Summary of Contents for AWA MSDV2968-O5
- Page 1 MSDV2968-O5 29" 74cm HD LED LCD Television USER MANUAL Thank you for purchasing this LCD TV. Before connection and operation of this product please read the manual carefully and completely. Please keep this manual for future reference. N294 Version 1.1...
-
Page 3: Table Of Contents
Contents INTRODUCTION................1 SAFETY AND WARNINGS............. 2-4 BASE STAND ASSEMBLY INSTRUCTION..........5 WALL MOUNTING INSTALLATION GUIDELINES........5 INSTALLATION................6-9 REMOTE CONTROL..............10-11 OPERATION................12-16 ELECTRONIC PROGRAM GUIDE (EPG MENU)........17 PERSONAL VIDEO RECORDER (PVR)..........18 DIGITAL MEDIA PLAYER (DMP)............21 TROUBLE SHOOTING..............22 TECHNICAL SPECIFICATIONS............23... -
Page 4: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. CAUTION 2) Keep these instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN! 3) Heed all warnings. CAUTION 4) Follow all instructions. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO 5) Do not use this apparatus near water. NOT REMOVE COVER (OR BACK). - Page 5 SAFETY AND WARNINGS Never stand on, lean on, or suddenly push the High voltages are used in the operation of this television or its stand. You should pay special television receiver. Do not remove the cabinet attention to children. Serious injury may result if it back from your set.
- Page 6 SAFETY AND WARNINGS CAUTION Never tamper with any components inside the TV, or any other adjustment controls not mentioned in this manual. All LCD-TVs are high voltage instruments. When you clean up dust or water drops on the LCD PANEL or CABINET, the power cord should be physically removed from the mains outlet. You may then wipe the TV with a dry soft cloth.
-
Page 7: Base Stand Assembly Instruction
INSTALLATION Base Stand Assembly Instruction Place the TV with the display side down on a flat surface. Ensure the table or desk you use provides a flat, totally clean surface. Use a cloth between the face of the TV and the table to protect the TV's screen. 1. -
Page 8: Installation
INSTALLATION Front panel Remote control sensor. Indicator LED: BLUE = POWER ON. = Stand-by. Key board (on side of TV). Main power switch (on bottom p a n e l of TV) The remote control needs to be pointed directly, within +/- 30 , of the sensor on the front of the TV for reliable operation. - Page 9 INSTALLATION REAR AV Connections AV INPUT AV OUTPUT AC-INPUT 100-240V~50/60Hz YPbPr VIDEO VIDEO All the terminals are (from left to right): AC POWER INPUT, YPbPr (component video) inputs, AV input (composite video and L+R audio), AV output (composite video and L+R audio). Note: 1.
- Page 10 INSTALLATION HEADPHONE STEPS: HDMI2 HDMI1 Be sure both the TV and computer are set to Power off. 1.Connect a VGA and audio cable. 2.Connect the power cord. 3.Power on the TV, switch to PC mode. 4.Power on the PC. This connection and power-up sequence VGA and audio cable not supplied is very important.
- Page 11 INSTALLATION AV EQUIPMENT You can use the input and output terminals on the TV set as follows. HEADPHONE HDMI2 HDMI1 HDMI VIDEO EQUIPMENT with YPbPr output (Component video output) Yellow (Composite video) White (audio L) Red (audio R or Pr) Blue (Pb) Green (Y) Component video...
-
Page 12: Remote Control
REMOTE CONTROL REMOTE CONTROL REMOTE CONTROL POWER :To set the TV to standby or power on. :In USB mode, used as reverse key, in teletext mode used as subpage key. : In USB mode, used as forword key, in teletext mode used as reveal key. - Page 13 REMOTE CONTROL TELETEXT Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.) Press: You will obtain:...
-
Page 14: Operation
OPERATION Installation Guide Please select an OSD Language Country Cesky English Magyar Polski Fran ais Australia Bulgaria Denmark Germany Italy Espanol Dansk Hrvatski Nederlands Portugues Austria Croatia Finland Greece Luxembourg Deutsch Italiano Norsk Pycck Belgium Czech France Hungary Netherlands This screen only appears when the TV is turned on for the first time, or reset to factory settings. You can choose language, country and auto tuning programs. - Page 15 OPERATION 2).DTV Manual tuning: You can select a DTV channel then find the program in this channel. Press to select the channel, then press OK to search the programs . NOTE: The Bad Normal Good bar graph on this screen shows signal intensity during DTV reception only. DTV Manual Tuning VHF CH Press OK to search...
- Page 16 6). Software Update: WARNING: Do not attempt to use this option unless you have a valid software program for the MSDV2968-O5 TV stored on a compatible USB drive, and the drive is connected to the TV. Please remove " "...
- Page 17 OPERATION 5.OPTION MENU To enter the Option Menu, press MENU button and then press buttons to select the Option Menu. Once in Option Menu, press buttons to select the settings you wish to adjust. Press MENU button to return to the Main Menu. OSD Language English Audio Languages Subtitle Languages...
- Page 18 OPERATION FACTORY RESET NOTE: If you wish to reset your TV, please select the Restore Factory Default option, this will clear all settings. 6.LOCK MENU To enter the LOCK Menu, press MENU button and then press buttons to select the LOCK Menu. The default password is 6666.
-
Page 19: Electronic Program Guide (Epg Menu)
OPERATION 8.EPG Menu (Electronic Program Guide). The EPG Menu is used to look at what is being broadcast by DTV stations. After you turn the TV on and select the DTV input, your TV will commence receiving EPG data progressively over a period of time (typically up to half an hour, depending on the number of stations being received). -
Page 20: Personal Video Recorder (Pvr)
OPERATION 9. PVR function 1). Prepare to record the program From OPTION MENU enter into the PVR File System and choose "check PVR File System". Click "OK", and wait until "checking" changes into "Success". Note: please check the result marked "Speed". If it is "HD support", that means the speed of your USB device is suitable for time shift and record functions. - Page 21 OPERATION Format disk Format disk Format disk Do not unplug USB device. Warning! All data will be lost. Formatting,please wait Start Exit When the Format process has finished, you can then run the “Check PVR File System” option to show the speed ability of your USB storage device.
- Page 22 OPERATION 10. Timeshift function Prepare to record the program This TV allows you to pause and record the currently watched digital TV program to a USB storage device, and to resume viewing at the point where it was paused. NOTE: Formatting a USB 2.0 storage device will be needed.
-
Page 23: Digital Media Player (Dmp)
OPERATION 11. Digital Media Player (DMP) To play and view low data-rate USB media files as well as DTV recordings made using this TV, use the DMP function that is accessible from the Applications Menu. For playback of high data-rate media files the use of an external Media Player is recommended. -
Page 24: Trouble Shooting
TROUBLE SHOOTING Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction Ghost Normal audio or connection electronic equipment, car/ Interference Noise motorcycle, fluorescent light Volume (check if mute is activated or if the audio system Normal Picture connections are not correct) Mute... -
Page 25: Technical Specifications
SPECIFICATIONS LCD : Viewing Picture Size (diagonal) 29" (74cm) Resolution 1366x768 Aspect Ratio 16:9 Display colours 16.7M Brightness 290 cd/m Contrast ratio 3000:1 Response time 9.5ms View angle (max) 160(H)/150(V) Digital TV: DVB-T TV system Analog TV: PAL Audio: MPEG2 Audio Layer I&II DVB-T decode Video: MPEG2 Transport MP@HL Demodulator : COFDM...
