Summary of Contents for e-motion X32-69G-GB-TCU-UK
- Page 1 HD Ready LCD TV with Freeview & USB Media Player User Guide Model No X32-69G-GB-TCU-UK...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Warnings • To reduce the risk of fi re, electric shock or damage to the television, do not expose it to dust, rain or moisture, or place any objects fi...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Important Information Regarding Use of Video Games, Computers, Captions or Other Fixed Image Displays The extended use of fi xed image program material can cause a permanent “shadow image” on the LCD panel.
-
Page 5: Table Of Contents
CONTENTS Manufacturers Guarantee Information ........3 Important Safety Instructions . - Page 6 What is included in the box WHAT IS INCLUDED IN THE BOX Accessories Included with this TV are the following accessories: 1 x User Guide 1 x Remote Control User Guide 2 x AAA Batteries 1 x Quick Start Guide Quick Start Guide 1 x TV...
- Page 7 Attaching/Detaching the stand and wall mounting ATTACHING / DETACHING THE STAND Attaching the stand 1) Insert the stand into the base of the TV 2) Fix the screws provided into the base of the stand Detaching the Stand 1) Remove the screws in the base of the stand and the remove the TV from the stand. IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there could be any electric wires, water or gas pipes.
- Page 9 Getting Started - Initial Set Up GETTING STARTED INITIAL SET UP 1) Using the RF cable supplied, connect the TV 2) Connect the power cable to the Electrical to the TV Aerial wall socket (Fig A) outlet (Fig B) Fig B Fig A 3) Switch on the television using the...
- Page 10 TV Buttons and Source Menu TV BUTTONS & SOURCE MENU Volume up and menu right Volume down and menu left Programme/Channel up and menu up Programme/Channel down and menu down Displays Menu/OSD Displays the input source menu Standby Power On/Off Choosing Mode Input/Source To switch between the different input/ connections.
-
Page 11: Remote Control
Remote Control REMOTE CONTROL STANDBY - Switch on TV when in standby or vice versa MUTE - Mute the sound or vice versa TV/RADIO - Switch to Freeview and switch between TV and radio in Freeview mode TV GUIDE - Opens the 7 Day TV Guide (Freeview mode) ATV - Switch to analogue TV source USB - Switch to USB Source S.MODE - Scrolls through sound mode options... -
Page 12: Connections
Connections CONNECTIONS CONNECTIONS USB port HDMI 1 HDMI input HDMI 2 HDMI input HDMI 3 HDMI input VGA(PC) VGA-PC input VGA(PC) Audio In 3.5mm PC audio input CI CARD IN Common Interface Module Input SCART SCART input COAX Audio Out Digital Coax output COMPONENT (HD) Component input (YPbPr) - Page 13 Connections CONNECTIONS Connecting a Camcorder, Camera or Games Console TVs Input / Source should be set to Video Camera or Camcorder Yellow Video White Audio In L/R Connecting a High Defi nition (HD) Device Option 1 - via HDMI to HDMI cable A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio with minimal loss of quality.
-
Page 14: Tv Menu Operation
TV Menu Operation CHANNEL MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button. -
Page 15: Picture Menu
TV Menu Operation PICTURE MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button. -
Page 16: Sound Menu
TV Menu Operation SOUND MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button. -
Page 17: Time Menu
TV Menu Operation TIME MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button. -
Page 18: Feature Menu
TV Menu Operation FEATURE MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button. -
Page 19: Setup Menu
TV Menu Operation TV Menu Operation SETUP MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. -
Page 20: Pc Operation
PC Operation USING THE TELEVISION AS A COMPUTER MONITOR IMPORTANT – Before connecting the computer to the television you must ensure the computer settings are correct for the television. You MUST do this using your old monitor. How to set up for Windows XP & Windows Vista (connecting via VGA cable to the TV) 1) Switch on your computer 2) When fi... - Page 21 PC Operation PC SETTINGS To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button.
-
Page 22: Day Tv Guide
7 Day TV Guide 7 DAY TV GUIDE TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported by the freeview channel). You can view the start and end time of all programmes and on all channels for the next 7 days and set reminders. - Page 23 USB Mode / Media Player USB MODE / MEDIA PLAYER USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. Please refer to technical specifi cation page for compatible fi le types On switching to USB source the above menu screen will appear.
-
Page 24: Operating The Tv With A Universal Or Sky (Bskyb) Remote Control
General Information OPERATING THE TV WITH A UNIVERSAL OR SKY (BSKYB) REMOTE CONTROL Using a Universal Remote Control. You may wish to use a Universal Remote control to operate your Television. In order to do so, you will need to enter the ‘code’ below into your universal remote control, to do this, please follow the instructions included with the Universal remote control. -
Page 25: Frequently Asked Questions
General Information FREQUENTLY ASKED QUESTIONS General I would like to have louder There are 2 options: sound by connecting 1) Use Digital COAX output connected to an external amplifi er/surround additional speakers sound system 2) Use the 3.5mm headphone output and a 3.5mm to phono cable (available separately) to connect to an amplifi... -
Page 26: Technical Specifi Cations
General Information TECHNICAL SPECIFICATION Model X32/69G-GB-TCU-UK Screen size (diagonal) 32"/ 81cm Resolution 1366 x 768 Contrast Ratio 4000:1 Brightness cd/m2 PC RGB 75 ohm Antenna / PAL-SECAM Video Inputs 1 x SCART, 1 x Video, 1 x Component (YPbPr - 1080i), 3 x HDMI(up to 1080i) Sound Inputs 1 x 3.5mm jack for PC audio input, 1 x pair RCA Audio input shared for Video and Component (YPbPr) -
Page 27: Index
General Information INDEX Aspect Ratio ..............21 Sleep Timer ..............19 Attaching the base/stand ..........9 Sound Mode ..............18 Auto Confi guration of screen (PC) ........ 23 Source Menu ..............12 Auto Tuning ..............16 System Lock ..............20 Auto Volume Level ............ - Page 30 Version 3 FEB11 X32/MAN/0044...
