Remote Pairing

Prepare the vehicle system to be Paired with a new remote
1. Open a door.
2. Turn the key to the ON position.
3. Within 5 seconds press and release the Control button on the Control Center one time.
4. Within 5 seconds, press and hold the Control button on the Control Center. The status LED will flash one
time and the siren then chirps to confirm the vehicle is ready for remote pairing.
5. Release the Control button and proceed below.
Note: If no remote pairing results, the system will exit after 60 seconds.
Prepare the LC3 2-way remote control to be Paired with the system:
Remote Pair matches your LC3 remote to the system. Make sure the LC3 remote is set for the desired Car 1
(Default) or Car 2 operation for the system it will be paired with.
1. Press and hold the
onds) until the main menu appears.
2. Press and release the
3. Press and release the
4. Press and hold the
5. Successful or Failed Pair: The LC3 remote control indicates a successful or failed pairing on the display.
Prepare the vehicle system to be Paired with the companion or a new 1-way remote as described above.
Note: If no remote pairing results, the system will exit after 60 seconds.
Prepare the companion 1-way remote control to be Paired with the system:
Make sure the remote is set for the desired Car 1 (Default) or Car 2 operation for the system it will be paired
with.
1. Press and hold the
Note: If Car 2 mode is on, ignore the Car Select beep after 3 seconds.
2. Wait for the Transmit LED to light solid and the remote to beep. Release the
3. Press the button for 1 second. The transmit LED will blink 3 times and beep 3 times.
AUX
4. Within 5 seconds, press the
5. The vehicle siren will chirp. You have now successfully learned the remote to the vehicle remote start and
security system.
AUX
6. Press the button two times to exit learn routine on the remote. The transmit LED will turn off and exit
tone will sound.
10
AUX
button for 8 seconds (If Car 2 mode is on, ignore the Car Select beep after 3 sec-
button until
Remote Pair
AUX
AUX
button until
Pair
button until tones are played on the LC3 remote.
AUX
AUX
button for 8 seconds.
button.
AUX
text is displayed.
text is displayed.
AUX
button.
