WARNING

Improper installation, adjustment,

alteration, service or maintenance

can cause injury or property

damage.

Read the assembly, operation

and maintenance instructions

thoroughly before assembling

or servicing this equipment.

DANGER

Failure to follow these

instructions could result in fire

or explosion that could cause

property damage, personal

injury or death.

DANGER

DO NOT use gas grill for indoor

cooking or heating. TOXIC fumes

can accumulate and cause

asphyxiation. DO NOT use in or

on boats or recreational vehicles.

PROP 65 WARNING

Chemicals known to the state of

California to cause cancer, birth

defects or other reproductive

harm are created by the

combustion of liquid propane

gas

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only.

(outside any enclosure)

SLG2006B

Owner's Manual

4-Burner LP Gas Grill

SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT

FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM

OR HER TO SAVE FOR FUTURE REFERENCE.

FOR CUSTOMER SERVICE, EMAIL TO

SERVICE@PYROMAGICBBQ.COM

CALL 1-877-885-8227 (TOLL-FREE),

6 A.M. – 5 P.M.(PST),MONDAY-FRIDAY.

ITEM # 13133

Printed in China

Table of Contents

Need help?

Do you have a question about the SLG2006B and is the answer not in the manual?

Questions and answers

Summary of Contents for Perfect Flame SLG2006B

Page 1 FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM FOR YOUR SAFETY: OR HER TO SAVE FOR FUTURE REFERENCE. FOR CUSTOMER SERVICE, EMAIL TO For Outdoor Use Only. SERVICE@PYROMAGICBBQ.COM (outside any enclosure) CALL 1-877-885-8227 (TOLL-FREE), 6 A.M. – 5 P.M.(PST),MONDAY-FRIDAY. Printed in China SLG2006B Owner’s Manual...
Page 2 • If odor continues, immediately call your gas supplier or fire department. Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use this gas barbecue grill, to prevent possible bodily injury or property damage. SLG2006B Owner’s Manual...
Page 3: Table Of Contents
Operating Your Grill .....................14 Propane tank Connection ........15 Checking for Leaks ..........15 Lighting Your Grill ..........15 Excess flow safety valve reset procedure …….…17 Care and Maintenance .........18 Award Winning Barbecue Recipes ..............19 Troubleshooting ....................20 Warranty Program ....................22 SLG2006B Owner’s Manual...
Page 4: For Your Safety
Move gas hoses as far away as possible from hot surfaces and dripping hot grease. Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. SLG2006B Owner’s Manual...
Page 5 Step 3 Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. GENERAL INFORMATION 1. A propane gas cylinder is required for operation. 2. This gas grill is NOT intended for commercial use. SLG2006B Owner’s Manual...
Page 6: Illustrated Parts List
12. Heat plate-----------4pcs Assembly------------1pc 13. Cooking Grid---------2pcs 14. Warming Rack------1pc 15. Grease Pan --------1pc 16. Cup Support---------1pc 17. Grease Cup------------1pc 18. Tank Clip-------------1pc 19. Rotisserie Motor 20. Side Burner Support --------------1pc Knob-----------------1pc 21 Side Knob Support------1pc 22. Basket----------------1pc SLG2006B Owner’s Manual...
Page 7: Hardware List
M6 Washers 14pcs M4 Nuts M4 Washers 3pcs 6pcs M6 Nuts 2pcs M4x16 mm Bolts 2pcs Screwdriver M4 x29 mm Screw Studs Hardware listed above is not scaled to exact size (A screwdriver is included for your convenience.) SLG2006B Owner’s Manual...
Page 8: Assembly Instructions
Go back to tighten all the bolts with the screwdriver provided. Step 2 Loosen four back panel bolts (pre-attached) and insert the back panel (4). Tighten four panel bolts by hand until secure. Go back to tighten all the bolts with the screwdriver provided. SLG2006B Owner’s Manual...
Page 9 Second Step: Insert the pin on top of the right door in the right side of the cart front beam. Repeat the same procedure for the left door (6-2). SLG2006B Owner’s Manual...
Page 10 M6 washer (E) into each hole on left sides of the body assembly. Tighten by hand until secure. Repeat the procedure for right side of the body assembly. Go back to tighten all the bolts with the screwdriver provided. SLG2006B Owner’s Manual...
Page 11 Screw a M4x16mm bolt (I) and a M4 washer (G) into each pre-drilled hole. Tighten the bolts with the screwdriver provide. Insert the side burner knob (20) into knob shaft on valve. SLG2006B Owner’s Manual...
Page 12 Insert the M4 washers ((G) on the bolts end and screw the M4 nuts (H) into bolts by hand. Go back to tighten all the bolts with the screwdriver provided. Step 10 Connect the ignition cable with the electrode. Make certain the connection is secure. SLG2006B Owner’s Manual...
Page 13 Insert a M6x15mm bolt (A) into each hole. Insert a M6 washer (E), a spring washer (D) and a M6 nut (J) into end of each bolt. Tighten all the bolts with nuts with the screwdriver provided. SLG2006B Owner’s Manual...
Page 14 Place the gas tank on the tank support and clip it with the clip. Connect the tank with regulator by screwing the collar onto the tank valve. (See diagram below) Make certain they are connected securely. SLG2006B Owner’s Manual...
Page 15: Operating Your Grill
Never store a spare propane cylinder in the vicinity of this grill, or in the vicinity of another potential heat source. Never fill the propane cylinder beyond 80% full. Warning: Do not store spare gas cylinder in or near grill. SLG2006B Owner’s Manual...
Page 16: Propane Tank Connection
If the burner does not light, return the control knob to the “OFF” position immediately. Wait five minutes for the gas to clear and repeat the procedure. After burner is lit, repeat the procedure with any other burner desired. Adjust control knob(s) to desired cooking temperature. SLG2006B Owner’s Manual...
Page 17 FIG. B FIG. C Normal: Soft blue flames Out of adjustment: Noisy hard Poor combustion: Wavy, with yellow tips between 1 blue flames – too much air. yellow flames- too little inch - 2 inches high. air. SLG2006B Owner’s Manual...
Page 18: Excess Flow Safety Valve Reset Procedure
12. After the first front burner is lit, turn on the other control knob(s) to the HIGH position. **If you have more than two burners, ONLY turn them on ONE AT A TIME. 13. When all front burners are lit, close the BBQ lid 14. Wait for 10-15 minutes, the temperature should reach 400 – 450 F° SLG2006B Owner’s Manual...
Page 19: Care And Maintenance
Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Check to ensure the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi). Also, check position of spark electrode. SLG2006B Owner’s Manual...
Page 20: Award Winning Barbecue Recipes
Prepare: marinade while they cook. Cooking times will Combine all ingredients and marinate steak for 7-8 vary according to the vegetables chosen. hours. Remove meat from marinade and grill over very high heat to desired doneness. SLG2006B Owner’s Manual...
Page 21: Troubleshooting
Burn grill for 15 minutes with the lid closed manufacturing oils. Spider webs or insect nest in venturi Clean venturi. Food residue, grease or seasoning Clean burner. salt on burner. Poor alignment of valve to burner Assure burner venturi is properly engaged venturi. with valve SLG2006B Owner’s Manual...
Page 22 If flames are blue and noisy – close flap at flames. the end of the venturi tubes in 1/8” increments until flames are correct. *Propane Models must be open a minimum of 1/8” *Natural Gas Models must be open a minimum of 1/16” SLG2006B Owner’s Manual...
Page 23: Warranty Program
If you have any questions related to the product or warranty, please call our customer service center at 1-877-885-8227, 6:00 AM to 5:00 PM (PST), Monday through Friday. Manufactured by: Lucas Innovation Inc. Xiekeng District, QingXi Town, Dong Guan, Guang Dong, China Printed in China SLG2006B Owner’s Manual...
