WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GSF2818KSN
Owner's Manual
Outdoor Natural Gas Barbecue Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8225 (TOLL-FREE), 07:00 A.M. – 16:00 P.M.
(EST), MONDAY-FRIDAY.
Service Center: 1-877-885-8225
0
MODEL# GSF2818KSN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSF2818KSN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BBQ GSF2818KSN

  • Page 1 MODEL# GSF2818KSN Outdoor Natural Gas Barbecue Grill WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these...
  • Page 2 Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use this gas barbecue grill to prevent possible bodily injury or property damage. NOTE: This grill must be used with natural gas only. Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GSF2818KSN Owner’s Manual...
  • Page 3: Table Of Contents

    Assembly Instructions..................... 7 Operating Your Grill....................... 13 Natural gas connection....................13 Checking for Leaks......................14 Lighting Your Grill......................14 Excess Flow Safety Valve Reset Procedure ............... 16 Care and Maintenance ....................17 Troubleshooting ......................18 Waranty Program ......................19 GSF2818KSN Owner’s Manual...
  • Page 4: For Your Safety

    DANGER: Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation. GSF2818KSN Owner’s Manual...
  • Page 5 *** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. GSF2818KSN Owner’s Manual...
  • Page 6 GSF2818KSN Owner’s Manual...
  • Page 7 Hardware list 28PCS 32PCS 32PCS Screwdriver M6 Nut Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GSF2818KSN Owner’s Manual...
  • Page 8: Assembly Instructions

    Insert one bolt (AA) with one spring washer (CC) and one flat washer (BB) into each pre-drilled holes. Tighten bolts by hand until secure. Repeat the procedure for the heat insulation panel and cart right side panel assembly. d) Tighten all bolts using the screwdriver provided. GSF2818KSN Owner’s Manual...
  • Page 9 Push down the top pin of left door insert it into the pre-drilled hole on the left end of cart front beam. Repeat the procedure for the right door (L) assembly. d) Close the two doors. GSF2818KSN Owner’s Manual...
  • Page 10 (BB) into each pre-drilled hole. Tighten bolts by hand until secured. d) Go back and tighten all bolts using the screwdriver provided. e) Repeat the procedure for the assembly of right side shelf (R) and side bar tool hanger. GSF2818KSN Owner’s Manual...
  • Page 11 (Q). (See the above diagram). d) Go back and tighten all bolts using the screwdriver provided. e) Place the side burner support (P) on the side burner assembly (Q), then close the side burner lid. GSF2818KSN Owner’s Manual...
  • Page 12 Then connect the gas hose with the tube of burners. Step 14 (Rotisserie kit assembly. Option) a) Insert two forks (KD), balance block (KF) and roller (KE) into shaft (KC) in sequence. GSF2818KSN Owner’s Manual...
  • Page 13 Move the roller and put it into the slot on right side wall of the firebox. Tighten the screw on roller by hand. Note: Make certain the shaft will be not pulling out from the motor during operation. Fully Assembled View Right Side Left Side GSF2818KSN Owner’s Manual...
  • Page 14: Operating Your Grill

    1. Make 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water. 2. Make sure control knobs are in the “OFF” position. 3. Spray some solution on the connection points of the natural gas hose. GSF2818KSN Owner’s Manual...
  • Page 15: Lighting Your Grill

    If the burner does not light, repeat 2 or 3 more times. If ignition does NOT occur in 5 seconds turn the burner controls to OFF, wait 5 minutes, and repeat the lighting procedure. Adjust valve knob to the desired cooking temperature. GSF2818KSN Owner’s Manual...
  • Page 16 Observing the Heat and Color of the Infrared Ceramic Burner when lit ● Flame of infrared burner might be visible in shaded area. ● After burner is lit, it should feel warm in 5-10 seconds and color of the ceramic plate turns red in approximately 2-3 minutes. GSF2818KSN Owner’s Manual...
  • Page 17: Excess Flow Safety Valve Reset Procedure

    Recommended cleaning materials: Mild dishwashing liquid detergent Hot water Nylon cleaning pad Wire brush Paper clip Putty knife/scraper Compressed air DO NOT use cleaners that contain acid, mineral spirits or xylene. Outside surfaces GSF2818KSN Owner’s Manual...
  • Page 18: Troubleshooting

    Sudden drop in gas flow or reduced Gas supply out of gas Call your local gas company. flame height. Excess flow safety device may have Refer to the Excessive flow safety been activated valve reset procedure on page 16. GSF2818KSN Owner’s Manual...
  • Page 19 1/8 in. increments until flames are correct. Natural Gas Models must be open a minimum of 1/16 in. *Propane Models must be open a minimum of 1/8 in. GSF2818KSN Owner’s Manual...
  • Page 20: Waranty Program

    If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8225, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. R. 507 Eking Building, Shida Road, Liaobu Town, Dongguan City, China Printed in China GSF2818KSN Owner’s Manual...
