READ THIS MANUAL CAREFULLY BEFORE USING THE WINE CHILLER
This appliance is intended to be used exclusively for the storage of wine
PRODUCT RANGE
PRODUCT TYPE
PRODUCT SERIAL
NUMBER
WARRANTY:
5-year warranty on anti-rust
5-year warranty on R600A Compressor
Standard 1-year warranty on manufacturing defects
PRODUCT WARRANTY REGISTRATION:
Log on to www.haustern.com for product warranty registration
FIAMMA TRADING SDN. BHD.
Wisma Fiamma, No. 20 Jalan 7A/62A, Bandar Manjalara
52200 Kuala Lumpur, Malaysia.
HT-MOSEL-165S
: WINE CHILLER
: FREESTANDING SINGLE ZONE
:
(330476-P)
USER MANUAL
1
Website: www.haustern.com
Office Number: +603-6279 8943
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hauster HT-MOSEL-165S
Summary of Contents for Hauster HT-MOSEL-165S
- Page 1 USER MANUAL German Engineered for Excellence HT-MOSEL-165S PLEASE READ THIS MANUAL CAREFULLY BEFORE USING THE WINE CHILLER This appliance is intended to be used exclusively for the storage of wine PRODUCT RANGE : WINE CHILLER PRODUCT TYPE : FREESTANDING SINGLE ZONE...
-
Page 2: Table Of Contents
USER MANUAL German Engineered for Excellence TABLE OF CONTENTS WINE CHILLER SAFETY IMPORTANT SAFEGUIDES REFRIGERANT GAS WARNINGS PARTS BREAKDOWN IMPORTANT SAFETY INSTRUCTIONS INSTALLATION INSTRUCTIONS Before using your wine chiller Installation of your wine chiller Free standing cabinet instructions Electrical connection Extension cord Powerbar with surge protector Installing stainless steel handle... -
Page 3: Wine Chiller Safety
USER MANUAL German Engineered for Excellence WINE CHILLER SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. -
Page 4: Important Safeguides
USER MANUAL German Engineered for Excellence IMPORTANT SAFEGUIDES Before the appliance is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the appliance, follow basic precaution, including the following: ... -
Page 5: Refrigerant Gas Warnings
USER MANUAL German Engineered for Excellence To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed. Choose a well-ventilated area with temperatures above 16°C (60°F) and below 32°C (90°F). This unit must be installed in an area protected from the element, such as wind, rain, water spray or drips. ... -
Page 6: Parts Breakdown
USER MANUAL German Engineered for Excellence PARTS BREAKDOWN Control Panel Top Hinge Wooden Shelves and Stainless Steel Door with Handle Telescopic Runner Kick plate Safety Child Lock Leveling Legs IMPORTANT SAFETY INSTRUCTIONS FIAMMA TRADING SDN. BHD. Website: www.haustern.com (330476-P) Wisma Fiamma, No. 20 Jalan 7A/62A, Bandar Manjalara Office Number: +603-6279 8943 52200 Kuala Lumpur, Malaysia. -
Page 7: Installation Instructions
USER MANUAL German Engineered for Excellence To reduce the risk of fire, electrical shock, or injury when WARNING using your appliance, follow these basic precautions: Read all instructions before using the wine chiller. DANGER or WARNING: Risk of child entrapment. Child entrapment and suffocation are not problems of the past. -
Page 8: Installation Of Your Wine Chiller
USER MANUAL German Engineered for Excellence This appliance is designed to be for free standing installation or flush-in. Place your wine chiller on a floor that is strong enough to support it when it is fully loaded. To level your wine chiller, adjust the front levelling legs at the bottom of the wine chiller. -
Page 9: Extension Cord
USER MANUAL German Engineered for Excellence The appliance should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating label on the appliance. This provides the best performance and also prevent overloading house wiring circuits that could cause a fire hazard from overheated. -
Page 10: Operating Your Wine Chiller
USER MANUAL German Engineered for Excellence Align the handle with the screws installed. Tighten the screws using a Phillips head screwdriver until the handle sets both flush and secured tightly against the door frame. (DO NOT over tighten as this will cause damage to the handle assembly). -
Page 11: On/Off Power
USER MANUAL German Engineered for Excellence Recommended temperature settings Wine conservation: 12°C-14ºC (53°F-57ºF) Rose and sparkling wines: 5°C-8ºC (41°F-46ºF) Dry/white wines: 9°C-12ºC (48°F-53ºF) Red wines: 14°C-18ºC (59°F-65ºF) ON/OFF Power To turn OFF the appliance, press the button and hold 2 seconds. Setting the temperature control You can select temperature display setting from Fahrenheit to Celsius degree by touching the button. -
Page 12: Interior Light
USER MANUAL German Engineered for Excellence NOTE: If the unit is unplugged, if the power is lost, or turned off, you must wait 3 to 5 minutes before restarting the unit. If you attempt to restart before this time delay, the wine chiller will not start. When you use the wine chiller for the first time or restart the wine chiller after having been shut off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the LED readout. -
Page 13: Shelves
USER MANUAL German Engineered for Excellence cloth. Do not use steel wool or steel brush on the stainless steel. These will contaminate the stainless steel with steel particles and rusting may occur. Shelves This appliance is equipped with a telescopic runner assembly (except for the bottom shelf) and you can move the wooden shelves out and in smoothly. -
Page 14: Energy Saving Tips
USER MANUAL German Engineered for Excellence Tape the door shut. Be sure the appliance stays secure in the upright position during transportation. If you absolutely need to transport the chiller horizontally, transport the chiller on its back (door on top). Also protect outside of appliance with a blanket, or similar item. -
Page 15: Troubleshooting Guide
USER MANUAL German Engineered for Excellence TROUBLESHOOTING GUIDE You can solve many common wine chiller problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE SOLUTION... - Page 16 USER MANUAL German Engineered for Excellence Check to assure that the chiller is level. The chiller is not levelled Make sure the bottles don’t touch each Vibrations. The bottles are vibrating. others. There is an object under the chiller. Remove the object. Level the chiller.
