SHAREBOT Kiwi-3D User Manual

Hide thumbs Also See for Kiwi-3D:

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kiwi-3D and is the answer not in the manual?

Questions and answers

Related Manuals for SHAREBOT Kiwi-3D

Summary of Contents for SHAREBOT Kiwi-3D

  • Page 3 USER’S MANUAL SHAREBOT Kiwi-3D...
  • Page 4 ATTENTION – EXTRUDER The fusion and extrusion system of the thermoplastic filament requires a heated end up to tempera- tures of 250 degrees and more. The contact, even for a very limited time, with the heated part causes burns. You must avoid to put your hands or other body parts in the printing area when printing and for minutes after the printing process is over.
  • Page 5 Summary Chapter 1 – Preliminar operations Open the package Positioning the printer Assembling the reel-carrier Unlocking the extruder Chapter 2 – Process of 3D Printing Model Downloading from internet From a 3D model to a printing file A good STL, a good slicing, a good print Printing file Storing the files Chapter 3 –...
  • Page 6 Chapter 4 – Setting the printer Loading the filament Preparing the printing plate Learning to set up the plate - Calibration - Regulating final leg of axis Z Calibrating axes X and Y - Recovering of scraps and usage of M99 - Squaring off axes X and Y Putting in tension the extruder’s rubber bands Chapter 5 –...
  • Page 7 Chapter 7 – Material and printing plate How ABS entails How PLA entails How other materials entai Capitolo 8 – Considerations about the model orientation Orientation Just one object? Supports Printing details Capitolo 9 – Ordinary manutention Cleaning the printer - Printing bed - Stretcher - Nozzle...

  • Page 8: Support Policies

    Sharebot: in the latter case we will provide you with a quote to request your consent to repair.

  • Page 10: Technical Characteristics

    Technical characteristics Printing technology: Fused Filament Fabrication Mono extruder printing volume: 140 x 100 x 100 mm +/- 5mm Theorical positioning resolution axes X and Y: 0,06 mm Positioning resolution axis Z: 0,0025 mm Extruder hole diameter: 0, 35 mm Filament to be extruded diameter: 1,75 mm PLA best extruding temperatures: 200-230°...
  • Page 11 Anatomy of a Sharebot NG Your professional 3D printer Sharebot Kiwi-3D is a tool of precision, ideated, developed and assem- bled in Italy by qualified staff. Before leaving the factory it was submitted to a quality control and to a quality test that guarantees its operation.
  • Page 12 1. Extruder 2. Extruder’s cables 3. Printing strand’s power hole 4. Material fan of cooling 5. Printing bed regulation screws...
  • Page 13 1. SD Card entry...
  • Page 14 1. Power cable socket 2. Label with Identification Code...

  • Page 15: Opening The Package

    Opening the package Your Sharebot Kiwi-3D is equipped with a series of accessories that allow you to make it immediately operative; there is no software because it is open source and constantly updated. Software must be downloaded from the website of Sharebot to always have the latest version.
  • Page 16 Assembling the reel-carrier For assembling the reel-carrier please see chapter 3, figures 9, 10 and 11 of the manual Assembly, recalling that the wire must carry out unhindered and in the direction of the extruder. Unlocking the extruder To avoid damage during transport, the blocking of the extruder is secured with clamps. The clamps must be carefully cut and removed to allow the extruder to move freely.
  • Page 17 Process of 3D Printing Before you start printing with your Sharebot NG it is important to understand how you arrive at a finished object. This allows you not only to know what you need to do to give form and substance to your ideas, but it helps you to identify any constraints and limitations of the technology used by this printer.
  • Page 18 Downloading from internet The net offers many ready-made 3D models, but also in this case there are differences between the models that you “see fine” and those who “print well”. A good indicator of the ability to print the pattern is of the form: the most popular 3D printing is STL (sites that intend to offer printable objects use this format).
  • Page 19 From a 3D model to a printing file The real “secret” of three-dimensional printing is the transformation of three-dimensional object into a sequence of two-dimensional slices that overlaping, reconstruct the object. Imagine a series of slices of bread: If the stack rebuilt the loaf from which they were cut. In the case of 3D printing every slice may consist of two-dimensional shapes not connected together as it is their sum to create the finished object.
  • Page 20 G-Code, a G-Code files is definitely running for the printer for which it was created but could be unus- able with other printers. If it is not clearly compatible with NG Sharebot there try to print files that you find on the net because they may have malicious entries to your printer.
  • Page 21 Storing the files As we have seen, the process consists of the stages of modeling, creation of STL files, slicing into a G- Code file and print. We recommend that you save the template file in the native format of the 3D mod- eling program, so as to keep any primitives that compose the object.

  • Page 22: Chapter 3 Lcd Panel

    Chapter 3 LCD Panel Sharebot Kiw-3D is a printer that supports both stand-alone operation and control from one com- puter (OS X, Windows or Linux). In both cases the LCD Panel provides functions both for consultation which edited. Informative mode...
  • Page 23 To the right of the display is a knob which rotates with small clicks and can be pressed as a button. With this knob you can interact with Sharebot NG: clockwise you decrease the selected value, turning it anti-clockwise will increase.
  • Page 24 Main Menu Disable engines Auto Home Preheat Cool Move Axes Change Wire “Adapt” Menu The item appears only when the printer is performing a job playing the G-Code, just by printing this article appears as first in the list when you press the knob. Main Menu Speed Nozzle...
  • Page 25 rent thread and the internal buzzer is activated as soon as the extruder is unloading. When you have positioned the new wire on the inlet hole and you did it so it hit the drive sprocket, you must press the knob to start dragging and extrusion which reloads the casting chamber and also allows you to expel the remnants of previous material.

  • Page 26: Setting The Printer

    Chapter 4 Setting the printer Your Sharebot Kiwi-3D is a mechanical device built with care both in design and in the Assembly. To keep it in a State of optimal functioning is necessary to compensate for some normal processes of adjustment, for example, due to repeated thermal cycles of extruder motors.
  • Page 27 Preparting the printing bed We remove the clothespins from the glass and extract it from the printer. Sprinkle over a thin layer of spray evenly up to cover the entire surface (light you will have a shiny effect). Now we await the complete lacquer drying and glass are placed on printing and secure it with pegs.
  • Page 28 Calibration The steps in the installation manual chapter 3e, figures 14 and 15, consists in printing of rectangles made with one layer on top, allowing you to assess the adhesion of the material to the print and to figure out if the plan is leveled properly observing the extrusion width must be equal at all points of the perimeter.
  • Page 29 CAD drawn, tolerances don’t fit together properly, it is probably necessary to calibrate the X and Y axes on your printer. The possible X and Y calibrations on your ShareBot NG are of two types, software or hardware: - Recovering of scraps and usage of M99 (software calibration) If you have a scrap on a strap of one of the two axes you will recognize it by checking any hole or circle printed.
  • Page 30 PONTE Y FUORI SQUADRA Putting in tension the extruder’s rubber bands Your Sharebot Kiw-3D is equipped with a cushioned versus pulley sprocket wire drag. This solution allows to compensate for thickness variations that some filaments can have, allowing you to bring the press anyway.
  • Page 31 To work around this limitation, Sharebot Kiwi-3D allows you to select, before printing, the outline of the material that we use. In this way we can create generic G-Code to be printed with the chosen material simply by choosing the corresponding profile.

  • Page 32: Starting The Print

    Pressing the knob you select for printing. Your Sharebot Kiwi 3D will begin with the heating phase and by positioning at the origin of the axes, then when it reaches the temperature you do in a central area of the print and will start with the first layer.
  • Page 33 Modifying printing parameters One of the features of Sharebot NG is the ability to intervene on a number of parameters while printing is in progress. The “Adapt” menu becomes available instead of the “Prepare” (see Chapter 3): This allows you to adapt the selected profile PLA or normal to their compatible materials for behavior and characteristics (v.
  • Page 34 ficient to cause a burn. look at the temperature on the display and absolutely avoid any contact with it if the value indicated is higher than 50 degrees. If in doubt, do not detach the piece until the temperature has dropped to safe levels before you put your hands inside the printing area.
  • Page 35 At this point it is necessary to define the parameters for the printer. In order to simplify the process we have made available on the site, in the same download section, the printer profile Sharebot Kiwi 3D that we invite you to download. After that, choose “load config ...” from the File menu; in the folder “profiles”...
  • Page 36 Basic parameters of Slic3r As we’ve seen, Sharebot Kiwi 3D allows you (thanks to Normal and Pla profiles) to generate a G-Code by setting only the geometric parameters of our interest: you can create not specific G-Code for individual materials, leaving then set all the parameters of temperature, fans, etc., to determine the material to be...
  • Page 37 alization of printing, the lower the fill faster printing. Obviously with a low filling will have a lighter piece and brittle. For this the fill parameter can be varied depending on the outcome you want to achieve. The entry “fill pattern” lets you choose from a drop down menu the texture that you want to fill areas to the (straight, hexagonal, etc.).

  • Page 38: Chapter 7 Materials And Printing Plate

    Chapter 7 Materials and printing plate One of the most critical elements in current 3D printers is the superficial treatment of the printing plate. When you extrude the filament, the first layer is crushed by the brass tip on the surface of the plate;...
  • Page 39 How PLA entails This material, created by processing the pulp plant waste rich in cellulose, comes from many pre- ferred over to ABS, although most subject to high temperatures (over 60° tends to become slack). Printing between 195 and 230 degrees, depending on the additives that have been added to color it and modify its physical and mechanical properties.
  • Page 40 Chapter 8 Consideration about model orientation The possibilities offered by your Sharebot Kiwi-3D are very broad, but like all technological tools, this must be understood and used by applying various measures over time more and more sophisticated. 3D printing technology, promises to create any shape but are frequent cases where a print ends with a big disappointment.
  • Page 41 Just one object? There are cases when printing in one piece is inevitable, but there are as many cases where you can cut into several parts the object to print more easily. An example that you often see on the internet is that the Eiffel Tower: for his height would print a whole small object and with details too tiny to be created from most printers FDM.
  • Page 42 In professiona printers supports are manufactured using special thermoplastic, possible to dissolve through special chemical or thermal baths, filed with a second extruder. Even with Sharebot NG, du- al-extruder version, you can use as supporting material of the “Poly” (polyester) limomene soluble in combination ABS for printing.
  • Page 43 Each type of object has its own range of optimum thickness for printing and only with a bit of experi- ence you can intervene on this knowing what parameter are you going to actually meeting. Our tip is to choose a small enough, but with an articulated form, upon which to pursue a systematic experi- mentation, thanks to which you will be able to see the effect of each variation.

  • Page 44: Cleaning The Printer

    Ordinary Manutention Cleaning the printer Sharebot Kiwi-3D does not require any special maintenance, but, like all machinery, efficiency in- creases if kept clean. - Printing bed: the first layer of the object we print is essential to the success of the press: for this rea- son the printing floor must be perfectly smooth, with a uniform layer of lacquer applied.
  • Page 45 A correct ventilation Your Kiwi-3D is equipped with a cooling fan devoted to electronics, located at the lower left on the front seat: you will notice that when the printer is turned on and stays on at all times. It should make sure that dust or other debris do not obstruct the forced cooling of electronics, blocking in the long run also the functioning of the fan.
  • Page 46 Sito web: www.sharebot.it Sharebot s.r.l company. cannot be held responsible or liable for damage caused by incorrect use of the documentation. To avoid incorrect manoeuvres which could cause danger to persons it is important that you read and understand all the documentation in support of the SHAREBOT NG.
  • Page 47 1.1 Personal details This use and maintenance manual is an integral part of the SHAREBOT KIWI-3D (identified in this document, the term machine) realized by the firm Sharebot srl; for this reason, it must follow the machine itself if it is transferred to a new user or owner.
  • Page 48 1.4.4 Personal means of protection and rules of conduct For each of the operations described in this manual are given protection means that the user is obliged to use and the rules of conduct to safeguard the safety of users themselves. 1.4.5 Machine status The status of the machine is the characteristic that describes both the mode of operation (for example, vehicle shutdown) as well as the status of these securities (for example, including guards, guards excluded, isolated from the power supply).
  • Page 49 2.3.1.3 ATTENTIONS TO FOLLOW DURING LIFTING AND TRANSPORTING During lifting and transport it is necessary to follow the precautions described in this paragraph. - Check and if necessary so that all parties can move are correctly attached. - Do not lift, for any reason, the various parts of the machine by grasping them for non-structural elements (e.g., cables and casings). 2.3.2 Installation and connections 2.3.2.1 RISKS PRESENT DURING INSTALLATION AND CONNECTION During connection setup and there are risks associated with:...
  • Page 50 2.3.3.4 ATTENTIONS TO FOLLOW WHILE USING THE MACHINE During use of the machine it is necessary to follow the precautions described in this paragraph - Operate the machine only if all devices for protection and safety are integrated. - Do not remove, for any reason, devices and security guards installed. - Follow all safety warnings and hazards affixed on the machine.
  • Page 51 Under conditions of use in accordance with manufacturer’s instructions in this manual, the vibrations are not such as to give rise to dangerous situations. The operator however, if vibrations occur, must stop the machine immediately and report the problem in writing to the manufacturer’s assistance service sup- port@sharebot.it 2.6 Proper and improper use of the printer The machine is designed and created for the purpose of creating prototypes and objects in three dimensions, starting from a technical drawing.
  • Page 52 The use of the machine to perform operations other than those described above may only be carried out after consulting the SHAREBOT S.R.L. and with the written consent of the same. The machine has been designed and built to work in environments where there is a potentially explosive atmosphere and by itself cannot generate a potentially explosive atmosphere.
  • Page 53 3.3. Installation WARNING: the manufacturer declines all responsibility for damages to things and/or people resulting from improper interventions carried out by unqualified, untrained or unauthorized use. To perform the task under consideration requires the following personal protective equipment: Please refer also to the instructions regarding the residual risks and specific warnings. 3.3.1 Connection to electricity supply WARNING: make sure that the circuit-breaker/isolator on the printer is in “0”...
  • Page 54 NOTE: for more detailed information about troubleshooting or solve any other problems check the how-to section on the website www.sharebot.it. Refer to how-to sections of the web site www.sharebot.it to learn whether text that you will also find videos on channel SHAREBOT on youtube.
  • Page 55 disconnect the machine and remove the plug in the wall. clean the machine. Perform even routine maintenance operations and cover the machine with a cloth. If necessary, disassemble and dismantle the machine, perform the steps below. Disconnect the machine and remove the plug in the wall. Disconnect and store the parts in environmental impact, namely: a.
  • Page 56 Sharebot S.r.l. Via Montello, 18 23895 Nibionno (LC) info@sharebot.it...
