- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/28/2019...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Overview ..................1 Front View ..............................1 Packaging Contents ..........................1 System Requirements ..........................1 Important operation notes ........................2 Installation ....................3 Microsoft® Windows® Operation ......................3 Specifications ..................6 Technical Support ..................7 Warranty Information ................7 Instruction Manual... -
Page 4: Product Overview
Product Overview Front View SCAN button Integrated DP #1 DP #2 DP #3 DisplayPort Cable Packaging Contents • 3-Port Multi Monitor DisplayPort® MST Hub • 1x Universal Power Adapter (NA/EU/UK/AUS) • 1x Instruction Manual System Requirements • DisplayPort 1.2 enabled computer system/video card •... -
Page 5: Important Operation Notes
• Different types of displays, such as HDMI®, DVI, and VGA work with this MST hub, provided the appropriate DisplayPort adapter is used. DisplayPort adapters aren’t included. The StarTech.com SKU for each adapter is listed below: • DisplayPort to HDMI adapter (DP2HDMI) •... -
Page 6: Installation
2. Connect the integrated DisplayPort cable into the DisplayPort connector on the host computer system/video card. 3. Connect the DisplayPort monitor/display device(s) into the DisplayPort #1/#2/#3 connectors on the MSTDP123DP MST Hub. 4. Power on the monitor/display device(s). 5. Turn on the computer system. - Page 7 NOTE: Each monitor connected is represented by a number displayed under “Change the appearance of your displays”. To determine which number corresponds with each display click the Identify button. 2. To adjust the Resolution, click on the number that corresponds with the monitor you wish to adjust, and select the drop down menu next to “Resolution:”.
- Page 8 3. To Choose whether the Monitor will Duplicate or Extend your main Monitor, select the number that corresponds with the Monitor you wish to adjust, and select the drop down menu next to “Multiple Displays:”. “Extend these displays” will extend your monitor main onto the selected monitor.
-
Page 9: Specifications
Specifications Video Signal DisplayPort Number of Ports 1x DisplayPort Male External Connectors 3x DP Female Maximum Display Resolution 4K at 30 Hz Instruction Manual... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
