The dryer must not be stored or installed where it will be exposed to water and/or weather.
WARNING: For your safety the infor-
mation in this manual must be fol-
lowed to minimize the risk of fire or
explosion or to prevent property dam-
age, personal injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
– WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Clear the room, building or area of all
occupants.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be performed by
a qualified installer, service agency or the
gas supplier.
Post the following "For Your Safety" caution in a
prominent location:
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
It is important that you read this Manual and retain it for
future reference. For service or replacement parts,
contact the distributor in your area or the manufacturer.
OPERATOR'S MANUAL
DDAD50KC Series Dryers
c
manufactured by
Dexter Laundry Inc.
2211 W. Grimes
Fairfield, Iowa 52556
for
AVERTISSEMENT. Assurez-vouz de
bien suivre les instructions données
dans cette notice pour réduire au
minimum le risque d'incendie ou
d'explosion ou pour éviter tout
dommage matérial, toute blessure
ou la mort.
Ne pas entreposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant
dans le bâtiment où vous vous trouvez.
Évacuez la pièce, le bâtiment ou la zone.
Appelez immédiatement votre
fournisseour de gaz depuis un voisin.
Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
– L'installation et l'entretien doivent être assurés par
un installateur ou un service d'entretien qualifié ou
par le fournisseur de gaz.
POUR VOTRE SÉCURITÉ
Ne pas enteposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
You, the purchaser, must post in a prominent loca-
tion instructions to be followed in the event the user
smells gas. Consult your local gas supplier for
procedure to be followed if the odor of gas is
present.
8514-141-001

Advertisement

Table of Contents
loading

Summary of Contents for Dexter Laundry DDAD50KC Series

  • Page 1 8514-141-001 OPERATOR’S MANUAL DDAD50KC Series Dryers The dryer must not be stored or installed where it will be exposed to water and/or weather. WARNING: For your safety the infor- AVERTISSEMENT. Assurez-vouz de mation in this manual must be fol- bien suivre les instructions données lowed to minimize the risk of fire or dans cette notice pour réduire au...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page No. Warnings about use and operation ..................2 Installation and Operating Instructions ..............4, 5, 6 Dryer Shutdown ......................... 8 Description of Controls ...................... 8 Operating Instructions ....................... 9 Changing Programmed Data ..................... 9 Options Available ......................11 Electronic Coin Acceptor Setting........
  • Page 3: Figure 1 - Dryer Dimensions

    8" VENT 4 3/4 6 7/8 GAS INLET ELECTRICAL CONNECTIONS 86 1/4 79 3/8 34 1/2 DDAD50 STACKED DRYER...
  • Page 4: Installation And Operating Instructions

    INSTALLATION AND OPERATING INSTRUCTIONS UNCRATING AND PLACING DRYER Tools Required: 3/4" hex socket & ratchet driver, wood block 4" or 5" thick, a knife and a groove joint plier which will open to 1 3/8". 1. Remove and discard packaging. 2.
  • Page 5: Figure 2 - Vertical Clearance Dimensions

    The sources of all make-up air and room ventilation air movement to all dryers must be located away from any dry cleaners. This is necessary so that solvent vapors will not be drawn into the dryer inlet ducts. Dry cleaner solvent vapors will decompose in contact with open flame such as the gas flame present in clothes dryers.
  • Page 6 CAUTION: The dryer and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig. The dryer must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig.
  • Page 8: Dryer Shutdown

    7. DRYER IGNITION (SOLID STATE IGNITION): The solid state ignition system lights the main burner gas by spark. The gas is ignited and burns only when the gas-relay (in the electronic controller) calls for heat. The procedure for first-time starting of a dryer is as follows. A.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS 1. Load clothes into either the upper or lower drum (or both). Close the door(s) completely. 2. Deposit coin or coins equal to or greater than the displayed vend price. Upon deposit of the first coin, the green light will flash on and off.
  • Page 10: Figure 4 - Rear View Of Controller

    The controller is put into the programming mode by opening both dryer doors and actuation of a switch on the controller circuit board and remains in this mode until one of these actions occur: 1. The switch is actuated again. 2.
  • Page 12: Servicing Dryer And Preventive Maintenance

    SERVICING DRYER CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. ATTENTION. Lors des opérations d'entretien des commandes, étiqueter tous les fils avant de les déconnecter. Toute erreur de câblage peut être une source de danger et de panne.
  • Page 13: Conversion To 208-240V Instructions

    Instructions - Convert a Dual Voltage Stack Dryer from 120V to 208-240V with Neutral Wire Only 1. Remove incoming power from the dryer. Use a known working voltmeter to check power. 2. Remove the cover of the control box assembly from the dryer using a 5/16” wrench. 3.
  • Page 14 Contact Information: Address: Dexter Laundry Inc. 2211 W. Grimes Ave. Fairfield, IA 52556 Phone: 1-800-524-2954 Website: www.dexterlaundry.com...
