- Page 1 Service manual Refrigerator service manual Double door serial MODEL :RD-42WC4SFY(BCD-325WYHCE) Refrigerator (freezer) Double door serial...
-
Page 2: Table Of Contents
Service manual Content 1.Safety precautions ………………….………………………………………… 3~3 2.Specification…………………………………………………………………..4~4 3.Parts identification…………...………………………………………….………5~5 4.Refrigeration system diagram………….………………………….……….……6~6 5.Circuit diagram…………………………………………………………………6~6 6.Maintenance service and Troubleshooting …………..………………………. 7~10 7.Quality information report……………………………….………………...…11~11 8.Exploded view and part list………………………………………….…..…12~15 Refrigerator (freezer) Double door serial... -
Page 3: Safety Precautions
Service manual 1.Safety precautions Please read the following instructions before servicing your refrigerator. 1)Check the refrigerator for current leakage. 2)To prevent electronic shock, unplug before servicing. 3)Always check line voltage and amperage. 4)If you use any kind of appliance, check regular current. voltage and capacity. 5)Don’t touch metal products in the freezer with wet hands, this may cause frostbite. -
Page 4: Specification
Service manual 2.Specification Model No. RD-42WC4SFY(BCD-325WYHCE) Type Bottom-mounted no-frost refrigerator/freezer Capacity Total/ (L/Cu.Ft.) 325(11.5) Freezer/ (L/Cu.Ft.) 93(3.3) Refrigerator/ (L/Cu.Ft.) 232(8.2) Performance 、 、 、 Climatic type N, ST, T Power V/Hz 220~240/50 Features General Temp. Control(Electronic/Mechanical) electronic Features Defrosting(Automatic/Manual) automatic... -
Page 5: Parts Identification
Service manual 3.Parts identification [Refrigerator] [Refrigerator] Door rac k co ver Control panel Door rac k Lamp p ort (Inside) Egg rack (inside) Door switch Air o utlet glass shelf Door rac k Vegetable drawer Crisper cover Door rac k Crisper [Freezer] [Freezer]... -
Page 6: Refrigeration System Diagram
Service manual 4.Refrigeration system diagram when the refrigerator is just powered on. The refrigerant flows in the sequence: Compressor Condenser Dry filter Capillary tube Evaporator . 5.Circuit diagram The electronic-controller directly controls the start and stop of compressor and hence the refrigerator temperature. -
Page 7: Maintenance Service And Troubleshooting
Service manual 6.Maintenance service and Troubleshooting. DEFECT EFFECT CAUSE REMEDY Group Evaporator dose not frost even though An empty refrigerant system indicates Leakage must be partially or motor-compressor runs continually. a leakage of R600a.this loss is eliminated by completely generally to be looked for at the re-soldering the out of soldering points connecting the... - Page 8 Service manual compress permit the piston to suck and and then proceed compressor the which consequentely with refilling. dose not circulate in the system. Noisy In case of mechanical failure in the The cause of the excessive noise is motor-comp motor-compressor there in an excessive normally to be sought for in a motor-compressor...
- Page 9 Service manual compressor runs Frost doesn’t form at the evaporator Refrigerant leaks poor Repair when operating set for more than compressing compressor 30min Power source separate the PTC-starter from the Equal applied compressor and measure the voltage voltage(rating voltage ±10%) between M and C of the compressor The applied voltage is not in the Advice the customer to use in...
- Page 10 Service manual Poor starting or First, separate the PTC from the compressor and no operating of check the voltage between NO 5 and 6 in the the compressor PTC with a multitester or Wheatstone bridge The value is in the range of Check another Normal.
-
Page 11: Quality Information Report
7. Quality information report Quality information Thank you very much for purchasing Kelon products. In order to provide you with more satisfied products, please kindly fill in the questionnaire as the items indicated below. We shall strive for best to optimize our 。...
