  • Page 1 G586VSY AIO Rev . A+ System Board Quick Reference...
  • Page 2 FCC Statement on Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful in- terference when the equipment is operated in a residential installation.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction ............5 Features and Specifications ..........6 Package Checklist .............. 8 Chapter 2: Hardware Installation ..........9 Preparing the Area.............. 9 Handling the System Board ..........9 Installing the System Board ..........10 Board Layout ..............12 System Memory ..............13 DIMM ................13 SIMM ................14...
  • Page 4 Supervisor Password ............42 User Password ............43 IDE HDD Auto Detection ..........44 HDD Low Level Detection ..........46 Save & Exit Setup ............47 Exit Without Saving............47 System Error Report ............48 IDE Device Drivers .............50 Chapter 4: Troubleshooting Checklist ..........51 Appendix A: Types of Modules ............52 Appendix B: Memory and I/O Maps ..........

  • Page 5: Chapter 1 Introduction

    150MHz, 166MHz and 200MHz frequencies. The G586VSY AIO also supports Cyrix P120+, P133+, P150+, P166+ and P200+ CPUs. The G586VSY AIO can support 8MB to 256MB of system memory us- ing EDO or fast page mode x32/x36 (parity check) DRAM. This system board also supports pipeline burst DRAM, and provides easy cache up- grades using 256KB or 512KB cache modules.

  • Page 6: Features And Specifications

    Features and Specifications Processor • Intel Pentium™ 75/90/100/120/133/150/166/200MHz • Future Pentium™ OverDrive Processor • Cyrix P120+/ P133+/ P150+/ P166+/P200+ -Liner brust mode supported Chipset • VLSI Lynx chipset Cache Memory • Supports 0KB, 256KB or 512KB pipeline burst, direct map write- back cache •...
  • Page 7 GRAPHICS ACCELERATOR • S3 Trio64V+ (86C765) chip graphics, video and game controller • 1MB upgradeable to 2MB using EDO DRAM only • Video playback supported • LPB (Local Peripheral Bus) connector for MPEG or TV card upgrade • Software MPEG supported •...
  • Page 8 CPU SOCKET • 321-pin ZIF socket (Intel Socket 7) • Supports future low votage 2.5V CPUs • Supports 3.3V 10A switching power supply CONNECTORS • 2 serial ports • 1 parallel port • 2 IDE connectors • 1 floppy connector •...

  • Page 9: Package Checklist

    Package Checklist The G586VSY AIO package contains the following items: • The G586VSY AIO system board • The G586VSY AIO user’ s manual • One 40-pin IDE hard disk cable • One 34-pin floppy disk drive cable • One 25-pin printer port cable for chassis mounting •...

  • Page 10: Chapter 2: Hardware Installation

    Chapter 2 Hardware Installation This chapter summarizes the steps to install the G586VSY AIO system board into your system unit. It also includes a description of the area in which you must work and directions for memory installation. Before in- stalling the system board, obtain the memory you plan to install.

  • Page 11: Installing The System Board

    ESD protection. Installing the System Board If you are installing the G586VSY AIO system board, the following out- lines the basic installation steps. Before installing the system board into your system unit, you should prepare the tools you will need.
  • Page 12 4. Loosen the screws holding the original system board and remove the board from the system. Save the screws. 5. Remove the G586VSY AIO from its original packing box. Be careful to avoid touching all connectors and pins on the board. Please refer to the handling instructions on pages 9-10 for proper handling tech- niques.
  • Page 13 Pin 1 of the jumpers and connectors PBSRAM = Pipeline Burst SRAM...

  • Page 14: System Memory

    Bank 0 or Bank 1, but you must populate a bank first before going to the next bank. The G586VSY AIO system board can support 8MB to 256MB of memory using 1MBx36, 2MBx36, 4MBx36, 8MBx36, or 16MBx36 72-pin SIMMs. The table below shows the supported SIM modules and their corresponding memory sizes.
  • Page 15 Installing a SIM Module A SIM module simply snaps into a socket on the system board. Pin 1 of the SIM module must correspond with Pin 1 of the socket . notch 1. Position the SIMM above the socket with the “ notch” in the module aligned with the “...

  • Page 16: Cache Memory

    Cache Memory The G586VSY AIO system board can support 256KB or 512KB pipeline burst, direct map write-back cache SRAM. Your system board may come with 256KB or 512KB cache mounted onboard. The 160-pin cache module slot lets you upgrade your cache memory by installing a 256KB cache module.
  • Page 17 Jumper Setting for Cache Jumper JP8 Cache Size Select Cache Size Cache Bank SRAM 2-4, 3-5 On 256K Onboard 32KX32X2 2-4, 1-3 On 512K Onboard 64Kx32x2 512K Onboard 256K 32Kx32x2 1-3, 2-4 On 32Kx32x2 Cache Module 256K 3-5, 4-6 On 256K Cache Module 256K 32Kx32x2...

  • Page 18: Cpu Installation

    CPU Installation The G586VSY AIO allows for easy installation of CPUs. Make sure all jump- ers are set correctly before applying power or you may damage the CPU or system board. Please see the jumper settings on the following pages. Use the needle-nosed pliers to move the jumpers if necessary.
  • Page 19 Cyrix CPUs JP18 JP15 JP16 JP17 → JP13 JP12 Voltage → 1-2 On 3.45V 2-3 On 3.3V...

  • Page 20: Installing Upgrade Cpus

    Installing Upgrade CPUs The G586VSY AIO is equipped with a 321-pin Zero Insertion Force (ZIF) socket at location U13 of the system board. Refer to page 12 for the location of the ZIF socket. This socket is designed for easy removal of an old CPU and easy insertion of an upgrade CPU.
  • Page 21 To install an upgrade CPU, do the following. 1. Make sure the handle on the side of the ZIF socket is up. To raise the handle, push it down, slightly pull it out to the side, then raise it as far as it will go. It may be necessary to initially apply a small amount of sideways force to free the handle from its retaining “...

  • Page 22: Installing A Fan/Heatsink For Cyrix Cpus

    3. Position the CPU above the ZIF socket. Make sure pin 1 of the CPU is aligned with pin 1 of the socket. Lower the chip until the pins are inserted properly in their corresponding holes. Remember that very little force is needed to install the CPU. If the CPU is not easily inserted, verify whether or not pin 1 of the CPU is aligned with pin 1 of the socket.
  • Page 23 Clearnance Requirements Your CPU comes with a heatsink mounted on top. To maintain proper airflow once the upgrade is installed on the system board, the CPU and heatsink require certain space clearances. The clearance above the CPU's fan/heatsink must be at least 0.4 inches.

  • Page 24: Jumper Settings For Display Type

    Jumper JP23 Internal/External Battery Select The G586VSY AIO comes with an internal lithium battery. Set JP23 pins 1 and 2 to On to use the internal battery. If you are connecting an external battery to connector J21, you must set JP23 pins 2 and 3 to...
  • Page 25 1-2 On : Internal Battery 2-3 On : External Battery (Default)

  • Page 26: Built-In Ports

    Built-in Ports The G586VSY AIO system board is equipped with two serial ports, one parallel printer port, one FDD connector, two IDE hard disk shrouded headers and one PS/2 mouse connector. Refer to page 12 for the loca- tions of the built-in connectors and pin 1 of those connectors.

  • Page 27: Serial Ports

    PS/2 Mouse Port The PS/2 mouse port is a 6-pin connector on the system board. Attach the 6-pin mouse port cable, which came with the G586VSY AIO, to connector J3/CN3. Make sure the brown wire on the PS/2 mouse con- nector is aligned with pin 1 of connector J3/CN3.

  • Page 28: Floppy Disk Drive Controller

    Connecting the Parallel Printer Port Attach the DB-25S printer port cable, which came with the system board, to connector J7 on the G586VSY AIO system board. Make sure the colored stripe on the ribbon cable aligns with pin 1 of connector J7.
  • Page 29 Header Note: The IDE cable with a standard 40-pin connector (without the keying mechanism) can be installed in the PCI IDE shrouded header. Be ex- tremely careful to match the colored edge of the ribbon with pin 1 of the header.

  • Page 30: Installing Expansion Cards

    Installing Expansion Cards The G586VSY AIO system board is equipped with 4 dedicated PCI slots and 3 dedicated 16-bit ISA slots. All PCI slots are bus masters. Due to the size of the CPU with its accompanying heatsink/fan compo- nent, the length of the add-in cards in PCI slot 4 and ISA slot 1 is limited to 18cm (7.07",measured from the bracket of the card).

  • Page 31: Chapter 3: Software Installation

    Chapter 3 Software Installation After you power up your system, the BIOS message appears on your screen and the memory count begins. After the memory test, the following message will appear on the screen: Press DEL to enter setup If the message disappears before you respond, restart your system or press the “...

  • Page 32: Standard Cmos Setup

    ROM PCI/ISA BIOS (2A59GD49) CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP INTEGRATED PERIPHERALS SUPERVISOR PASSWORD BIOS FEATURES SETUP USER PASSWORD CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP IDE HDD AUTO DETECTION HDD LOW LEVEL FORMAT PNP/PCI CONFIGURATION SAVE & EXIT SETUP LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS EXIT WITHOUT SAVING...
  • Page 33 you can select Auto, User, one of 46 predefined drive specifications or None. Auto: This option indicates that the parameters for your hard disk drive(s) will be automatically detected and displayed when you boot your system. By default, the LBA mode is selected for a hard disk drive larger than 528 megabytes.

  • Page 34: Bios Features Setup

    No Errors: The system boot will not stop for any detected errors. All Errors: The system will stop whenever the BIOS detects a non-fatal error. All, But Keyboard: The system will stop for any error except a keyboard error. All, But Diskette: The system will stop for any error except a disk error. All, But Disk/Key: The system will stop for any error except a keyboard or disk error.

  • Page 35: Chipset Features Setup

    Chipset Features Setup The G586VSY AIO uses the Intel 82430VX chipset. The Chipset Fea- tures Setup allows you to modify some functions to optimize system performance. If you press <Enter>, a screen similar to the one on the...

  • Page 36: Power Management Setup

    ROM PCI/ISA BIOS (2A59GD49) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. Auto Configration :Enabled DRAM Timing :60 ns DRAM RAS# Precharge Time DRAM R/W Leadoff Timing Fast RAS To CAS Delay DARM Read Burst (EDO/FP) :x222/x333 DRAM Write Burst Timing :x222 Fast MA to RAS# Delay CLK Fast EDO Path Select :Disabled...

  • Page 37: Pnp/Pci Configuration Setup

    PNP/PCI Configuration Setup Use the arrow keys to highlight “ PNP/PCI Configuration Setup” and press <Enter>; a screen similar to the one below will appear. ROM PCI/ISA BIOS (2A59GD49) PNP/PCI CONFIGURATION SETUP AWARD SOFTWARE, INC. Resources Control By :Auto PCI IRQ Active By Level PCI IDE IRQ Map To PCI-AUTO...

  • Page 38: Load Setup Defaults

    Load Setup Defaults The “ Load Setup Defaults” option loads optimized settings from the BIOS ROM. Use the Setup default values as standard values for your system Highlight this option on the main menu and press <Enter>. The mes- sage below will appear. Load Setup Defaults (Y/N)? N Type <Y>...

  • Page 39: User Password

    If you want to protect access to setup only, but not your system, set a supervisor’ s password with the “ Setup” option selected in the BIOS Features Setup. You will not be prompted for a password when you cold boot the system. Use the arrow keys to highlight the “...

  • Page 40: Ide Hdd Auto Detection

    Standard CMOS Setup. Hard Drive Mode The G586VSY AIO supports three HDD modes: Normal, LBA and Large. If your hard disk drive does not support LBA mode, the “ LBA” option will not be displayed. If your HDD has 1024 or fewer cylinders, the “...
  • Page 41 Large Mode The Large mode is the extended HDD access mode supported by the G586VSY AIO system board. Some IDE HDDs have more than 1024 cylinders without LBA support (in some cases, you may not want the LBA mode). This system board provides another alternative to support these kinds of HDDs.
  • Page 42 The BIOS tells the operating system that the number of cylinders is half of the actual number and that the number of heads is double the actual number. During disk access, the reverse conversion is done by the INT13h routine. Example of Large mode: CYLS.

  • Page 43: Save & Exit Setup

    ROM PCI/ISA BIOS (2A59GD49) CMOS SETUP UTILITY AWARD SOFTWARE, INC. Hard Disk Low Level Format No. CYLS HEAD Utility SELECT DRIVE BAD TRACK LIST PERFORMAT Current select drive is : C DRIVE: C CYLINDER: 0 HEAD: 0 LANDZ SECTOR SIZE CYLS HEAD RECOMP...

  • Page 44: System Error Report

    Quit Without Saving (Y/N)? N Type “ Y” and press <Enter>. The system will reboot and you will once again see the initial diagnostics on the screen. If you wish to make any changes to the setup, press <Ctrl> <Alt> <Esc> simultaneously or <Del>...
  • Page 45 DISPLAY SWITCH IS SET INCORRECTLY The display switch on the system board can be set to either mono- chrome or color. This error indicates the switch is set to a different setting than indicated in Setup. Determine which setting is correct and either turn off the system and change the jumper or enter Setup and change the VIDEO selection.

  • Page 46: Ide Device Drivers

    Press and hold down the CTRL, ALT and DEL keys simultaneously. IDE Device Drivers To install the IDE device drivers supported by the G586VSY AIO sys- tem board, please refer to the “ Readme” file contained in the provided diskette.
  • Page 47 Chapter 4 Troubleshooting Checklist If you experience difficulty with the G586VSY AIO system board, please refer to the checklist below. If you still cannot identify the problem, please contact your dealer. 1. Check the jumper settings to ensure that the jumpers are properly set.

  • Page 48: Appendix A: Types Of Modules

    Appendix A Types of Modules The G586VSY AIO system board allows you to populate memory with 1MBx64 or 2MBx64 DIMM, and 1MBx32, 2MBx32, 4MBx32 and 8MBx32 SIMMs. The following modules have been tested with this board. Most untested brands will work but a few may fail to do so.

  • Page 49: Appendix B: Memory And I/O Maps

    Appendix B Memory and I/O Maps Memory Address Map Address Name Function 0000000 to 640KB System System Board Memory 009FFFF Board RAM 00A0000 to 128KB Video Reserved for Graphics 00BFFFF Display Memory Display Memory 00C0000 to 160KB I/O Reserved for ROM on 00E7FFF Expansion ROM I/O Adapter Card...
  • Page 50 I/O Address Map I/O Address Function 0000-001F DMA Controller 1, 8237A-5 0020-003F Interrupt Controller 1, 8259A, Master 0040-005F Timer, 8254-2 0060-006F 8742 (Keyboard Controller) 0070-007F Real-time Clock, NMI (Non-maskable Interrupt) Mask 0080-009F DMA Page Memory, 74LS612 00A0-00BF Interrupt Controller 2, 8259A 00C0-00DF DMA Controller 2, 8237A-5 00E8...

  • Page 51: Appendix C: Pci I/O Pin Assignments

    Appendix C PCI I/O Pin Assignments Component Side Solder Side -12V - 01 - TRST# - 02 - +12V Ground - 03 - - 04 - - 05 - INTA# - 06 - INTB# - 07 - INTC# INTD# - 08 - PRSNT1# - 09 - Reserved...

  • Page 52: Appendix D: Isa I/O Pin Assignments

    Appendix D ISA I/O Pin Assignments -I/O Chck - 01 - Reset Drv - 02 - +5V DC - 03 - IRQ9 - 04 - -5V DC - 05 - DRQ2 - 06 - -12V DC - 07 - O W S - 08 - +12V DC - 09 -...

  • Page 53: Appendix E: Connector Pin Assignments

    Appendix E Connector Pin Assignments Connector J3 Power LED/Keylock Connector Function LED Signal Reserved Ground Keylock Signal Ground Connector J4 Speaker Connector Function Reserved Ground Signal Connector J5 Green LED Connector Function Signal Ground Connector J6 Turbo Switch Function Ground Signal...
  • Page 54 Connector J7 Turbo LED Connector Function Signal LED Power Connector J8 Reset Switch Function Ground Reset Connector J9 IDE LED Connector Function Signal Ground Connector J10 Wave Table Connector Function Function Ground N.C. Analog Ground Ground N.C. MIDI In Analog Ground Ground +12V Analog Ground...
  • Page 55 Connector J11 Line out/Speaker out Connector Function Audio R-out Ground Ground Audio L-out Connector J12 MIC In Function Signal-In Ground Ground Signal-In Connector J13 Line In Function Audio R-in Ground Ground Audio L-in Connector J14 and J15 Primary and Secondary IDE Hard Disk Drive Connectors Function Function -Reset...
  • Page 56 Function Function Reserved Ground Reserved -IOW Ground -IOR HCS0 Ground HCS1 Reserved BALE Ground Connector J16 Feature Connector Function Function LPB-D0 G N D G N D Blank LPB-D1 G N D G N D HSYNC LPB-D2 G N D G N D VSYNC LPB-D3...
  • Page 57 Connector J18 USB Port 1 Function USB 1 Negative Data Line USB 1 Positive Data Line G N D Connector J19 Folppy Disk Drive Connector Function Function Ground DENSEL Ground Ground Step Reserved Ground Ground Write Data Drate0 Ground Ground Wrote Gate Index Ground...
  • Page 58 Connector J21 External Battery Connector Function 3.6V Lithium Battery Ground Ground Connector J22 IrDA Connector Function IRTX G N D IRRX N.C. Connector J23 Power Connector Function Function Power Good Ground Ground +12V -12V Ground Ground Connector J24 Internal VGA Connector Function Function Ground...
  • Page 59 Connector J25 12V Fan Connector Function Ground +12V Ground Connector J26 PS/2 Mouse Connector Function Mouse Data Reserved Ground Mouse Clock Reserved Connector J27 PS/2 Keyboard Connector Function Keyboard Data Reserved Ground Keyboard Clock Reserved Connector Jgame Joystick (MIDI Port) Function Function Ground...
  • Page 60 Connector CON 2 VGA Connector Function Function NCPIN Green Ground Blue NCPIN NCPIN SPD (DDC_SPD) Ground HSYNC Ground VSYNC Ground SCL (DDC_DCL) Ground Connector CON3 Parallel Printer Port -STB -Write -STB PD <0:7> PD <0:7> PD <0:7> PD <0:7> PD <0:7> PD <0:7>...
  • Page 61 Connector CON4 and CON5 COM 2 and COM 1 Serial Ports Function DCD (Data Carrier Detect) RX (Receive Data) TX (Transmit Data) DTR (Data Terminal Ready) Ground (Signal Ground) DSR (Data Set Ready) RTS (Resquest to Send) CTS (Clear to Send) RI (Ring Indicator)
