Summary of Contents for Ultra chef UC-SBP
- Page 1 ASSEMBLY INSTRUCTIONS HOODED GAS GRILL Model: UC-SBP FOR OUTDOOR USE ONLY PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY RETAIN THIS MANUAL FOR FUTURE REFERENCE...
- Page 2 WARNING Hazardous fire or explosion may result if instructions are ignored It is the consumer’s responsibility to see that the barbecue is properly assembled, installed, and taken care of. Failure to follow instructions in this manual could result in bodily injury and/or property damage. FOR YOUR SAFETY IF YOU SMELL GAS: 1.
- Page 3 Expanded view UC-SBP...
- Page 4 PARTS LIST UC-SBP Description Side burner cover Side burner rack-squareness Side burner rack protective pad-sq Drip tray-side burner Hot plate-Optional Side burner build in board Side burner brass cover Side burner Side burner back cover board Side burner brace board...
- Page 5 ASSEMBLY : UC-SBP Ref # 34 Ref # 34 Ref # 33 Ref # 29 Ref # 22 Ref # 33 M5x50x 4 PCS Ref # 28 M6x12x 16 PCS Ref # 27 Ref # 19 M6x50x4PCS M6 Nut x 4PCS...
- Page 6 Ref # 10 Ref # 25 M5x12x 4 PCS IMPORTANT: Read the following instructions carefully and be sure your barbecue is properly installed, assembled and cared for. Failure to follow these instructions may result in serious bodily injury and/or property damage. If you have any questions concerning assembly or operation, consult your dealer or LPG Gas Company.
- Page 7 Regulator and Hose These items are supplied with the barbecue, but replacements are available from your equipment retailer or an authorized LPG gas stockist. Use only regulators and hose approved for LP Gas at the above pressures. The life expectancy of the regulator is estimated as 2 years. It is recommended that it the regulator be changed within 2 years of the date of manufacture.
-
Page 8: To Check For Leaks
BEFORE USE CHECK FOR LEAKS Never check for leaks with a naked flame, always use a soapy water solution TO CHECK FOR LEAKS Make 2-3 fluid ounces of leak detecting solution by mixing 1 part dish soap with 3 parts water. Ensure the control valve is “OFF”. - Page 9 CLEANING “Burning off” the barbecue after every use (for approx 15 minutes) will keep excessive food residue to a minimum. OUTSIDE SURFACE Use mild detergent or baking soda and hot water solution. Non-abrasive scouring powder can be used on stubborn stains, then rinse with water. If the inside surface of the barbecue lid has the appearance of pealing paint, baked on grease build-up has turned to carbon and is flaking off.
-
Page 10: Troubleshooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION 1.LP gas cylinder is empty 1.replace with full cylinder Burners will not light using the 2.faulty regulator 2.have regulator checked ignition system 3.obstructions in burner or replace 4.obstructions in gas jets or gas hose 3.clean burner 5. - Page 11 How to maintain your BBQ 1 Wipe over the stainless steel surface with rust resistant oil when you store the BBQ or after used. 2. Cover the BBQ when not in use.
- Page 12 Battery insert : Remove ignition button, insert 1 AA battery Warning: Here for storage only, the gas cylinder cannot be placed inside when the BBQ is in use.
- Page 13 2010 Ultra Chef 375 Model Limited Warranty 3 YEARS STAINLESS STEEL BURNERS-PERFORATION 1 YEAR ALL OTHER COMPONENTS To process a warranty claim please contact ONE of the following: WOLF STEEL, UK T. 01676 522788 Email: info@napoleongrills.co.uk Napoleon Grills by Heartland T.
