Summary of Contents for DeVilbiss HVLP TRANS-TECH
- Page 1 SB-E-2-535 ISS.07 Operation Manual ® HVLP & Trans-Tech Gravity Feed Spraygun P 1 - 12...
-
Page 2: Ec Declaration Of Conformity
Important: : These Sprayguns are suitable for use with both waterbased and solvent based coating materials. The design uses EPA compliant (Devilbiss Trans-Tech®) and HVLP atomising technology to reduce overspray and improve coating efficiency. These guns are not designed for use with highly corrosive and/or abrasive materials and if used with such materials it must be expected that the need for cleaning and/or replacement of parts will be increased. -
Page 3: Safety Warnings
SAFETY WARNINGS Always wear eye protection when Fire and explosion spraying or cleaning the spraygun Solvents and coating materials Gloves must worn when can be highly flammable or spraying cleaning combustible when sprayed. ALWAYS equipment refer to the coating material suppliers Training –... -
Page 4: Parts List
Parts List Ref. No Description Part Number Options Air Cap/Retaining ring See Selection Chart Nozzle See Selection Chart Separator SP-626-K5 Packing GTI-445-K2 Spreader Valve SP-403-K Stud and Screw GTI-408-K5 Needle Adjusting Screw SP-614-K Spring SP-622-K5 Needle See Selection Chart Airvalve housing + seal SP-612-K Spindle Trigger... - Page 5 © 2005 ITW Finishing Systems and Products...
-
Page 6: Specification
Patent No 2372465 (GB) Specification Air supply connection - Universal “ BSP and NPS Maximum static Air inlet pressure - = 12 bar (175 psi) Nominal gun Air inlet pressure - 2. bar (29 psi) 510 Trans-Tech Air Cap with gun triggered 1.4 bar (20 psi) 505 HVLP Air Cap Maximum Service temperature 40°C... -
Page 7: Installation
Installation Important: To ensure that this equipment earth should be checked with an ohmeter. A resistance of less than reaches you in first class condition, protective coatings have been used. Ohms is recommended. Flush the equipment through with a Air supply should be filtered and suitable solvent before use. -
Page 8: Replacement Of Parts
clean and free from damage. Build Lubrication – stud/screw (6), needle (9) and air valve (11) should be up of dried paint can distort the spray pattern. oiled each day. Replacement of Parts Nozzle (2) and Needle (9) – Remove 10. - Page 9 © 2005 ITW Finishing Systems and Products...
- Page 10 © 2005 ITW Finishing Systems and Products...
- Page 11 Accessories Spanner – order SPN-5 Cleaning Brush – order 4900-5-1-K3 Regulator/Gauge Attachment - order HAV-501-B Pressure gauge Attachment – order GA-515 Gun Mounted Regulator – order DVR-501 Spraygun Lubricant - order GL-1-K10 © 2005 ITW Finishing Systems and Products...
- Page 12 Roundspray Aircap - COM-500R HVLP Mode - Air Inlet Pressure = 1.0 Bar (14.5 PSI) Tanstech Mode – Air Inlet Pressure = 2 bar (29 PSI) Approx Spot Size = Ø50mm ITW Finishing Systems and Products Ringwood Road, Bournemouth, BH11 9LH, England.
