Summary of Contents for Allied GE1050
- Page 1 GE1050 / GE1050C Technical Manual 700052A Updated September 15, 2010 Allied Vision Technologies Canada Inc. 101-3750 North Fraser Way Burnaby, BC V5J 5E9 / Canada...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ......................ii Introduction ......................5 Precautions......................5 Warranty ......................... 5 Specifications ......................6 Supported Features ....................7 Mechanical ......................8 Connections ......................9 Cleaning the Sensor ....................14 Adjusting the C-mount ....................15 Camera Installation ....................16 System Optimization .................... - Page 3 Allied Vision Technologies customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Allied Vision Technologies for any damages resulting from such improper use or sale.
- Page 4 Contacting Allied Vision Technologies • Technical information: http://www.alliedvisiontec.com • Support: support@alliedvisiontec.com Allied Vision Technologies GmbH (Headquarters) Taschenweg 2a 07646 Stadtroda, Germany Tel.: +49.36428.677-0 Fax.: +49.36428.677-28 e-mail: info@alliedvisiontec.com Allied Vision Technologies Canada Inc. 101-3750 North Fraser Way Burnaby, BC, V5J 5E9, Canada...
-
Page 5: Introduction
Introduction The GE1910 series of cameras are sensitive, 32 frames per second, HDTV resolution, Gigabit Ethernet cameras based on the Kodak KAI-02150 CCD sensor. Precautions READ INSTALLATION GUIDE CAREFULLY. This document contains specific information which is necessary for the correct operation and treatment of this product. -
Page 6: Specifications
Specifications Sensor Type Kodak KAI-02150 Sensor Shutter Type Progressive Interline Image Resolution 1920 x 1080 pixels Pixel Size 5.5μm x 5.5μm Optical Format 2/3 inch Lens Mount C-mount with adjustable back focus † Color Sensor Filter Pattern Bayer Full Resolution Frame Rate 32.8 fps Frame Rate (640 x 480 ROI) 56.5 fps... -
Page 7: Supported Features
Supported Features Imaging Modes free-running, external trigger, fixed rate, software trigger Fixed Rate Control 0.001 fps to maximum frame rate External Trigger Delay 0 to 60 seconds in 1 microsecond increments External Trigger Event rising edge, falling edge, any edge, level high, level low Exposure Time 10 microseconds to 60 seconds in 1 microsecond increments Gain... -
Page 8: Mechanical
Mechanical Figure 1. GE SERIES mechanical dimensions. GE1910 Technical Manual Page 8... -
Page 9: Connections
Connections Figure 2. GE SERIES connection diagram. GE1910 Technical Manual Page 9... - Page 10 Item 1: GIGABIT ETHERNET PORT This port conforms to the IEEE 802.3 1000BASE-T standard for Gigabit Ethernet over copper. It is recommended that CAT5E or CAT6 compatible cabling and connectors be used for best performance. Cable lengths up to 100m are supported. Item 2: General Purpose I/O PORT FUNCTION Trigger Input...
- Page 11 Sync Out 2 and Sync Out 3 These signals only function as outputs and can be configured as follows: Exposing Corresponds to when camera is integrating light. Trigger Ready Indicates when the camera will accept a trigger signal. Trigger Input A relay of the trigger input signal used to “daisy chain”...
- Page 12 Item 4: Mini-SMB Sync Out 1 This Mini-SMB port on the camera uses an Amphenol 903-406J-51R connector. A suitable mating cable connector is Amp 413985-3 which can be used with RG174 coaxial cable. Contact AVT to purchase cabling. This connector is particularly useful for triggering multiple cameras in a “daisy chain” fashion. The Sync Out 1 signal can be configured as follows: Exposing Corresponds to when camera is...
- Page 13 Item 7: AUXILIARY POWER PORT This port is required to provide power to the camera. This port provides threaded captivation of the power cable if required. The captivated cable mating connector is the Switchcraft 760K. This connector can be purchased from AVT or from http://www.digikey.com.
-
Page 14: Cleaning The Sensor
Cleaning the Sensor DO NOT CONTACT CLEAN SENSOR UNLESS ABSOLUTELY NECESSARY. Identifying Debris Debris on the image sensor or optical components will appear as a darkened area or smudge on the image that does not move as the camera is moved. Do not confuse this with a pixel defect which will appear as a distinct point. -
Page 15: Adjusting The C-Mount
Adjusting the C-mount LOCKING RING C MOUNT RING Figure 4. Camera Front View. THE C-MOUNT IS ADJUSTED AT THE FACTORY AND SHOULD NOT REQUIRE ADJUSTING. If for some reason, the C-mount requires adjustment, use the following method. Loosen Locking Ring Use an adjustable wrench to loosen locking ring. -
Page 16: Camera Installation
Camera Installation Computer Interface The Prosilica GE Series cameras will work with any Gigabit Ethernet network card; however AVT strongly recommends using Gigabit Ethernet components that support Jumbo Frames. A Jumbo Frame is loosely defined as a frame size greater than 1500 bytes however typical Jumbo Frames are around 9000 bytes. - Page 17 Gigabit Ethernet Setup for Windows o Install network card in computer. o Boot the PC and cancel the “Found new Hardware Wizard” window that may appear when Windows detects the new card. o Install the driver that came with the network card. o Once the driver is installed, open the Network Connections Dialog as follows: From the Windows desktop select start, then select Control Panel, then double click on the Network Connections icon.
- Page 18 Figure 6. Network card TCP/IP address. Figure 7. Turn off Firewall. o Return to the Gige Local Properties window as in Figure 5. Select the Advanced tab as in Figure 7 and disable the Firewall for this device. Click OK to save changes. GE1910 Technical Manual Page 18...
- Page 19 Gigabit Ethernet Cabling All Gigabit Ethernet cabling and connectors should be CAT5E or CAT6 compatible. Cable lengths must not exceed 100 meters. Power Connection The camera requires a 12V DC power supply that can source a minimum of 500 mA of current. See the Connections section of this document for more information.
- Page 20 Installing GigE Viewer for Testing o The latest Viewer software can be downloaded from http://www.alliedvisiontec.com/us/support.html. o Run the GigE Viewer Installer.exe. This will install the Prosilica GE Digital Camera drivers as well as the AVT GigE Viewer application program. o Plug in the Prosilica GE camera via the Gigabit Ethernet port. Plug in the power connection. Verify that the Status LED 1 is a solid green.
-
Page 21: System Optimization
System Optimization o Open the Network Connections Dialog as follows: From the Windows desktop select start, then select Control Panel, then double click on the Network Connections icon. Double click the relevant network card listed or right-click the relevant network card and select Properties. This will open the properties window for your network card. - Page 22 Figure 10. Network card advanced settings. o Set Maximum Frame Size or Jumbo Frames to the maximum possible value. A typical value is 9000. If the list contains a property called Receive Descriptors, then change this value to its maximum value. Select OK to save properties. o From the main properties dialog as in Figure 9, make sure that only the Internet Protocol (TCP/IP) check box is selected then click OK.
-
Page 23: Trouble Shooting
Trouble Shooting Is the camera getting power? The right LED is the camera power indicator. If unlit, check the power adaptor. If possible, swap with one that is known to work. If using a custom power adaptor, be sure the adaptor and wire gauge is rated to at least 500 mA. - Page 24 • Camera is not listed, or flashing “Camera Unavailable”: There may be multiple NICs on your system set to the same subnet. The camera can not know which card to resolve to. Change the IP address of your NIC. If you are still having problems, type: ipconfig /all in a windows command prompt, and send a screenshot to support@alliedvisiontec.com.
- Page 25 All stats 0 while streaming. Firewall likely blocking traffic • All stats 0. Likely a firewall is blocking incoming traffic. Disable your firewall. Check your camera trigger settings. Many camera trigger modes require a software or hardware trigger event to capture frames.
-
Page 26: Addendum
Addendum GE1910 Technical Manual Page 26... -
Page 27: Ge Io Schematic
GE IO Schematic HIROSE HR10A-10R-12SB CAMERA INTERNAL CIRCUIT TRIGGER INPUT SY NC OUT 2 SY NC OUT 3 RS-232 RXD RS-232 TXD TEXAS INSTRUMENTS SN74ACT244PWR 1Y 1 SY NC OUT 3 1Y 2 SY NC OUT 2 1Y 3 SY NC OUT 1 ISO+5V VDD-3.3 1Y 4... -
Page 28: Hirose 12-Pin Trigger Schematic
Hirose 12-pin Trigger Schematic USERS TRIGGER CIRCUIT CABLE SIDE TRIGGER INPUT USER TRIGGER (5V TTL DRIVER) SY NC OUT 2 SY NC OUT 3 SY NC OUT 2 (5V TTL RECEIVER) SY NC OUT 3 (5V TTL RECEIVER) HIROSE HR10A-10P-12P ONE GROUND RETURN IS SUFFICIENT. -
Page 29: Mini-Smb Trigger Schematic
Mini-SMB Trigger Schematic USERS TRIGGER CIRCUIT RG-174 COAX CABLE MINI-SMB TRIGGER INPUT USER TRIGGER (5V TTL DRIVER) RG-174 COAX CABLE MINI-SMB SY NC OUT 1 SY NC OUT 1 (5V TTL RECEIVER) The trigger circuit is connected to a Texas Instruments SN74ACT244PWR buffer/driver inside the camera. The required trigger input current is less than 10uA and the maximum sync output current is 24mA. -
Page 30: Trigger Timing Diagram
Trigger Timing Diagram Readout Time Trigger Latency Expose Start Registered Delay Exposure Time User Trigger Logic Trigger Exposure Trigger Jitter Readout Interline Time Trigger Ready Imaging Idle GE1910 Technical Manual Page 30... -
Page 31: Notes On Triggering
Notes on Triggering Definitions o User Trigger is the trigger signal applied by the user. o Logic Trigger is the trigger signal seen by the camera internal logic. o Tpd is the propagation delay between the User Trigger and the Logic Trigger. o Exposure is high when the camera image sensor is integrating light. - Page 32 Triggering during the Readout State o For applications requiring the fastest triggering cycle time whereby the camera image sensor is exposing and reading out simultaneously, then the User Trigger signal should be applied as soon as a valid Trigger Ready is detected. o In this case, Trigger Latency and Trigger Jitter can be up to 1 line time since Exposure must always begin on an Interline boundary.
