Crown DSi 1000 Specification

T he Crown ® DSi Series of power amplifiers provides onboard
digital signal processing including crossovers, EQ filters, delay
and output limiting. A rear panel HD-15 connector provides easy
input/output connectivity between DSi amplifiers and the new DSi
8M System Monitor. All DSi amplifiers are THX
The intuitive front panel LCD screen guides installers through a
setup process—featuring presets for the industry-standard JBL
cinema loudspeaker systems—to make configuration quick and
easy. At the touch of a button, Crown's DSi cinema amplifiers de-
liver perfectly matched performance with each award-winning JBL
ScreenArray system, making this the ultimate cinema solution.
DSi Amplifier Features
• Intuitive front-panel LCD screen, automatic presets for popular
JBL cinema speaker systems for quick, easy configuration
• Onboard digital signal processing includes crossovers, EQ filters,
delay, and output limiting
• Computer connectivity via USB allows fast setup and configuration
with HiQnet TM System Architect TM software
• Rear-panel HD-15 connector provides easy input/output connectivity
between DSi amplifiers and new DSi 8M System Monitor
• Barrier strip outputs, removable Phoenix-style input
DSi 8M Features
• 25-pin D-sub connectors, plus removable terminal blocks and HD-15
for quick, hassle-free connections
• Designed to work with bi-amplified sound systems to monitor the high-
and low-frequency outputs from the left, center and right channels
®
approved.
DSi 1000
DSi 2000
DSi 4000
T he Crown ® DSi 8M is a projection booth monitor designed
to work with bi-amplified cinema systems using the Crown
DSi Series amplifiers. All controls necessary for daily operation
of the DSi 8M are easily accessible on the front panel. 8-channel
monitoring allows you to monitor either the processor or the
power amplifier's outputs: L,C, R, Ls, Rs, Bsl, Bsr, and Sub in
any combination.
Input levels from the processor and power amplifier can be
adjusted independently. There are no huge level jumps when
switching between processor and power amplifiers. The
bargraph display can be calibrated to the reference level for your
theater. The projectionist can see auditorium levels instantly.
Power Output
2-ohm 4-ohm 8-ohm
Stereo Stereo Stereo
(per channel) (per channel) (per channel)
700W * 475W 275W
1000W * 800W 475W
1600W * 1200W 650W
Maximum average power in watts at 1 kHz with 0.5% THD.
*Maximum average power in watts at 1 kHz with 1% THD.
4-ohm 8-ohm
Bridge- Bridge-
Mono Mono
1400W * 950W
2000W * 1600W
3200W * 2400W
