Summary of Contents for Freelinc FDM300
- Page 1 ® FreeLinc FDM300 DualMuff Headset User Guide...
-
Page 2: Table Of Contents
Table of Contents Introduction..... . – Welcome and Product Overview DualMuff Headset Diagram..Operating Concepts and Terms..–... -
Page 3: Introduction
Introduction Welcome Congratulations, and thank you for choosing FreeLinc products to enhance your two-way radio communications. Near Field Magnetic Induction (NFMI) wireless technology. NFMI supports mobility, freedom-of- motion, exceptional battery life, audio integrity, ease of use, durability, secure communications and implemented into practical voice and audio solutions for two-way radios. - Page 4 Introduction Product Overview The FreeLinc DualMuff Headset works within a small area surrounding the user. The size of the area is determined by the distance between your headset and the adapter. If your headset and adapter are close together, the area shrinks in diameter –...
-
Page 5: Dualmuff Headset Diagram
DualMuff Headset Diagram Replaceable Silicon Ear Pads Pairing button/ Charging Indicator Light Push-to-Talk Button Status Indicator Light... - Page 6 DualMuff Headset Diagram Adjustable Headband Noise cancelling Microphone Push-to-Talk Button Volume on/off Control Charge Jack...
-
Page 7: Operating Concepts And Terms
Operating Concepts and Terms Adjusting the Headband Velcro Strap Use the velcro strap to adjust the fit of your Headset. If you are in a noisy environment, to insure optimal sound quality, pull your hair away from your ears so the cushions fit directly against your head. -
Page 8: Charging
Operating Concepts and Terms Charging Red/Green Charge Status Indicator Light... -
Page 9: Headset Tones
Operating Concepts and Terms Headset Alert Tones When the link between the FreeLinc DualMuff Headset and the adapter is broken, you will hear the following alert tones: TONE INDICATION Three double beeps Link is broken Continuous series Push-to-Talk button of beeps... - Page 10 Operating Concepts and Terms Pairing Before your headset can communicate with an adapter, it must establish a link. To establish a link, your headset and adapter must exchange a unique software ID code, which is stored in each device. This process is called “pairing.
- Page 11 Operating Concepts and Terms Linking After entering Seek Mode and finding the adapter with which it is paired, your headset will establish a link, and communication can occur. This link will remain active until you turn off the adapter or radio, at which point the headset will return to Seek Mode.
-
Page 12: Getting Started
Using Your Headset for the First Time Step One: Attach Adapter Attach your FreeLinc adapter to the accessory interface of your portable radio (see your portable radio’s user manual if you need assistance locating the accessory interface). If your adapter has a mounting clip on top, use the clip and locking screw to secure the adapter to your radio. - Page 13 When you have successfully paired your headset to the adapter, the adapter indicator light will flash green, indicating a successful pairing. NOTE: When pairing, make sure that there are no other FreeLinc products within 6 feet of the devices being paired.
- Page 14 Getting Started Step Five: Establish Link (Automatic) Once you pair your headset to an adapter, the two devices establish a communication link. This occurs automatically after pairing, and the link persists as long as your headset remains within the communication area. If you move your headset outside the defined area, the link is lost and the unit returns to Seek Mode.
-
Page 15: Additional Information
Keep in mind that your headset can only be paired with one adapter at a time. NOTE: When pairing, make sure that there are no other FreeLinc products within 6 feet of the devices being paired. -
Page 16: Specifications
Additional Information Specifications Near-Field Magnetic Wireless Technology Induction Battery Type Li-Po 3.7v 2200mAh Up to 150 hours Battery Life talk time Range Up to 5 feet 1.25m Operating -20 C to +60 C Temperature 95% @ 8 hours Humidity (non-condensing) Noise Reduction -25db\SPL Rating (NRR) -
Page 17: Frequently Asked Questions
Additional Information Frequently Asked Questions What happens if I go out of range and lose the link between my headset and my adapter? When your headset is out of range of the adapter, the headset will beep and the indicator light on the adapter will blink red. - Page 18 Do I need to modify my radio in any way for my headset or adapter to work? No. The only requirement is that the FreeLinc adapter is compatible with your radio model. For a complete list of the radio models FreeLinc supports, please refer to the FreeLinc website at www.freelinc.com.
- Page 19 Tips and Suggestions For up-to-date troubleshooting information, or to get help with a specific problem, or to contact a customer service representative, please visit www.freelinc.com, and click the “support” link or call 1-866-467-1199. Accessories FreeLinc continually releases new accessories for its products.
-
Page 20: Safety Information
Safety Information Caution: To reduce the risk of fire or injury, please read and follow the instructions below. • Do not dispose of product in a fire; the battery cells may explode. Check with local codes for possible battery disposal instructions. •... - Page 21 Safety Information • Do not stick anything inside the product as this may damage internal components. • This product conforms to the following safety standards: ANSI/UL 60950-1 1st Ed. CAN/CSA C22.2 No. 60950-1-03 EN 60950-1 1st Ed.
-
Page 22: Warranty And Fcc Compliance
(the “Warranty Period”). b. Rechargeable batteries will be replaced during the warranty period if the battery fails. c. FreeLinc, at its option, will at no charge either repair, replace, or refund the purchase price for warranted Product during the warranty period provided it is returned in accordance with the terms of this warranty to the place of purchase. - Page 23 FreeLinc. Unless made in a separate written agreement between FreeLinc and the original end user purchaser, FreeLinc does not warrant the installation, maintenance or service of warranted Product.
- Page 24 A product which, due to illegal or unauthorized alteration of the software/firmware in the Product, does not function in accordance with FreeLinc’s published specifications or the FCC type acceptance labeling in effect for the Product at the time the Product was purchased.
- Page 25 Purchaser shall return the nonconforming Product to the place of purchase freight prepaid. IV. Limitation of Liability: a. This warranty sets forth the full extent of FreeLinc’s responsibilities regarding the Product. Repair, replacement, or refund of the purchase price, at FreeLinc’s option, is the exclusive remedy.
- Page 26 Warranty and FCC Compliance c. FREELINC SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE PRODUCT, EVEN IF FREELINC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. d. EXCEPT FOR CLAIMS FOR BODILY INJURY...
- Page 27 Warranty and FCC Compliance FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 28 Warranty and FCC Compliance reception, which can be determined by comparing the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. •...
- Page 29 ® © 2005, 2006, 2007, 2008, 2015, Radeum Inc., DBA FreeLinc. All Rights Reserved. Protected by one or more of the following U.S. patents: 7.149.552, 7.254.366, 7.236.741, 7.215.924, 7.142.811, 7.035.608, 6.819.762, 6.459,882, 5.982.764, 5.912.925, 5.771.438 7.732.901, 7.565.187, 7.574.173 authorized for use in some countries.
